Toto PLANO TX474SPV1 Quick Start Manual

SPECIFICATIONS
150±10
G½
G½
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and
fittings.
2. Flow Regulator should not be remove because it could
damage the system
As the product model is constantly updated, the actual
3.
product may not look the same as it shown in the
diagram, but the basic installation principles are the same.
4.
The hot water supply side of the faucets is in a condition
of high temperature. Do not allow skin to contact with the
hardware surface directly. Otherwise,
scalding may occur.
S060159-1N
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm
water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as
ammonia, chlorine, toilet cleaner etc. which could adversely
affect the finish and are not recommended for cleaning
INSTALLATION
1
MOUNT CONNECTORS PARALLEL WITH
Hot
Water
Supply
Leg
0
49
-7
2
* Tighten the nut
Body
"PLANO" SINGLE LEVER SHOWER MIXER
W/O HAND SHOWER SET
THE WALL
Cold
Water
150±10
Supply
Use Seal tape
(Not Include)
150
Cover
Packing
Nut *
TX474SPV1
TROUBLESHOOTING
CHECK
PROBLEM
POINT
1
Water leaks around the handle
Handle is loose 2
1. CONNECTING
NUT
2. BOLT
SOLUTION
Tighten
Tighten
R7
