Introduction ......................................................................................................................30
Features ........................................................................................................................30
Description of the device ...............................................................................................31
Safety ................................................................................................................................32
Safety instructions .........................................................................................................32
Operating determinations ..............................................................................................32
Installation........................................................................................................................33
Fitting/Exchanging the lamp ..........................................................................................33
Beampath ......................................................................................................................35
Inserting/Exchanging gobos ..........................................................................................35
Rigging ..........................................................................................................................36
Connection with the mains.............................................................................................37
DMX-512 connection / connection between fixtures ......................................................38
DMX-Protocol ...................................................................................................................39
Function of the control channels - 16 bit protocol ..........................................................39
Function of the control channels - 8 bit protocol: ...........................................................42
Addressing .......................................................................................................................42
Remotely controllable functions ....................................................................................43
Lamp..............................................................................................................................43
Switching on and off the lamp via the Control Board .....................................................43
Colour wheels ................................................................................................................43
Static gobo wheel ..........................................................................................................43
Rotating gobo-wheel......................................................................................................43
3-facet rotating prism .....................................................................................................43
Iris..................................................................................................................................43
Focus - multistep zoom..................................................................................................43
Focus.............................................................................................................................43
Dimmer / Shutter / Strobe ..............................................................................................43
Fan ................................................................................................................................44
Control Board...................................................................................................................44
Main functions ...............................................................................................................44
SPEC -Special functions................................................................................................45
Error and information messages....................................................................................48
Technical specifications .................................................................................................50
Cleaning and maintenance .............................................................................................51
8VHUPDQXDO
Table of contents
28
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Future light MH-860
Summary of Contents for Future light MH-860
-
Page 1: Table Of Contents
0+6SRWOLJKW 8VHUPDQXDO Table of contents Introduction ........................30 Features ........................30 Description of the device ....................31 Safety ..........................32 Safety instructions ......................32 Operating determinations ....................32 Installation........................33 Fitting/Exchanging the lamp ..................33 Beampath ........................35 Inserting/Exchanging gobos ..................35 Rigging ..........................36 Connection with the mains.....................37 DMX-512 connection / connection between fixtures ............38 DMX-Protocol ........................39 Function of the control channels - 16 bit protocol ............39 Function of the control channels - 8 bit protocol: ............42... - Page 2 Appendix...........................52...
-
Page 3: Introduction
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOU INITIAL START - UP! Introduction Thank you for having chosen a FUTURELIGHT MH-860. You acquired a versatile, powerful and intelligent lighting-effect. Unpack your FUTURELIGHT MH-860 and make sure that there are no damages caused by transportation. -
Page 4: Description Of The Device
Description of the device 1 - Projector-head 2 - Yoke 3 - Left side panel 4 - Base 5 - Control Board 6 - Right side panel 7 - Carring handles -8 6 0 Left side panel: POWER 8 - Power-switch 9 - Powercord POWER SUPPLY... -
Page 5: Safety
Safety Safety instructions CAUTION! Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric shock when touching the wires! This device has left our premises in absolutely perfect condition. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this user manual. -
Page 6: Installation
Never run the device without lamp! Do not shake the device. Avoid brute force when installing or operating the device. Never lift the fixture by holding it at the projector-head, as the mechanics may be damaged. Always hold the fixture at the transport handles. When choosing the installation-spot, please make sure that the device is not exposed to extreme heat, moisture or dust. - Page 7 Remove the screws X, Y and Z for re-lamping WARNING! Disconnect the fixture from AC power before re-lamping. Lamp is hot! Risk of fire! Protect hands and eyes. Wait at least 15min. before opening the covers and removing lamp from the fixture. Screws Maximum room temperature t=40°C X, Y and Z...
-
Page 8: Beampath
Beampath 15° radiation angle 18° radiation angle 22° radiation angle Inserting/Exchanging gobos DANGER! Install the gobos with the device switched off only. Unplug from mains before! To insert the gobos open the top cover of the head by loosening the 4 Phillips screws on the front and rear sides of the top cover. -
Page 9: Rigging
Rigging DANGER TO LIFE! Please consider the EN 60598-2-17 and the respective national norms during the installation! The installation must only be carried out by an authorized dealer! The installation of the projector has to be built and constructed in a way that it can hold 10 times the weight for 1 hour without any harming deformation. -
Page 10: Connection With The Mains
DANGER OF FIRE! When installing the device, make sure there is no highly-inflammable material (decoration articles, etc.) within a distance of min. 0.5 m. CAUTION! Use 2 appropriate clamps to rig the fixture on the truss. Follow the instructions mentioned at the bottom of the base. Make sure that the device is fixed properly! Ensure that the structure (truss) to which you are attaching the fixtures is secure. -
Page 11: Dmx-512 Connection / Connection Between Fixtures
The occupation of the connection-cables is as follows: Cable International Brown Live Blue Neutral Yellow/Green Earth The earth has to be connected! In general, lighting effects should not be connected to dimming-packs. DANGER TO LIFE! Before taking into operation for the first time, the installation has to be approved by an expert! DMX-512 connection / connection between fixtures The wires must not come into contact with each other, otherwise the fixtures will not work at all, or will not work properly. -
Page 12: Dmx-Protocol
DMX-Protocol Function of the control channels - 16 bit protocol Channel 1 - Horizontal movement (Pan) Push slider up in order to move head horizontally (PAN). Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The head can be turned by 530° and stopped at any position you wish. - Page 13 Channel 7 - Colour-wheel 1 Linear colour change following the movement of the slider. In this way you can stop the colour-wheel in any position - also between two colours creating double-coloured beams. Between 128 and 190 and between 194 and 255, the colour-wheel rotates continuously the so-called "Rainbow"...
