Connects2 CAM-8 User Manual

Adjustable angle camera vertical adjustment

U s e r M a n u a l

CAM-8

PRODUCT FEATURES:

Image Sensor: 7080

TV Lines: 480

Lumen: 0.1 Lux

Horizontal Angle: 170 Degrees

Vertical Angle: 120 Degrees

TV System: NTSC/PAL

Video Output: 1.0V p-p 75ohm

Operating Voltage: 12V DC (Negative Ground)

Current Consumption: 90mA @ 13.8V

Waterproof Rating: IP68

Parking Lines: Yes

Removable Lines: Yes

Enhanced Performance In Low Light: Yes

Prior to Installation

Read the manual prior to installation. Technical knowledge is necessary for installation.

Please ensure you use the correct tools to avoid damage to the vehicle or product.

Connects2 can not be held responsible for the installation of this product.

Connects2 want to provide a fast and suitable resolution should you encounter any tech-

nical issues. With this in mind, when contacting Connects2, try to provide as much Infor-

mation as possible. This will speed up the process and help us to help you.

Please use our dedicated online technical support centre: support.connects2.com

Adjustable Angle Camera

Vertical Adjustment
