Summary of Contents for Lekker Jordaan Step Through
- Page 1 Jordaan Step Through...
- Page 2 Assembly & Maintenance Guide Jordaan Step Through...
- Page 3 Even a manual the size of every Harry Potter book combined couldn’t detail every possible combination, tricks and available components. For this reason, our manual is only applicable bicycle assembled by a skilled to your new LEKKER bicycle and its assembly, alongside any important notes, warnings and maintenance guides. bicycle mechanic.
- Page 4 Index Getting started Fitting the handlebars Fitting the pedals Fitting the saddle Aligning the brakes Aligning the gears Finishing touches Safety and warranty Assembly & Maintenance Guide Jordaan Step Through...
-
Page 5: Getting Started
So, without further ado, unbox your LEKKER bike and feast your eyes on your newest sidekick. Once you’- ve removed the packaging, make sure you have your trustly toolkit to hand, as shown in the illustration on the next page. - Page 6 Assembly & Maintenance Guide Jordaan Step Through...
- Page 7 Handlebars. Using a 6mm allen key, loosen the bolt located at the top of the handlebar stem, then insert it into the frame. Once inserted, centre the handlebar and stem and tighten it. Assembly & Maintenance Guide Jordaan Step Through...
- Page 8 3 or 4. Steering Lock. Your Jordaan Step Through comes fitted with a stee- ring lock to help keep your bike stationary when the kickstand in in use.
-
Page 9: Fitting The Pedals
LEFT pedal: this is the pedal that has indented hori- zontal lines on the small part between the pedal and thread. RIGHT pedal: This pedal has no indented lines and is smooth in between the pedal and thread Assembly & Maintenance Guide Jordaan Step Through... -
Page 10: Fitting The Saddle
Make sure it’s at the correct height. When sitting on the saddle, your knee should be at a slight bend when the pedal is at its lowest position. Then, tighten the bolt. Assembly & Maintenance Guide Jordaan Step Through... -
Page 11: Aligning The Brakes
Tip: To help with the bedding in of your brakes and prevent squeal, we recommend 4-5 firm applications of the brakes for both front and rear during your first test ride. Assembly & Maintenance Guide Jordaan Step Through... - Page 12 Once you are happy, tighten the lock nut again. system. With second gear engaged, the yellow mark should fall in between the two white lines on the click box located on the rear wheel axle. Assembly & Maintenance Guide Jordaan Step Through...
-
Page 13: Finishing Touches
Using the nut and bolt provided, tighten the light Now, you’re good to go. Enjoy your ride, the onto the fixture. Amsterdam way! Assembly & Maintenance Guide Jordaan Step Through... -
Page 14: Safety And Warranty
(including when sold to another consumer) and can only be used by the original buyer of a LEKKER product. If you want to use the warran- ty, please ensure you have your receipt and go to the original shop in which you made your purchase. - Page 15 Assembly & Jordaan Step Through Maintenance Guide lekkerbikes.com Assembly & Maintenance Guide...
