Modular T Smart version only
Connection of PRE-HEATING probe
3xD
D
1
ø5mm
ø10mm
ø5mm
2
Not
provided
8
Installation of probe (PRE-HEATING)
Electric pre/post
heating coil
Suggested
distance
beetween probe
and coil
Pre-heating probe
3xD
D
3
Connect the
probe according
to the supplied
wiring diagram
4
9
