3-2 Basic Switch Functions
Checking Port/Computer
Status
You can confirm which ports are currently active and whether each port has a
computer or a slave switch connected by the following:
1. Press Print Scrn. The CCR Selection window appears on the monitor.
Plus
Asterisk
2. Press Esc to exit the CCR selection window.

Advanced Switch Operations

Many switch functions are available that allow you to tailor your system to
meet your unique needs. Like the basic operation of the unit, system
configuration is achieved through the keyboard and the Console Configuration
Reporting. Some of the advanced operations include :
The symbols after the Port or Name columns show the status of the
port as follows:
Type of Symbol
Scanning the computers connected to the switch
Displaying switch firmware version and settings
Saving switch settings
Resetting the mouse and keyboard
Table 3-1
Port/Computer Status
Symbol
+ Computer connected and running
* Slave connected and running
Meaning
