Printed Matter No. 9839 0928 01
Valid from Serial No. B9600001
2017-08-21
LBB16 EP-024 (2400 r/min)
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
LBB16 EP024
8421010820
WARNING
Pistol-grip Drills
Product Instructions
Advertisement
Table of Contents
Related Manuals for Atlas Copco LBB16 EP024
Summary of Contents for Atlas Copco LBB16 EP024
- Page 1 LBB16 EP024 Printed Matter No. 9839 0928 01 Pistol-grip Drills Valid from Serial No. B9600001 Product Instructions 2017-08-21 LBB16 EP-024 (2400 r/min) 8421010820 WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
Preparations for service and maintenance .... 14 Service recommendations ........... 14 Preventive maintenance .......... 15 Lubrication instructions............ 15 Rust protection and cleaning ........ 15 Lubrication guide............ 15 Maintenance and lubrication ........ 15 © Atlas Copco Industrial Technique AB - 9839 0928 01... - Page 3 Assembling of spacer ring on the chuck ...... 18 Dismantling/Assembling of the chuck ...... 19 Troubleshooting................. 20 Troubleshooting.............. 20 Recycling .................. 21 Recycling instruction ............. 21 Recycling information ............ 21 © Atlas Copco Industrial Technique AB - 9839 0928 01...
-
Page 4: Product Information
• To avoid damage or destruction of tool parts, service the tool according to the recommended maintenance schedules and follow the correct instruc- tions. • Warranty repairs are only performed in Atlas Copco workshops or by Certi- fied Service Partners. Atlas Copco offers extended warranty and state of the art preventive mainte- nance through its ToolCover contracts. -
Page 5: Servaid
ServAid is available on DVD and on the website: https://servaid.atlascopco.com For further information contact your Atlas Copco sales representative or e-mail us at: servaid.support@se.atlascopco.com Website Log in to Atlas Copco: www.atlascopco.com. -
Page 6: Main Components And Functions
Technical data Ordering No 8421010820 Model LBB16 EP-024 Free speed 2400 r/min Chuck capacity - mm Power level 290 W 0.4 hp Stall torque in lb Weight 0.6 kg 1.2 lb © Atlas Copco Industrial Technique AB - 9839 0928 01... -
Page 7: Service Overview
Vibration standard ISO28927-5 Vibration value <2.5 m/s Height (H) Length (L) Service overview Maintenance and service instructions The service must only be done by authorized workshops or qualified ser- vice technicians. © Atlas Copco Industrial Technique AB - 9839 0928 01... -
Page 8: Service Recommendations
Make sure to perform a preventive maintenance every 6 months. If it is used in heavy duty conditions or not running properly, it should be removed from oper- ation for inspection more often. © Atlas Copco Industrial Technique AB - 9839 0928 01... -
Page 9: Installation
• For optimum performance and maximum product life we recommend the use of compressed air with a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration type air dryer. • Use a separate air filter which removes solid particles larger than 30 mi- crons and more than 90% of liquid water. -
Page 10: Installation Instructions
4. Connect the tool to the air supply. 5. Use the appropriate drilling speed for the application. 6. To start the tool, press the trigger. When lubrication is recommended - only use lubricants recommended by Atlas Copco. © Atlas Copco Industrial Technique AB - 9839 0928 01... -
Page 11: Operation
Adapt the torque setting to the operator's strength and posture and use a torque arm or reaction bar if the torque is too high. • Use dust extraction system or mouth protection mask in dusty environments. © Atlas Copco Industrial Technique AB - 9839 0928 01... -
Page 12: Operating Instructions
8. Start the tool by pressing the trigger. 9. Do not force the drill. If the drill slows down, change to a drill with more power, so that the drill bit can continue cutting smoothly. © Atlas Copco Industrial Technique AB - 9839 0928 01... - Page 13 10. If the drill gets caught in the material, release the trigger immediately, un- plug the drill and remove the bit from the material. When lubrication is recommended - only use lubricants recommended by Atlas Copco. © Atlas Copco Industrial Technique AB - 9839 0928 01...
-
Page 14: Service
If no detailed information about preventive maintenance is included, follow these general guidelines: • Clean appropriate parts accurately • Replace any defective or worn parts © Atlas Copco Industrial Technique AB - 9839 0928 01... -
Page 15: Preventive Maintenance
3. Assemble the motor and make sure that it is running free. Add two drops of oil through the air inlet and run the motor at idling speed for 5-10 sec- onds. © Atlas Copco Industrial Technique AB - 9839 0928 01... -
Page 16: Dismantling/Assembling Instructions
4080 0182 04 4080 0182 05 4080 0182 06 10.5 4080 0182 07 12.5 4080 0182 08 15.5 4080 0182 09 17.5 4080 0182 10 20.5 4080 0182 11 25.5 © Atlas Copco Industrial Technique AB - 9839 0928 01... - Page 17 Ø C 4080 0567 04 12.5 4080 0567 11 14.5 4080 0567 01 15.5 4080 0567 05 18.5 4080 0567 02 18.5 4080 0567 06 21.5 4080 0567 03 21.5 © Atlas Copco Industrial Technique AB - 9839 0928 01...
-
Page 18: Disassembly Of Trigger
4080 0567 09 31.5 15.5 4080 0567 10 34.5 18.5 Table 2: Dismantling tool Mandrel B E: Ball bearing Disassembly of trigger Assembly of motor Assembling of spacer ring on the chuck © Atlas Copco Industrial Technique AB - 9839 0928 01... -
Page 19: Dismantling/Assembling Of The Chuck
6. Assemble the chuck and tighten with a chuck key. Dismantling/Assembling of the chuck 1. Put a 15 mm open end spanner over the spacer ring. 2. Remove or assemble the chuck using a chuck key. © Atlas Copco Industrial Technique AB - 9839 0928 01... -
Page 20: Troubleshooting
Not enough grease in gear housing. Make sure that the amount of grease is correct. Damaged gear. Worn motor bearings. *) This service must only be carried out by authorized workshop or qualified service technician. © Atlas Copco Industrial Technique AB - 9839 0928 01... -
Page 21: Recycling
Valve Plastics, Other, POM Adapter and adjacent parts Metal, Steel *The rotor blades (vanes) in the tool contains PTFE, the normal health and safety recommendations concerning PTFE must be observed. © Atlas Copco Industrial Technique AB - 9839 0928 01... - Page 24 Original instructions Atlas Copco Industrial © Copyright 2017, Atlas Copco Industrial Technique AB. All rights reserved. Any Technique AB unauthorized use or copying of the contents or part thereof is prohibited. This SE-10523 STOCKHOLM applies in particular to trademarks, model denominations, part numbers and drawings.
