ACCESSORIES

Second CONTROL HEAD
RMK-4 (Main unit attachment)
The serial number seal is put
here, and labeled "RMK-4."
Mounting bracket
Flat washers
for CONTROL HEAD
(M5)
Spring
washers (M5)
Nuts (M5)
Key caps
Microphone hanger
and screw set
Function name
KEY-STICKER
stickers
• Used for labelling
the programmable
function keys. See
at right for details.
Mounting screws
(M5×12)
Self-tapping screws
(M5×16)
Bracket screws
• Function name stickers
There are no labels on the programmable function keys since
the functions can be freely assigned to these keys.
Attach the supplied function name stickers to the appropriate
keys for easy recognition of the key's assigned function as
shown below.
Then, protect the attached stickers from coming off with the
supplied key cap, as shown below.
Function name sticker
Key cap
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ii
