Luffing jib crane
Loadview
System manual
Manual No. SM0974050 R1-2
11/2013
Set LV7080 (Art. No. 0402980)
Set LV7085 (Art. No. 0406720)
Set LV7085 (Art. No. 0406720)
ORLACO PRODUCTS BV
Albert Plesmanstraat 42, 3772 MN Barneveld
PO Box 193, 3770 AD Barneveld
The Netherlands
Phone: +31 (0) 342 404555
Fax:
+31 (0) 342 404556
E-mail: info@orlaco.com
Internet: http://www.orlaco.com
Set LV7080 (Art. No. 0402980)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Orlaco Loadview LV7080
Summary of Contents for Orlaco Loadview LV7080
- Page 1 Set LV7080 (Art. No. 0402980) Set LV7085 (Art. No. 0406720) Set LV7085 (Art. No. 0406720) Set LV7080 (Art. No. 0402980) ORLACO PRODUCTS BV Albert Plesmanstraat 42, 3772 MN Barneveld PO Box 193, 3770 AD Barneveld The Netherlands Phone: +31 (0) 342 404555...
-
Page 2: Table Of Contents
Orlaco Products BV Service department. The camera/display systems from Orlaco comply with the latest CE, ADR and EMC regulations. All products are manufactured in accordance with the ISO 9001 quality management system, ISO... -
Page 3: Introduction
System manual 1. Introduction The crane operator can see immediately on his monitor when a lifting operation could possibly become dangerous. The operator is no longer dependent on information from other persons by means of a portable radios. He can make the right decisions without delay and thus prevent accidents on site. -
Page 4: Mounting Af-Zoom Camera Bracket
System manual 3. Mounting camera bracket 3.1. Oil Damped Camerabracket (0701200) See figure 1A. Art. No. 0910250 Quick release set bolt version. Mount at first the mounting bracket to the AF-Zoom Camera with the included mounting bracket, according figure 1A. Use for this the following bolts nuts and washers. -
Page 5: Mounting Afi Camera
System manual 4. Mounting AFI Camera 4.1. Mounting OGB Adapter quick release to the crane See figure 4. Art. No. 0910250 Quick release set bolt version. Mount at first the mounting bracket to the AF-Zoom Camera with the included mounting bracket, according figure 4. Use for this 45°... -
Page 6: Operation Afi Camera
• Ensure that all parts are firmly fixed, stable and secure. • Check that the power and connector cables are suitable for the system power supply; use exclusively Orlaco multi-cable, product AFI Auto focus Insulated no 1304410/1221000. Art. No. 0103610/40 Cable connection 4.4. -
Page 7: Power Supply
System manual 5. Power supply, Art. No. 0503810 5.1. Electrical connections (Back side) of the power supply sockets. The connectors A and B tor the external devices are interchangeable, see figure 8 1 = Red (Power output) 24V/DC 7P female socket 1 = Red (Power output) 24V/DC 2 = White (Power output) GND 2 = White (Power output) GND... -
Page 8: Mounting Monitor 7
System manual 6. Mounting 7” monitor units in mm Set LV7080 (Art. No. 0402980) ∅7,0 (4x) See figure 8 and 9. 40,5 ∅64,5 Figure 8 Optional Foot switch 0502630 Joystick 0702000 Zoom in and out Zoom in and out (connected to wire 6 and 7) Connections to the monitor: 1 = Red = Power input: 18...30V/DC... -
Page 9: Mounting Monitor 12
System manual 7. Mounting 12” monitor Set LV7085(Art. No. 0406720) See figure 11 and 12. ∅7,0 (4x) 40,5 ∅64,5 units in mm Figure 11 Connections to the monitor: (Secure the power input with a 5A fuse) 1 = Red = Power input: 12...30V 2 = White = Power input: 0V 3 = Blue... -
Page 10: Release Notes
System manual 8. Release notes: R1-0, First issue R1-1, Article numbers changed, cable in set added; August 2013 R1-2, Set LV 7085 added; August 2013 SM0974050 R1-2... - Page 11 ORLACO Orlaco is a production company specialised in making camera-, and monitor systems for commercial vehicles, fork-lift trucks, cranes, off shore and maritime. Our objective is to design and produce camera systems for the professional market that improve the drivers view and increase operating efficiency.