- Page 14 Channel 10 - Static gobo-wheel 0 - 7 Open/hole 8 - 15 Gobo 1 16 - 23 Gobo 2 24 - 31 Gobo 3 32 - 39 Gobo 4 40 - 47 Gobo 5 48 - 55 Gobo 6 56 - 63 Gobo 7 64 - 71 Gobo 8...
-
Page 15: Function Of The Control Channels - 8 Bit Protocol
MH-860 will respond to the controller. If you set, for example, the address to channel 5, the MH-860 will use the channel 5 to 20 for control. Please, be sure that you don’t have any overlapping channels in order to control each MH-860 correctly and independently from any other fixture on the DMX data link. -
Page 16: Remotely Controllable Functions
V/575 W GX-9,5, MSD 575 95 V/575 W GX-9,5 lamp. A relay inside of the MH-860 allows you to switch on and off the lamp via the Control Board on the top side or via your controller without affecting the rest of the lighting. -
Page 17: Fan
The MH-860 is cooled by three axial fans - one each in the projector head and one in the base. The speed of the fan (and of course the noise) can be continuously reduced if very quiet performance is required. -
Page 18: Spec -Special Functions
- Reset Function Press [Enter] key to run reset. This option enables the MH-860 to index all effects (functions) and return to their standard positions. SPEC -Special functions Use the [Up] and [Down] keys to browse through the special functions and select the one by pressing [Enter]. - Page 19 standard operation. Use the [Up] and [Down] keys to select "Off" if you wish to switch the lamp light sensor Off and press [Enter] to confirm or [Mode] to cancel and return to the menu. Important: The option"Off" is for "emergency operation" only if the lamp light sensor is defective and you will wait for a delivery of the spare light sensor! If the lamp light sensor was switched Off, the error messages "LAEr,SnEr,HEAt"...
- Page 20 - Temperature Inside temperature readouts of the fixture in Celsius. Inside temperatures below 80° C are not critical. 80° C and more lead to the lamp being switched off. Please note that the outside temperature should not exceed 45° C. - Fan speed operating By using this function you can choose 5 types of fan speed operating.
-
Page 21: Error And Information Messages
This message appears if you try to switch on the lamp within 5 minutes after having switched it off (the lamp is too hot). The message will appear on the display if the lamp doesn't ignite within 28 seconds. The MH-860 will store this information and automatically ignite the lamp when the 5 minutes period has expired. - Page 22 The ignition of the lamp is seven times unsuccessful (the HEAt message appeared six times before), and the display shows "LAEr", meaning that the lamp could be damaged or even missed, the fixture is overheating (this can occur if the ambient temperature is 45° C or more) or there could be a failure on the ignitor or ballast.
-
Page 23: Technical Specifications
Technical specifications Power supply EU-model: 210/230/250 V AC, 50/60 Hz ~ US-model: 100/120/210/230/250 V AC, 50/60 Hz ~ Power consumption: 900 W Fuse: T 5 A, 250 V Lamp OSRAM HSR 575/2 95 V/575 W GX-9,5 or PHILIPS MSR 575/2 95 V/575 W GX-9,5, MSD 575 95 V/575 W GX-9,5 Optical System igh luminous-efficiency parabolic mirror and double condenser system... -
Page 24: Cleaning And Maintenance
Channel 12 - Rotating gobo index, rotating gobo rotation Channel 13 - Iris Channel 14 - Focus, multi-step zoom Channel 15 - Shutter, Strobe Channel 16 - Dimmer intensity Pan/Tilt Pan movement range 530° Tilt movement range 280° 8/16 bit movement resolution Automatic Pan / Tilt position correction Maximum PAN-movement 530°... - Page 25 Should you have further questions, please contact your dealer. Appendix We hope you will enjoy your MH-860. We can assure you that you will enjoy this device for years if you follow the instructions given in this manual. Should you have further questions, do not hesitate to contact your local dealer.
