Summary of Contents for Waterco OXISWIM
- Page 1 D U A L S A N I T I S A T I O N Installation and Operation manual Version: 1.1.3 December 2022...
- Page 2 Improper installation will void the warranty. If you cannot obtain the information to a particular question from this guide, please contact the place of purchase or your nearest Waterco branch for further information. Notice to Installer This manual contains important information about this product's installation, operation, and safe use.
-
Page 3: Table Of Contents
6.3 Connect the Chemical Supply Tubes ................18 6.4 Connect Chemical Injection Points to the Chemical Dosing Unit ......... 19 6.5 Assemble the Foot Filter & Weight................21 6.6 PUMP PROGRAMMING PROCEDURE – OXISWIM ............22 6.6.1 Set Time ......................23 6.6.2... - Page 4 OXISWIM MANUAL 9.6.2 Injection valve maintenance ................35 10 GREEN WATER POOL RECOVERY ..................36 10.1 Green Pool Recovery Using Chlorine ................36 10.2 Changing from Hydrogen peroxide to chlorine............38 10.3 Changing from Chlorine to Hydrogen Peroxide ............39 11 GENERAL SAFETY GUIDELINES ..................
-
Page 5: Chemical Guide
• Perox Pro – Hydrogen peroxide designed explicitly for use in a swimming pool • Perox Safe & Clear – Needed to generate chlorine dioxide from Oxiswim Sanitiser • Perox Activate – Used to break down and remove body fats, oils, sun tan lotions, and makeup. - Page 6 OXISWIM MANUAL CHEMICAL INITIAL DOSE MAINTENANCE 1.5 litres per 10,000 litres raises Approx. 0.09 litres (90ml per Hydrogen Peroxide level by 100ppm 10,000 litres per day) PEROX PRO 21 fl oz. per 1000 US gal raises HP level 1/8 fl oz. per 1000 US gal, per day...
-
Page 7: Introduction
OXISWIM MANUAL 2 INTRODUCTION The Oxiswim Sanitisation system is a revolution in how a swimming pool owner can run their swimming pool or spa. The system has been developed as a result of many years of research using alternatives to chlorine whilst offering the cost savings of being able to use chlorine if desired. - Page 8 OXISWIM MANUAL Attention Installer READ AND FOLLOW ALL INSTRUCTIONS In emergencies, the system should be switched off immediately. The manufacturer is not liable for misuse of this product that may cause damage to persons and/or materials. Only a certified service technician should perform servicing requirements to reduce the risk of injury.
-
Page 9: What Is In The Box
4) 2 x Chemical hose connections kits 5) 2 x Chemical pick-up and float pieces 6) 1 x Oxiswim Sanitiser (Electrolysis equipment) Additional materials required, but not supplied in kit The following items may be required to install the Hybrid system but are not supplied in the kit: •... -
Page 10: Perox Pro - Safety Guide
OXISWIM MANUAL 4 PEROX PRO - SAFETY GUIDE Ensure that all work complies with local authority regulations and any local or organisational workplace health and safety regulations, policies and procedures. STORAGE AND HANDLING Store in the original closed container in an upright position in a cool, well-ventilated place. - Page 11 OXISWIM MANUAL INSTALLATION AND COMMISSIONING P a g e 11 | 45...
-
Page 12: Installation Guide
OXISWIM MANUAL 5 INSTALLATION GUIDE The Oxiswim system can be fitted into most types of pools or spas. In addition, the system can be retrofitted into other existing sanitisation systems to complement the operation of the existing system. 5.1 Water Chemistry... - Page 13 OXISWIM MANUAL When operating on chlorine, the following operating parameters are recommended: Test Result Residual sanitiser chlorine 1.0ppm – 3.0ppm pH level 7.2-7.6 Total Alkalinity level 100ppm – 150ppm Calcium Hardness 180ppm – 400ppm Salinity (= total Pool salt & Mineral Crystals) For low salt cell...
-
Page 14: Phosphate Treatment
Perox Perfect, provided Perox pH control is used to control the pH. Diatomaceous Earth filters are not recommended for use with Hydrogen Peroxide. Copper ionisers can be used in conjunction with the Oxiswim system, but total copper levels must not exceed 1ppm. - Page 15 OXISWIM MANUAL P a g e 15 | 45...
