Chassis Intrusion
DP2
DP1
USB2_3/4
USB3_3/4
USB2_1/2
USB3_1/2
LAN3
LAN2
LAN1
DC-IN
Single 12V +/-10% DC (CMS101)
Wide Range 15~36V (CMS103)
Front Audio
M.2 2230 E key
M.2 2242/3042/3052 B key
USB2_7/8
USB2_5/6
M.2 2280 M key
SPI
SATA 3.0
SATA 3.0
SATA Power
CPU FAN
Quick Reference | CMS101/CMS103
Battery
DIO Power
DIO
PCIE 1
Clear CMOS
Front Panel
COM1
COM2
COM3
COM4
Power Selection COM 1
Power Selection COM 2
Panel Power Select
LVDS Power
SYS FAN
LCD/Inverter Power Select
Backlight Voltage Select
LVDS
LPC
