- Page 1 GETTING STARTED GUIDE EMS1G-48 48-PORT 1G IP NETWORK SWITCH 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM...
-
Page 2: Table Of Contents
1.877.877.2269 SAFETY INSTRUCTIONS .................................. 3 1. INTRODUCTION ..................................... 4 1.1 Hardware Overview ....................................4 1.1.1 Power Consumption for EMS1G-48 Switch ..............................4 1.1.2 Ventilation System ......................................4 2. INSTALLATION ....................................5 2.1 Rackmounting the Switch ..................................5 2.1.1 Back Panel of the Switch ....................................5 2.1.2 Installing in a Rack ......................................5... -
Page 3: Safety Instructions
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 SAFETY INFORMATION TECHNICAL SUPPORT 1.877.877.2269 CAUTION: To avoid electrostatic discharge (ESD) damage, wear grounding wrist straps when handling this equipment. WARNING: Only trained and qualified personnel can install this equipment. Read this guide before you install and power up this equipment. -
Page 4: Introduction
TECHNICAL SUPPORT 1.877.877.2269 This document provides basic information about the EMS1G-48 switch, including how to install a switch and perform the initial configuration. 1.1 HARDWARE OVERVIEW This section contains information about device characteristics and modular hardware configurations for the EMS1G-48 switch. -
Page 5: Installation
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: INSTALLATION TECHNICAL SUPPORT 1.877.877.2269 2.1 RACKMOUNTING THE SWITCH WARNING: Read the safety information in the Safety and Regulatory Information as well as the safety information for other switches that connect to or support the switch. The AC power connector is on the rear panel of the switch. - Page 6 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: INSTALLATION TECHNICAL SUPPORT 1.877.877.2269 FIGURE 2-2. ALIGNING THE BRACKETS 2. Push the rackmounting bracket towards the back to secure the bracket in a locked position. 3. Repeat the process for the rackmounting bracket on the other side of the switch. 4.
-
Page 7: Stacking Multiple Switches
2.2 STACKING MULTIPLE SWITCHES You can stack EMS1G-48 switches up to 12 switches high using mini-SAS fixed stacking ports on the rear of the switch. When multiple switches are connected together through the stack ports, they operate as a single unit with up to 576 front-panel ports. -
Page 8: Starting And Configuring The Switch
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: STARTING AND CONFIGURING THE SWITCH TECHNICAL SUPPORT 1.877.877.2269 The following flow chart provides an overview of the steps you use to perform the initial configuration after the switch is unpacked and mounted. -
Page 9: Connecting The Switch To A Power Source
CAUTION: Read the safety information in the Safety and Regulatory Information manual as well as the safety information for other switches that connect to or support the switch. The EMS1G-48 switches support one or two FRU power supplies. The power receptacle is on the rear panel. 3.2.1 AC POWER CONNECTION 1. -
Page 10: Performing The Initial Configuration
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: STARTING AND CONFIGURING THE SWITCH TECHNICAL SUPPORT 1.877.877.2269 3.4 PERFORMING THE INITIAL CONFIGURATION The initial configuration procedure is based on the following assumptions: Š The switch was never configured before. Š... - Page 11 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: STARTING AND CONFIGURING THE SWITCH TECHNICAL SUPPORT 1.877.877.2269 Š Sets up the SNMP community string to be used by the SNMP manager at a given IP address. Skip this step if SNMP management is Š...
-
Page 12: Easy Setup Wizard Console
Black Box. By downloading SupportAssist and agreeing to be bound by these terms and the end user license agreement, you agree to allow Black Box to provide remote monitoring services of your IT environment and you give Black Box the right to collect the Collected Data in accordance with Black Box’s Privacy Policy... - Page 13 Collected Data from SupportAssist in accordance with these terms. You agree that the provision of SupportAssist may involve international transfers of data from you to Black Box and/or to Black Box’s affiliates, subcontractors or business partners. When making such transfers, Black Box shall ensure appropriate protection is in place to safeguard the Collected Data being transferred in connection with SupportAssist.
- Page 14 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 4: EASY SETUP WIZARD CONSOLE TECHNICAL SUPPORT 1.877.877.2269 NOTE: If it is configured, the default access level is set to the highest available access for the SNMP management interface. Initially only SNMPv2 will be activated. SNMPv3 is disabled until you return to configure security access for SNMPv3 (e.g.
-
Page 15: Next Steps
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 4: EASY SETUP WIZARD CONSOLE TECHNICAL SUPPORT 1.877.877.2269 Step 5: Finally, set up the default gateway. Please enter the IP address of the gateway from which this network is reachable. [0.0.0.0]: 10.1.1.1 This is the configuration information that has been collected: SNMP Interface = “public”@10.1.2.100 User Account setup = admin... -
Page 16: Appendix. Disclaimer/Trademarks
A.1 DISCLAIMER Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Corporation may revise this document at any time without notice. - Page 17 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ 1.877.877.2269 BLACKBOX.COM...
- Page 18 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ _________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ _________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ 1.877.877.2269 BLACKBOX.COM...
- Page 19 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 ________________________________________________________________________________________________ ________________________________________________________________________________________________ _________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ____________________________________________________________________________________________ ________________________________________________________________________________________________ ____________________________________________________________________________________________ ________________________________________________________________________________________________ ____________________________________________________________________________________________ ________________________________________________________________________________________________ ____________________________________________________________________________________________ ________________________________________________________________________________________________ ____________________________________________________________________________________________ ________________________________________________________________________________________________ 1.877.877.2269 BLACKBOX.COM...
- Page 20 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL SUPPORT 1.877.877.2269 © COPYRIGHT 2018. BLACK BOX CORPORATION. ALL RIGHTS RESERVED. EMS1G-48_GETTING-STARTED_REV1.PDF...