-
Page 16: System Install
POWER supply is off until ready to commission the unit. 6.1.6 Plug the Oxiswim Sanitiser (OS) unit into the GPO located on the Oxiswim controller board. Switch the OS unit to the on position (refer to instructions of the OS). -
Page 17: Install The Chemical Injection Points
OXISWIM MANUAL 6.2 Install the Chemical Injection Points 6.2.1 Acid Injection Point The acid (pH) injection point is to be installed on the pool return line, after all, other pool equipment. Dry fit the chemical injection point saddles to ensure sufficient space and clearances. -
Page 18: Connect The Chemical Supply Tubes
OXISWIM MANUAL Figure 6.6 Figure 6.7 Figure 6.8 Figure 6.9 Figure 6.10 6.2.2 Hydrogen Peroxide/Chlorine Injection Point The Hydrogen Peroxide/Chlorine injection point is connected to the chemical injection point located on the Hydroxyl Radical. The injection point should be on the inlet side of the Hydroxyl Radical Generator. -
Page 19: Connect Chemical Injection Points To The Chemical Dosing Unit
OXISWIM MANUAL Figure 5.11 Connection Point Assembly6 6.3.2 Take one end of the chemical supply tube and feed it through the tightening nut and holding ring. Then push the end of the tube over the pipe holder. Ensure that the tube is pushed on firmly over the tip and screw the tightening nut hand tight. - Page 20 OXISWIM MANUAL Figure 5.13 Figure 5.14 RIGHT Peristaltic Pump HEAD (hydrogen LEFT Peristaltic Pump HEAD (pH) peroxide or chlorine ) Repeat, so both tubes are now connected with one end joined to the chemical injection point, and the other joined to the RIGHT-HAND SIDES (discharge sides) of the chemical dosing unit pumps.
-
Page 21: Assemble The Foot Filter & Weight
OXISWIM MANUAL 6.5 Assemble the Foot Filter & Weight. 6.5.1 Prepare the chemical drum to enable the chemical tube to pass through the exit point of the drum. This can be done by drilling a hole in the cap to the approximate size of the chemical tube (7-8mm). -
Page 22: Pump Programming Procedure - Oxiswim
6.6 PUMP PROGRAMMING PROCEDURE – OXISWIM Please note: The Oxiswim system comes preset to operate on a pool with a water volume of 50,000 litres. If your swimming pool has a different water volume, please refer to the recommended dosage rate charts in this quick reference guide for the appropriate percentages of feed and timer operation times for your specific size pool. -
Page 23: Set Time
OXISWIM MANUAL 6.6.1 Set Time Starting from the main screen press the Up and Down buttons simultaneously to enter the menus. Scroll Up/Down until you see the Set Date and Time option. Select this option by clicking the tick button. -
Page 24: Set Timer
OXISWIM MANUAL 6.6.2 Set Timer Starting from the main screen press the Up and Down buttons simultaneously to enter the menus. Scroll and select the Time Switch option. In the next menu select “Timer Progr.0”. For our uses, we will only be selecting Timer 0 as the main timer on both the ACID and PEROXIDE pumps. - Page 25 OXISWIM MANUAL Tables 6.1 and 6.2 Hydrogen Peroxide Setting Hydrogen Peroxide Pool size Tube Size Summer Run Winter Run % Setting (L/min) Time (hr) Time (hr) 10,000 20,000 30,000 40,000 50,000 60,000 70,000 80,000 90,000 100,000 110,000 120,000 pH Control...
- Page 26 OXISWIM MANUAL Tables 6.3 and 6.4 Chlorine Setting Chlorine Pool size Tube Size Summer Run Winter Run % Setting (L/min) Time (hr) Time (hr) 10,000 20,000 30,000 40,000 50,000 60,000 70,000 80,000 90,000 100,000 110,000 120,000 pH Control Pool size...
-
Page 27: Water Preparation
OXISWIM MANUAL 7 WATER PREPARATION IMPORTANT: The following steps must be followed to ensure the pool is correctly prepared. Measure the pool volume with reasonable accuracy 7.1 Balance the Pool Water Ensure the pool water is balanced within the parameters set out in section 5.1 and within these tolerances be balanced to the Langelier Saturation Index within a range of -0.5 - +0.5... - Page 28 OXISWIM MANUAL OPERATION AND MAINTENANCE P a g e 28 | 45...
-
Page 29: Maintenance
Please ensure that you follow the correct procedure for filling the pool and that pool water chemical levels are carefully monitored. The Oxiswim system is a kit of components. Attempting to operate the system without correctly installing all components or with chemicals other than those recommended in this manual may result in the system not functioning correctly, failure of the system, maybe hazardous, or may cause adverse effects to your swimming pool or bathers. - Page 30 OXISWIM MANUAL MAINTENANCE PROGRAM CHART CHEMICAL INITIAL DOSE MAINTENANCE 1.5 litres per 10,000 litres raises Approx. 0.09 litres (90ml per Hydrogen Peroxide level by 100ppm 10,000 litres per day) PEROX PRO 21 fl oz. per 1000 US gal raises HP level 1/8 fl oz.
