- Page 1 Freedom Silver 6000 Plus Power Wheelchair Owner’s Manual Model # MM-FS6000P-W1 MM-FS6000P-W22 E6012...
-
Page 2: Table Of Contents
Table of Contents Welcome Chair Specifications Unpacking, Setting Up & Electrical Connection How to Fold, Unfold & Stroll Wheelchair 8-10 Anti-tipping Wheel, Armrests & Transferring to/from Wheelchair 11-13 Electric Mode & Manual Mode 13-15 Battery & Charger 16-20 Joystick & Basic Driving 21-22 Additional Features 23-25... -
Page 3: Welcome
Welcome Thank you for choosing the Miracle Mobility Freedom Silver 6000 Plus Folding Electric Wheelchair. Miracle Mobility is an industry leader in medical mobility. Your wheelchair is designed to provide years of use. Please read this owner’s manual before attempting to operate your Wheelchair. The safety and operating instructions will help you to understand the performance and limitations of your new mobility aid. -
Page 4: Chair Specifications
Color Options Silver or Rose Gold Chair Specifications MM-FSSPL6000-W1 - Silver Model # MM-FSSPL6000-W22 - Rose Gold 8-50012-19854-3 - Silver UPC Code 8-50012-19849-9 - Rose Gold Motor Type Magnetic Brushless DC Motor Motor Power Rating 200 Watts x 2 (400 Watts Total) Weight Capacity 265 lbs Chair Weight w/o Battery... - Page 6 5 Speed Settings...
- Page 7 Unpacking and Setting UP Image 1 1. Begin by unpacking the wheelchair and spare parts from the shipping carton 2. Remove packing wrap and stand the chair upright (see Image 1) 3. Install the joystick controller on the armrest (see Image 2) 4.
- Page 8 Image 5 Make Electrical Connections with Joystick Make the electrical connections for the joystick and carefully alien prongs. (see Image 3 & 4) Be careful not to bend the connector prongs as this will cause the chair to malfunction) After you unfold the chair carefully install the battery under the seat and make the electrical connections (see Image 5 &...
- Page 9 How To Unfold 7. Grasp one hand on the back push handle and the other hand on the Image 7 seat frame and separate to unfold the frame (see Images 7 & 8) You will hear the safety clip lock in place when the chair is fully expanded in place correctly.
- Page 10 How To Fold Lift the safety clamp found on the back of the chair to unlock your chair (see Image 9) Once the chair is unlocked release the safety clip and push the chair handle forward and down to the ground (see Image 10) Now lift the chair (vertically) upright and it will stand by itself (see Image 11)
- Page 11 How to Stroll the Wheelchair 8. Make sure the chair is powered off then switch the (2) back break levers to manual mode (back toward you) (See Image 12). 9. Once the chair is folded, you can pull the wheelchair using the seat cross bar (see Image 13) 10.
- Page 12 Anti-Tipping Wheels The chair is equipped with anti-tipping wheels. During shipping the wheels are secured to the tightest setting (see Image 14) Push the release button and slide the anti-tipping wheel to the fully engaged button (see Image 15) When engaged the wheels help prevent tipping backwards while navigating inclines (see image 16) Image 14 Image 15...
- Page 13 Lifting The Armrest 14. Notice the armrest release button on the outside of each armrest (see Image 17) 15. This button is in the locked position when the armrests are down 16. You will not be able to lift the armrest when the armrest lever is in the locked position 17.
- Page 14 Transferring Onto the Wheelchair Before sitting, make sure the Power is OFF and chair is in electric mode locking the wheels. If you accidently touch the joystick with the power on the wheelchair could move. Transfer onto the wheelchair sideways, then swing around facing forward. (see Image 19) Transferring from the Wheelchair Image 19...
- Page 15 Electric Mode vs Manual Mode 27. A caregiver can push the power wheelchair in manual mode when the chair is powered off and break levers are in manual mode (see Image 20 & 21) If the power is on and in manual mode, the chair will beep to alert you to turn off the power If the power is on you will not be able to push the wheelchair as the wheels will be locked.
- Page 16 Electric Mode vs Manual Mode (Troubleshooting) If the power is turned off and the brake levers are in electric mode, the wheels will not turn manually Both wheels need to be in the same position (electric or manual) for the chair to function correctly. Pull the brake levers back towards you to engage the manual mode with the joystick turned off and the wheels will turn freely allowing you to push the wheelchair.
