- Page 1 FLOOR STANDING DZDF4-2A-XMi D22 - D80 DZDF5-2A-XMi D22 - D80 DZGF3B-2A-XMi D22 - D80 M0F400002 - 07-21...
- Page 2 Dear Customer, Congratulations for having chosen this product. Clivet has been working for years to offer the market systems able to assure maximum and long- lasting wellbeing with high reliability, efficiency, quality ad safety. The company aim is that to offer its customers developed systems that assure the best comfort, reduce energy consumptions and installation and maintenance costs for the entire life-span of the system.
-
Page 3: Table Of Contents
When installing the unit in a small room, take measures CONTENTS PAGE against to keep refrigerant concentration from exceeding PRECAUTIONS..................allowable safety limits in the event of refrigerant leakage. Contact the place of purchase for more information. INSTALLATION INFORMATION..............2 Excessive refrigerant in a closed ambient can lead to oxygen ATTACH ED FITTINGS................ -
Page 4: Installation Information
DISPOSAL： Do not dispose this product as unsorted keep the interconnection cable away from the copper municipal waste. Collection of such waste separately for tube. special treatment is necessary. After completing the installation work, check that the refrigerant does not leak. Toxic gas may be produced if the refrigerant leaks into the room and comes into contact with a source of fire, such as a fan heater, stove or cooker . -
Page 5: Attached Fittings
3. ATTACHED FITTINGS NOTE All the illustrations of this manual are for explanatory purpose Please check whether the following fittings are of full scope. only. If the appearance, functions and physical objects are If there are some spare fittings , please restore them carefully. inconsistent, refer to the actual product. -
Page 6: Indoor Unit Installation
Ceiling has no obvious slant. There is sufficient space for repair and maintenance work to be carried out. No leakage of flammable gas. The length of the piping between the indoor and outdoor units is within the permitted range (refer to the manual on installation of the outdoor unit). - Page 7 Indoor Unit Installation 1. Remove the casing(for uncovered product) Remove screws ①*2 and ②*2 and then the casing. Base Base Footing Casing assembly Fig.4-6b 4. Installation with lifting bolts Use different bolts for the installation depending on the installation environment. Fig.4-4 2.
- Page 8 5. Dimensions Connecting point of Connecting point of refrigerant pipe refrigerant pipe BOLT HOLES (Liquid side ΦE) (Gas side ΦF) Fig.4-11 Uncovered product...
- Page 9 Connecting point of Connecting point of refrigerant pipe refrigerant pipe (Liquid side ΦE) (Gas side ΦF) BOLT HOLES Fig.4-12 Covered product Table 4-1 Capacity(KW) 1020 1360 1020 1020 1240 1360 1360 1104 1104 1104 12.7 15.9 12.7 12.7 12.7 12.7 15.9 1133 1253...
- Page 10 4.4 Cleaning the air filter 4.5 INSTALL THE CONNECTING PIPE To ensure proper air return, clean the air filter at least once CAUTION every month. If used in a dusty environment, the filter must be cleaned on a more frequent basis. Take the air filter out Do not let air, dust, or other impurities fall in the pipe system before you can clean it.
- Page 11 Before the socket cap is installed on the pipe socket, apply some refrigerant Refrigerant Piping Installation oil on the socket (both inside and outside), and then rotate it three or four 4.6.1 Length and Level Difference Requirements for the Piping times before you tighten the cap.
-
Page 12: Water Discharge Piping Installation
Water Discharge Piping Installation 5.2 Water Discharge Test 5.1. Water Discharge Piping Installation for Indoor Unit Before the test, make sure that the water discharge pipeline is 1. Use PVC pipes for the water discharge pipes (outer diameter: 37~39 mm, smooth, and check that each connection is sealed properly. - Page 13 3. Select circuit breaker that having a contact separation in all poles ：Copper wire not less than 3 mm providing full disconnection，where MFA is Circular wiring terminal used to select the current circuit breakers and residual current operation breakers: Proper power wiring connections Insulation tube Table 6.3 Power cord...
