INSTRUCTIONS FOR USE

The cooker fan is made for mounting in a
cabinet. The fan is equipped with the Easy-
Clean motor core, LED lighting and metal
mesh filters. The cooker fan has three
speeds, an intensive mode as well as a ven-
tilation mode. The fan is equipped with an
automatic power control function and an
additional water sensor option is also avai-
lable. Use, care, maintenance etc., are des-
cribed in these instructions.
FUNCTION SWITCH
A B
Fig. 1
A. Lighting.
B. Ventilation mode. The extractor fan runs
on low speed for 60 minutes.
C. Speed 1 on fan motor.
D. Speed 2 on fan motor.
E. Speed 3 on fan motor. If the button is
held in for 2 seconds, the fan switches
to intensive mode. After 7 minutes, the
fan motor returns to its previously set
mode. The fan can be started and stop-
ped with buttons B-E.
Attention!
For certain installations of the fan inten-
sive mode is not used.
Start the kitchen fan before cooking. If
cooking is done without that the fan is star-
ted manually, it will start automatically. This
is to prevent fumes from cooking spreading
in the room. After cooking, the kitchen fan
will automatically switch off with some
delay.
Adjust the speed of the fan depending on
the type of food you are preparing. Prefe-
rably allow the fan to run on low speed for
a while after cooking. If needed, also use
the fan's low speed when the oven is in
use, or after using the dishwasher.
991.0623.409/D000000006538/180023/
C D E
FUNCTIONALITY OF SAFETY
SYSTEM
Fig. 2
A. Sensor.
B. Button for controlling functions.
C. Indicator light for activated functions.
D. Warning light in the event of an overhea-
ted hotplate or oven.
E. Warning light in the event of water lea-
kage (if a water sensor has been fitted).
F. Button for child safety lock on cooker.
G. Indicator light for child safety lock.
H. Button for programming mode.
I. Indicator lamp.
The Safe System automatically monitors
temperature changes on the cooker. When
a situation occurs where the temperature
increases, an alarm goes off and the power
to the cooker is cut off.
Max connection times for hotplates and
oven is 1 hour. To use the hob or oven
again, press the OK button, Fig. 2B.
When the system is properly connected and
working normally, the OK symbol's indica-
tor light flashes at five second intervals.
CHILD SAFETY LOCK FUNCTION
Activate the child safety lock by pressing
the lock symbol.
23
