Click the button to watch the assembly video What’s in the box*: *Not to scale Head end leg End support panel Bedhead bracket Foot end Leg Middle support frame Side support panel End platform Side platform Base platform Bedhead Tapered Bedhead Leg Gumnut Gumnut...
Page 3
Pre-assembly check Click the button to watch the assembly video U-Clip NOTE - Do not remove u-clip from any of the panels Lay out all parts in the desired orientation for the room Head Foot...
Page 4
Click the button Slot head-end legs onto the end to watch the support panel assembly video Ensure surface is flush Attach the bedhead brackets onto the end support panel...
Page 5
Click the button Fasten the bedhead brackets to the to watch the end support panel using the Gumnuts assembly video Slot the end panel to the foot-end legs Ensure surface is flush...
Page 6
Click the button Attach the side support panel to watch the using the metal brackets. assembly video repeat for other side NOTE - Ensure felt pads are facing inwards Ensure surface is flush Fasten the side panel to the legs using the Gumnuts...
Page 7
Click the button Slot the middle support frame to watch the to the side support panels assembly video Ensure surface is flush Lower side platform into position and align the holes...
Page 8
Loosely screw in the tapered Gumnuts Click the button to watch the assembly video Attach the end platforms to the head and foot of the bed by aligning the dowels to the holes...
Page 9
Click the button Fasten the remaining Gumnuts firmly to watch the assembly video Mount the headboard onto the bedhead support by slotting in the bottom brackets and push down firmly...
Page 10
Click the button Fasten the bedhead using the to watch the bedhead Gumnuts provided assembly video Place the base platforms into the frame by aligning with the grooves on the side rail...
Page 11
Click the button to watch the assembly video don’t forget to recycle.