-
Page 31: Low Levels Of Hydrogen Peroxide
OXISWIM MANUAL Water balancing should be carried out as required to ensure water is balanced within the following parameters. Within these tolerances, be balanced to the Langelier Saturation Index within a range of -0.5 to +0.5. When operating using hydrogen peroxide the following operating parameters are... -
Page 32: Recommended Chemical List
• Perox Pro – Hydrogen peroxide designed explicitly for use in a swimming pool • Perox Safe & Clear – Needed to generate chlorine dioxide from Oxiswim Sanitiser • Perox Activate – Used to break down and remove body fats, oils, sun tan lotions, and makeup. -
Page 33: Chemical Supply
OXISWIM MANUAL 9.1 Chemical Supply The installer will recommend a local supplier of the recommended products. For further information or a list of other suppliers in your area, please contact your local Waterco branch. 9.2 Cartridge Filters Users should have two cartridge elements. The first is used as the current filter element. The second should be soaked in a water bath and Aqua~Health Natural Filter Cleaner for at least 24 hours before being hosed off (follow the dose rates provided on the product). -
Page 34: Hydroxyl Radical Generator (Hrg)
Please refer to the instruction manual located in the packaging of the Hydroxyl Radical Generator. The catalytic component of the HGR should be replaced every 12 months. Please use the following part number to order it from Waterco using part number 3533000 Hydroxyl Catalyst Replacement. -
Page 35: Injection Valve Maintenance
OXISWIM MANUAL 9.6.2 Injection valve maintenance The chemical injectors should be unscrewed from the pipe location and cleaned every six months. The ball bearing located on the injector's outlet should be checked for correct operation by placing a blunt object into the end of the injector to check the ball is moving freely. -
Page 36: Green Water Pool Recovery
OXISWIM MANUAL 10 GREEN WATER POOL RECOVERY Under normal circumstances, it is best practice to recover a green pool with chlorine. However, if this is not practical, then the following procedure can be followed. NOTE: Do Not Swim While Performing This Procedure... - Page 37 OXISWIM MANUAL Pre-Start directions: 1) Hydrogen Peroxide level is best to be zero when doing this procedure. 2) Backwash filter or clean cartridge filter and flush Multicyclone. 3) To flush all parts of the recirculation system, all pumps, including water features, and solar and in-floor systems, must be running nonstop during this procedure.
-
Page 38: Changing From Hydrogen Peroxide To Chlorine
OXISWIM MANUAL 10.2 Changing from Hydrogen peroxide to chlorine. Generally, this change is done when the swimming season is over. Steps to follow if using liquid chlorine: 1) Allow hydrogen peroxide level to diminish to zero 2) Add 4 kg of powdered chlorine per 50,000 litres of water into the pool as per... -
Page 39: Changing From Chlorine To Hydrogen Peroxide
OXISWIM MANUAL 10.3 Changing from Chlorine to Hydrogen Peroxide Steps to follow if using liquid chlorine: Turn off the chlorine dose pump or chlorine generation via the salt chlorinator 1) Add one drum of Hydrogen Peroxide per 50,000 litres into the pool. If the pool is an indoor pool, please make sure the room is well ventilated during this process 2) Remove the chlorine chemical feed tube from the drum. -
Page 40: General Safety Guidelines
OXISWIM MANUAL 11 GENERAL SAFETY GUIDELINES • In emergencies, the instrument should be switched off immediately. First, disconnect the power cable from the power supply. • When installing, always observe local regulations. • The manufacturer is not liable for any unauthorised use or misuse of this product that may cause injury or damage to persons and/or materials. -
Page 41: Warranty
5. Using the most advanced technology and production procedures available. WARRANTY COVER If a defect occurs in any Waterco product during the warranty period, Waterco will at its discretion, repair the product or replace and install the defective part, free of charge provided that the defect results solely from poor workmanship or materials and is subject to these terms and conditions. - Page 42 7. Electrical equipment has been adequately protected from salt air environments and from salt water, and all repairs and replacements shall be carried out by Waterco or its authorised service dealer unless otherwise authorised in writing by Waterco.
- Page 43 Waterco. LIMITATIONS OF LIABILITY To the extent permitted by law Waterco excludes all liability it may have to the purchaser for indirect, special, or consequential loss arising from or related to any defect in any...
- Page 44 This warranty gives specific legal rights. In addition, the purchaser may have other rights depending on the jurisdiction in which the Waterco product was purchased, or the purchaser is located. SCHEDULE OF WARRANTY PERIODS...
- Page 45 2 Stretton Place Balcatta WA 6021 Perth, Australia. Indonesia p: +61 8 9273 1900 f: +61 8 9273 1999 Jakarta Inkopal Plaza France e-sales & administration: wa.sales@waterco.com Kelapa Gading Parc d’Activite ENTRIMMO Blok B no. 31-32 3 rue Paul Rieupeyroux 69800 SAINT PRIEST.
