Wireless USB Audio Transport
UWL-1
Instruction Manual
Thank you for purchasing the Onkyo Wireless
USB Audio Transport. Please read this manual
thoroughly before making any connections and
plugging it in.
Following the instructions in this manual will
enable you to obtain optimum performance and
listening enjoyment from your new Wireless USB
Audio Transport.
Please retain this manual for future reference.
Contents
Package Contents........................... 5
Features........................................... 6
Transmitter (UTX-1) ........................... 7
Receiver (RX-1) Rear......................... 7
Getting Started................................ 8
System Requirements ............................. 8
Setting Up the UWL-1 ..................... 9
Typical Hookup Example.................. 10
Changing the Receiver's ID ................... 11
Using the UWL-1 ........................... 12
Settings ...................................... 12
Listening to Music .................................. 13
Enabling CD Playback ........................... 15
Troubleshooting ............................ 16
Specifications ............................... 20
E
n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UWL-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onkyo UWL-1

Summary of Contents for Onkyo UWL-1

  • Page 1: Table Of Contents

    Audio Transport. Please retain this manual for future reference. Contents Package Contents... 5 Features... 6 Getting to Know the UWL-1 ... 7 Transmitter (UTX-1) ... 7 Receiver (RX-1) Front and Top ... 7 Receiver (RX-1) Rear... 7 Getting Started... 8 System Requirements ...

  • Page 2: Important Safety Instructions

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING QUALIFIED PERSONNEL.
  • Page 3 Never handle this unit or its power cord while your hands are wet or damp. If water or any other liquid gets inside this unit, have it checked by your Onkyo dealer. 5. Handling Notes • If you need to transport this unit, use the original packaging to pack it how it was when you originally bought it.
  • Page 4 Precautions—Continued The available scientific evidence does not show that any health problems are associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are abso- lutely safe. Low power Wireless devices emit low levels of radio frequency energy (RF) in the micro- wave range while being used.

  • Page 5: Package Contents

    GROEBENZELL, GERMANY ONKYO EUROPE ELECTRONICS GmbH We, the Onkyo hereby declare that this Wireless USB Audio Transport, model UWL-1 is in compli- ance with the essential requirements and other rele- vant provisions of Directive 1999/5/EC and the Electromagnetic Compatibility Directive 89/336/ EEC in accordance with the tests conducted to the appropriate requirements of the relevant standards.

  • Page 6: Features

    Transmitter into a free USB port on your PC, and that’s it! ■ 30 meter range The UWL-1 has a 30 meter range, so you can transmit audio all around your house. Note that the usable range may be reduced by walls and floors constructed from concrete or steel.

  • Page 7: Getting To Know The Uwl-1

    Getting to Know the UWL-1 The page numbers in parentheses show where you can find the main explanation for each item. ■ Transmitter (UTX-1) ■ Receiver (RX-1) Front and Top ■ Receiver (RX-1) Rear Protective cap (9) USB connector (9) Plugs into a USB port on your PC.

  • Page 8: Getting Started

    • Intel and Pentium are registered trademarks of Intel Corporation. Note: Even if your PC meets the above requirements, it may not work with the UWL-1 due to its specifications or the way it’s configured. See the Onkyo Web site for up to date com- patibility information and other issues.

  • Page 9: Setting Up The Uwl-1

    Transmitter to another location may resolve the issue. If you’re using a powered USB hub, make sure its AC adapter is plugged in when you use the UWL-1. • Always stop audio playback on your PC before plugging in or unplugging the Transmit- ter.

  • Page 10: Connecting The Receiver (Rx-1)

    (loose connections can cause noise or malfunctions). Optical Digital Jack The UWL-1’s optical digital jack has a shut- ter-type cover that opens when an optical plug is inserted and closes when it’s removed. Push the plug in all the way.

  • Page 11: Connecting An Onkyo Component With A Dc Output (European Model)

    Setting Up the UWL-1—Continued ■ Connecting an Onkyo Component with a DC Output (European Model) Connect one or the other. Miniplug-to-RCA audio cable Optical digital audio cable OPTICAL LINE 1 DC5V 2W/0.4A MAX. DIGITAL DC OUT Onkyo component with DC output Changing the Receiver’s ID...

  • Page 12: Using The Uwl-1

    ■ Volume Used to adjust the volume. To get the best sound quality with the UWL-1, set all of the Volume sliders to maximum and use the volume control on the audio system or powered speakers connected to the Receiver to adjust the volume level.

  • Page 13: Listening To Music

    Using the UWL-1 —Continued Listening to Music With the UWL-1, you can play the digital music stored on your PC through an audio system or powered speakers located in any room in your house. You can also stream Internet radio, CDs, or DVDs.

  • Page 14: Changing The Wireless Channel

    Using the UWL-1—Continued Note: While the Transmitter is plugged into your PC, your PC’s built-in speakers will not output any sound. This is because USB audio devices have priority. To output sound from your PC’s built-in speakers, unplug the Transmitter, or change the Default device setting on the Audio tab of the Sounds and Audio Devices Properties control panel (see page 19).

  • Page 15: Enabling Cd Playback

    Using the UWL-1 —Continued Enabling CD Playback For the UWL-1 to wirelessly transmit audio from your PC’s CD/DVD drive, your CD/DVD drive must support digital audio output and, in Windows CD-ROM device option must be selected. ■ Windows ® Click the Start button, click Control Panel, click Performance and Maintenance, and then click System.

  • Page 16: Troubleshooting

    Troubleshooting If you’re having trouble using the UWL-1, look for a solution here. Some issues may be due to a connected component, so refer to the manuals for your other components, too. If you can’t resolve the issue yourself, contact your Onkyo dealer.
  • Page 17 • For copyright reasons, it’s not possible to record from the Receiver’s optical digital jack. Note: The UWL-1 uses microcomputers for signal processing and control functions. In very rare situations, severe interference, noise from an external source, or static electricity may cause it to lockup.

  • Page 18: Confirming Driver Installation

    Troubleshooting—Continued Confirming Driver Installation You can confirm that the necessary drivers for the UWL-1 are installed. ■ Windows ® Click the Start button, click Con- trol Panel, click Performance and Maintenance, and then click Sys- tem. On the Hardware tab, click the Device Manager button.

  • Page 19: Confirming The Audio Playback Device

    Click the Start button, point to Settings, click Control Panel, click Sounds and Multime- dia, and then click the Audio tab. To use the UWL-1, in the Sound playback section, the Default device should be set to: • C-Media USB Headphone Set Normally, this is selected automatically when the Transmitter is plugged into your PC.

  • Page 20: Specifications

    ONKYO CHINA LIMITED Unit 1&12, 9/F, Ever Gain PlazaTower 1, 88, Container Port Road, Kwai Chung, N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039 http://www.ch.onkyo.com/ SN 29344245 (C) Copyright 2004 ONKYO CORPORATION Japan. All rights reserved. HOMEPAGE http://www.onkyo.com/ Printed in Japan I0609-1...
