Summary of Contents for 3Com 35
- Page 1 35 and 45 Amp AC and DC Total Control Chassis Getting Started Guide Part No. 1.024.1326-00...
- Page 2 35 and 45 Amp AC and DC Total Control Chassis ® Getting Started Guide http://www.3com.com/ Part No. 1.024.1326-00...
- Page 3 3Com Corporation reserves the right to revise this documentation and to make changes in content from time 95052-8145 to time without obligation on the part of 3Com Corporation to provide notification of such revision or change. 3Com Corporation provides this documentation without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
-
Page 4: Table Of Contents
ONTENTS VERVIEW Contacting 3Com................... 1-1 Document Conventions ................1-2 Product Description ................1-2 NSTALLATION Supplies ....................2-1 Conditions ..................... 2-1 Installing a Chassis in a 19-inch Rack ............2-2 Mid-mounting a Chassis in a 19-inch Rack ..........2-3 Installing a Chassis in a 23-inch Rack ............2-5 Mid-mounting a Chassis in a 23-inch Rack .......... -
Page 6: Overview
VERVIEW This chapter provides contact information and document conventions, and describes the 35 and 45 Amp AC and DC Total Control chassis. Contacting 3Com Call the appropriate number listed below for technical support. If you are calling from the United States or Canada Dial 1.800.231.8770... -
Page 7: Document Conventions
1: O HAPTER VERVIEW Document The following table lists conventions used throughout this guide. Conventions Icon Notice Type Description Information note Information that contains important features or instructions. Caution Information to alert you to potential damage to a program, system, or device. Warning Information to alert you to potential personal injury or fatality. - Page 8 Product Description Various chassis configurations operate with both analog or digital phone services. In addition, the chassis is fully manageable via Simple Network Management Protocol (SNMP) through the Network Management Card (NMC) placed in slot 17 of the chassis.
-
Page 10: Installation
NSTALLATION This chapter contains 35 and 45 Amp AC and DC Total Control chassis installation information. Supplies To install the chassis you will need: A flat-head screwdriver A #2 Phillips screwdriver Fasteners (nuts, bolts, and screws) compatible with the rack... -
Page 11: Installing A Chassis In A 19-Inch Rack
HAPTER NSTALLATION Installing a Chassis To install the chassis: in a 19-inch Rack 1 Slide the chassis into the rack, until the front of the chassis is flush with the front of the rack. 2 Secure the chassis mounting flange to the front vertical rails of the rack. a Insert the two bottom fasteners (screws). -
Page 12: Mid-Mounting A Chassis In A 19-Inch Rack
Mid-mounting a Chassis in a 19-inch Rack Mid-mounting a To mid-mount the chassis: Chassis in a 19-inch Rack 1 Secure the extender brackets to the chassis mounting flanges. Mid-mount brackets must be used if you wish to adhere to the Bellcore Standard on Earthquakes NEBS TR-NWT-000063, Sections 5.5.7 and 5.5.9, Issue 5. - Page 13 HAPTER NSTALLATION 2 Secure the extender brackets and chassis to the mounting rails of the rack. a Insert the two bottom fasteners (screws). b Insert the two top fasteners (screws).
-
Page 14: Installing A Chassis In A 23-Inch Rack
Installing a Chassis in a 23-inch Rack Installing a Chassis To install the chassis: in a 23-inch Rack 1 Secure the extender brackets to the chassis mounting flanges using fasteners (screws). 2 Slide the chassis into the rack, until the front of the chassis is flush with the front of the rack. - Page 15 HAPTER NSTALLATION 3 Secure the extender brackets and chassis to the mounting rails of the rack. a Insert the two bottom fasteners (screws). b Insert the two top fasteners (screws).
-
Page 16: Mid-Mounting A Chassis In A 23-Inch Rack
Mid-mounting a Chassis in a 23-inch Rack Mid-mounting a To mid-mount the chassis: Chassis in a 23-inch Rack 1 Secure the extender brackets to the chassis mounting flanges. Mid-mount brackets must be used if you wish to adhere to the Bellcore Standard on Earthquakes NEBS TR-NWT-000063, Sections 5.57 and 5.5.9, Issue 5. - Page 17 HAPTER NSTALLATION 2 Secure the extender brackets and chassis to the mounting rails of the rack. a Insert the two bottom fasteners (screws). b Insert the two top fasteners (screws).
-
Page 18: A Technical Specifications
ECHNICAL PECIFICATIONS Certification Complies with FCC Part 15 Class A EMI/RFI requirements; complies with FCC Part 68; UL-listed; CSA-approved; IC-certified. Regulatory United States Compliance FCC Part 15 Compliance Statement Statements This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 19: Environment
A: T PPENDIX ECHNICAL PECIFICATIONS Environment Shipping and Storage Temperature: -25° C to 75° C -13° F to 167° F Humidity: 0 to 95%, non-condensing Operating Temperature: 0 to 40° C 32° F to 104° F Humidity: 0 to 95%, non-condensing... - Page 23 ® 3Com Corporation 5400 Bayfront Plaza P.O. Box 58145 Santa Clara, CA 95052-8145 ©1998 3Com Corporation All rights reserved Printed in the U.S.A. p/n 1.024.1326-00...