-
Page 14: On-Site Configuration
Caution • For the specific connection method, refer to the instructions in the corresponding wired controller manual to carry out the wiring and connections. Indoor unit 1 Handling the Electrical Wiring Connection Points Once the wiring and connections are done, use tie straps to secure the wiring properly so that the connection joint cannot be pulled apart by external force. -
Page 15: Test Run
Test Run Things to Note Before Test Run Auto restart function enabled Indoor and outdoor units are properly installed; Piping and wiring are correct; Auto restart function disabled No leakage from the refrigerant piping system; Water discharge is smooth; Insulation is complete; Grounding line has been properly connected;... - Page 16 2.2kW 70.0 60.0 60.0 50.0 50.0 40.0 40.0 30.0 30.0 20.0 20.0 10.0 10.0 Airflow (m 2.8kW 70.0 60.0 60.0 50.0 50.0 40.0 40.0 30.0 30.0 20.0 20.0 10.0 10.0 Airflow (m 3.6kW 70.0 60.0 60.0 50.0 50.0 40.0 40.0 30.0 30.0 20.0...
- Page 17 4.5kW 70.0 60.0 60.0 50.0 50.0 40.0 40.0 30.0 30.0 20.0 20.0 10.0 10.0 Airflow (m 5.6kW 70.0 60.0 60.0 50.0 50.0 40.0 40.0 30.0 30.0 20.0 20.0 10.0 10.0 Airflow (m 8.0kW 70.0 60.0 60.0 50.0 50.0 40.0 40.0 30.0 30.0 20.0...
- Page 18 Oper Manual • Do not touch the unit or its remote controller with wet hands, as doing so can lead to electric shocks. There are two types of precautions as described below: • Do not allow children to play near this unit, as doing so risks injury. Warning: Failure to comply may lead to death or serious injury.
-
Page 19: Part Names
• To avoid damaging the remote controller, exercise caution when ● Version II using it and replacing its batteries. Do not place objects on top of it. Vertical unit with casing. The air intake is at the bottom and the •... -
Page 20: The Explain Of The Display Panel
11. The Explain Of The Display Panel The display panel has one type and the appearance of the type is shown in Figure 11.1. Anti-cold air / Check button defrosting indicator Infrared signal receiver Digital LED display MANUAL OPERATION TIMER DEF./FAN ALARM Timer indicator Alarm indicator Operation lamp... -
Page 21: Maintenance
1. Take out the air intake grille Note that outlet air is cooler or heater than set room temperature. Remove the bolts, push the grille switches simultaneously, as Avoid direct exposure to outlet air as it may be too cool or hot. indicated in Figure 13.1. -
Page 22: Symptoms That Are Not Faults
14. Symptoms That Are Not Faults The following symptoms may be experienced during the normal operation of the unit and are not considered faults. Note: If you are not sure whether a fault has occurred, contact your supplier or service engineer immediately. - Page 23 15.2 Unit Troubleshooting Symptom Possible causes Troubleshooting steps A power cut has occurred (the power to the premis- Wait for the power to come back on. es has been cut-off). Power on the unit. This indoor unit forms part of an air conditioning system that has multiple indoor units that are all connected.
- Page 24 15.3 Remote Controller Troubleshooting Warning: Certain troubleshooting steps that a professional technician may perform when investigating an error are described in this owner's manual for reference only. Do not attempt to undertake these steps yourself – arrange for a professional technician to investigate the problem. If any of the following errors occur, power the unit off and contact a professional technician immediately.
- Page 25 15.4 Error Codes With the exception of a mode conflict error, contact your supplier or service engineer if any of the error codes listed in the following table are displayed on the unit's display panel. If the mode conflict error is displayed and persists, contact your supplier or service engineer. These errors should only be investigated by a professional technician.