- Page 17 Charging the Battery 34. Your chair is equipped with a powerful 24V 12ah lithium-ion battery (see Image 24) This battery meets FAA standards for airline travel 36. You can charge your battery from the joystick by connecting the 3-prong charger to the joystick as shown Charging time is typically 4-5 hours.
- Page 18 Check the battery indicator light before each use to ensure you have the power you need Do not use a battery charger that have not been certified by Miracle Mobility If the battery is damaged, do not handle the battery without protective gloves and eyewear...
- Page 19 Charging The Batteries The wheelchair uses a 24V12ah lithium-ion battery. Your wheelchair will arrive with a partially charged battery The battery should allow you to drive for a distance up to 12 miles under normal operation conditions (see Image 26) The battery can also be removed from the chair and charged using the battery charging port (see Image 27) Allow your wheelchair to charge for 4-5 hours or until the light on the charger turns green...
- Page 20 LED Joystick Controller The joystick is designed to provide all the information you need to safely operate your wheelchair. (see Image 28) also reference page 5 in your manual The joystick is designed to operate the chair with a zero-turn radius (within its own footprint) and will detect micromovement of the joystick Image 28 Driving...
- Page 21 Joystick Controller Practice operation in a safe and controlled environment to learn the operation of your joystick along with the different speeds and the maneuverability of the wheelchair. (see Image 29) When turning, reduce your speed, which will help you avoid any potential tilting or tipping of the wheelchair and adjust the speed depending on your environment.
- Page 22 Basic Driving Before operating your wheelchair, be sure to read all safety information and precautions included in this manual. Operate only in an appropriate environment. Be certain that the power is OFF before sitting in the seat of Silver 6000 Plus Wheelchair. TRANSFER ON There should be no lights on the controller and always board with a side transfer.
-
Page 23: Additional Features
Additional Features Aluminum Construction Rear Suspension Shocks Ideal for Travel The Silver 6000 Plus has a frame The Silver 6000 Plus power The Silver 6000 Plus power construction made of a wheelchair folds within 3 wheelchair is equipped with two lightweight aluminum alloy. - Page 24 Additional Features 400 Watts of Total Power Never a Flat Tire Safety Belt The Silver 6000 Plus has safety The tires are made of a solid The Silver 6000 Plus has a total of polyurethane and rubber seat belt. The nylon belt has a 400 Watts of power.
- Page 25 Additional Features Breathable Seat Cushion Lifting Footrest Padded Back Cushion The seat cushion cover is The Silver 6000 Plus is equipped The backrest is equipped with removable to allow for machine with a footrest that will lift out of enhanced embroidery and washing and is constructed of the way making it easier for additional backrest padding to...
- Page 26 Additional Features Uneven Surfaces Rear Pocket Storage Under the Seat Storage The Silver 6000 Plus can be driven The Silver 6000 Plus has a rear The Silver 6000 Plus has an on hard uneven surfaces such as storage seat pocket to store added under the seat storage dirt or small pebble paths or low valuables.
-
Page 27: Safety Precautions
Safety Precautions Image 29 Safety First Please Do Not ✓ Do not operate in water ✓ Do not operate on stairs or escalators ✓ Do not operation while on a moving vehicle such as a bus ✓ Do not exceed the weight capacity of 265 lbs ✓... - Page 28 General Safety Precautions Image 34 ✓ Do not lean over the front or side of the wheelchair as this can cause a tipping (see images 31 & 32) situation. ✓ Do not transfer on/off the wheelchair from the front. This can cause a tipping (see image 33) situation.
- Page 29 Electromagnetic Interference ✓ Powered vehicles such as the Freedom Silver 6000 Plus wheelchair may be susceptible to electromagnetic interference, which is interfering electromagnetic energy emitted from sources such as radio station, TV station, amateur (two way) radio transmitters, two-way radios, and cellular phones.
-
Page 30: Warranty
Limited Warranty ✓ The purchaser of this product is entitled to a limited warranty as offered by Miracle Mobility, and its affiliates on the following components and timeframes: ✓ Chair frame: (2 years) Motors: (2 years) Controller and CPU system (1 year) Battery (1 year) ✓... - Page 31 Corporate Office 13575 58 St N 201 Clearwater FL 33760 Store Location 10593 Ulmerton Rd Largo FL 33771 Website: www.miraclemobility.com Email: info@miraclemobility.com...
