HT-R520_En.book Page 1 Monday, March 15, 2004 2:47 PM
AV Receiver
HT-R520
Instruction Manual
Thank you for purchasing an Onkyo AV Receiver.
Please read this manual thoroughly before making
connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new AV Receiver.
Please retain this manual for future reference.
Contents
Introduction ..................................... 2
Connection .................................... 16
Turning On & First Time Setup..... 31
Basic Operation
Playing your AV components ....... 32
Using the Tuner............................ 34
Enjoying the Listening Modes ..... 38
Advanced Operation ..................... 43
Troubleshooting ............................ 56
E
n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT-R520 and is the answer not in the manual?

Questions and answers

steve sheer
March 1, 2025

my stereo turns on lights up but no sound sometimes after 5-10 minutes in kicks in and everything works fine some times it takes a couple hours for it to start

0
1 comments:
Mr. Anderson
March 1, 2025

Intermittent sound issues with the Onkyo HT-R520 that turns on but has no sound for several minutes could be caused by:

1. Speaker Cables Not Connected Properly – Check and secure all speaker cable connections.
2. Incorrect Speaker Configuration – Verify and adjust the speaker configuration settings.
3. Subwoofer Standby Mode – If the input signal is too low, the subwoofer may enter Standby mode. Increase the subwoofer pre-out output level.
4. Microcomputer Lockup – External interference or static electricity can cause the unit to lock up. Unplug the power cord for at least five seconds and then plug it back in.
5. Power Supply Issues – Ensure that the power plug is fully inserted into the wall outlet and consider using a different branch circuit if needed.

Checking and addressing these issues should help resolve the problem.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Onkyo HT-R520

Summary of Contents for Onkyo HT-R520

  • Page 1 HT-R520_En.book Page 1 Monday, March 15, 2004 2:47 PM AV Receiver HT-R520 Instruction Manual Thank you for purchasing an Onkyo AV Receiver. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new AV Receiver.

  • Page 2: Introduction Important Safety Instructions

    HT-R520_En.book Page 2 Monday, March 15, 2004 2:47 PM WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.

  • Page 3: Memory Backup

    1. Recording Copyright —Unless it’s for personal use only, recording copyrighted material is illegal with- out the permission of the copyright holder. 2. AC Fuse —The AC fuse inside the HT-R520 is not user-serviceable. If you cannot turn on the HT-R520, contact your Onkyo dealer.

  • Page 4: Supplied Accessories
