- Page 1 Amsterdam 8-Speed...
- Page 2 Assembly & Maintenance Guide...
- Page 3 Amsterdam 8-Speed...
- Page 4 Contact Warning Australia For safety purposes it is re- Phone commended that you have this 1300 053 525 – Melbourne bicycle assembled by a skilled 0466 596 301 – Sydney bicycle mechanic. Address 23 Provost Street, North Melbourne, 3051, VIC, Australia 415 Bourke Street, Surry Hills, 2010, NSW, Australia Email...
-
Page 5: Welcome To Lekker
Even a manual the size of every Harry Potter book combined couldn’t detail every possible MANUAL LEKKER BIKES / Amsterdam GT combination, tricks and available components. For this reason, our manual is only applicable to your new LEKKER bicycle and its assembly, alongside any important notes, warnings and maintenance guides. Amsterdam 8-Speed... - Page 6 Assembly & Maintenance Guide...
- Page 7 Index Getting started Fitting the front wheel and fender Aligning the brakes Fitting the saddle and handlebars Fitting the pedals Finishing touches Safety and warranty Amsterdam 8-Speed...
-
Page 8: Getting Started
So, without further ado, unbox your LEKKER bike and feast your eyes on your newest sidekick. Once you’- ve removed the packaging, make sure you have your trustly toolkit to hand, as shown in the illustration on the next page. - Page 9 Amsterdam 8-Speed...
- Page 10 Assembly & Maintenance Guide...
- Page 11 Amsterdam 8-Speed...
- Page 12 02. Fitting the front wheel and fender Step 1: Attach the front fender Referring to step 1 in the illustration, loosen the nut and bolt (using the 2x 5mm allen keys) that runs through the front fork and attach the fender, making sure there’s enough space between the tyre and the fender.
- Page 13 Amsterdam 8-Speed...
-
Page 14: Aligning The Brakes
03. Aligning the brakes Lift the wheel off the ground and give it a spin. It should spin freely and without any noise. If you hear a metallic rubbing sound, then the brakes will need adjusting. To do this, you’ll need to use the 5mm allen key. With the bike upside down, adjust the caliper. - Page 15 Amsterdam 8-Speed...
- Page 16 04. Fitting the saddle and handlebars Saddle. Using the 5mm allen key, loosen the seatpost clamp bolt and insert the seatpost. Make sure it’s at the correct height. When sitting on the saddle, your knee should be at a slight bend when the pedal is at its lowest position.
- Page 17 Amsterdam 8-Speed...
- Page 18 Step 2: Next, align the handlebars so that they are straight and perpendicular to the frame. Then, tigh- ten the handlebar stem to the front fork, using the 4mm allen key. Tip: Should you wish to adjust the angles of your grips, brakes and shifter, you can do so with a simple turn of allen key 3 or 4.
- Page 19 Amsterdam 8-Speed...
-
Page 20: Fitting The Pedals
05. Fitting the pedals To assemble the pedals, you will need a 15mm open- ended spanner. Insert the pedal into the crank and ensure the pedals are properly tightened. LEFT pedal: this is the pedal that has indented hori- zontal lines on the small part between the pedal and thread. - Page 21 RIGHT pedal: This pedal has no indented lines and is smooth in between the pedal and thread ATTENTION: please make sure you check the thread direction before inserting the pedals. Fitting the pe- dal to the wrong side can damage the crank arm and is not covered under warranty.
-
Page 22: Finishing Touches
06. Finishing Touches Install the bell on your handlebars, in your preferred position. Generally, this is on the left hand side, next to the brake lever. Pump the tyres to 55-65 PSI If you’ve ordered any accessories such as racks, locks or lights, don’t forget to fit these too. -
Page 23: Safety And Warranty
(including when sold to another consumer) and can only be used by the original buyer of a LEKKER product. If you want to use the warran- ty, please ensure you have your receipt and go to the original shop in which you made your purchase. - Page 24 Assembly & Amsterdam 8-Speed Maintenance Guide lekkerbikes.com Assembly & Maintenance Guide...
