Summary of Contents for Atlas Copco LCD 1500
- Page 1 500, 1500 Safety and operating instructions Hydraulic core drill © 2015 Construction Tools EOOD | No. 3392 5189 01c | 2015-01-31 Original instructions...
-
Page 3: Table Of Contents
LCD 500, 1500 Contents Contents Introduction............... . 5 About the Safety and operating instructions. - Page 4 Contents LCD 500, 1500 EC Declaration of Conformity............18 EC Declaration of Conformity (EC Directive 2006/42/EC).
-
Page 5: Introduction
Safety and operating instructions Introduction Thank you for choosing a product from Atlas Copco. Since 1873, we have been committed to finding new and better ways of fulfilling our customers' needs. Through the years, we have developed innovative and ergonomic product designs that have helped customers improve and rationalize their daily work. -
Page 6: Safety Instructions
Safety and operating instructions LCD 500, 1500 Drugs, alcohol or medication Safety instructions WARNING Drugs, alcohol or medication To reduce the risk of serious injury or death to Drugs, alcohol or medication may impair your yourself or others, read and understand the Safety judgment and powers of concentration. - Page 7 LCD 500, 1500 Safety and operating instructions WARNING Unexpected movements WARNING Dust and fume hazard The inserted tool is exposed to heavy strains when Dusts and/or fumes generated or dispersed when the machine is used. The inserted tool may break using the machine may cause serious and permanent due to fatigue after a certain amount of use.
- Page 8 Safety and operating instructions LCD 500, 1500 Select, maintain and replace consumables/ ► WARNING Splinters hazard working tools/ other accessories as recommended Using the insertion tool as a hand struck tool can in the operating and safety instructions. Incorrect result in splinters hitting the operator and can cause selection or lack of maintenance of consumables/ personal injury.
- Page 9 LCD 500, 1500 Safety and operating instructions Participate in health surveillance or monitoring, ► WARNING Vibration hazards medical exams and training programs offered by Normal and proper use of the machine exposes the your employer and when required by law. operator to vibration.
-
Page 10: Maintenance, Precautions
Safety and operating instructions LCD 500, 1500 WARNING Involuntary start Maintenance, precautions Involuntary start of the machine may cause injury. Keep your hands away from the start and stop ► WARNING Machine modification device until you are ready to start the machine. Any machine modification may result in bodily injuries ►... -
Page 11: Overview
Design and function LCD 500 and LCD 1500 are sturdy and reliable core drills designed for working together with Atlas Copco power packs. The core drills are small and flexible machines with a high performance compared to the weight. -
Page 12: Data Plate
Safety and operating instructions LCD 500, 1500 Data plate Safety label xxxxx RPM label Maximum permitted hydraulic oil flow Machine type Maximum relief valve setting The warning symbol together with the book symbol means that the user must read the safety and operating instructions before the machine is used for the first time. -
Page 13: Hydraulic Oil
LCD 500, 1500 Safety and operating instructions cause overheating and cause foreign matter to enter Water flushing the hydraulic system. For diamond bit core drilling, water flushing is Hydraulic oil required. Mount the water swivel and water hose on the core drill as follows. In order to protect the environment, use of biologically degradable hydraulic oil is recommended. -
Page 14: Operation
"Technical data". ♦ During all breaks you must place the machine in Atlas Copco recommends using an LFD oil flow ♦ such a way that there is no risk for it to be divider, if the flow from the power source can unintentionally started. -
Page 15: Maintenance
LCD 500, 1500 Safety and operating instructions Maintenance Disposal Regular maintenance is a basic requirement for the A used machine must be treated and disposed of in continued safe and efficient use of the machine. such a way that the greatest possible portion of the Follow the maintenance instructions carefully. -
Page 16: Technical Data
Use a power source with higher cooling capacity or add an additional oil cooler in the return line Machine data LCD 500, LCD 1500 Weight without hoses and drill bit, kg (lb) 7.25 (15.9) Oil flow range, l.p.m. (US gal/min) -
Page 17: Noise And Vibration Data
LCD 500 (Ø 102 mm, 20 lpm) <70 3.10 0.81 LCD 500 (Ø 102 mm, 30 lpm) <70 3.00 0.82 LCD 1500 (Ø 62 mm, 20 lpm) <70 2.70 0.76 LCD 1500 (Ø 62 mm, 30 lpm) <70 3.40 0.83 Vibration declaration statement Vibration value A and uncertainty B determined according to EN ISO 20643. - Page 18 We, Construction Tools EOOD, hereby declare that the machines listed below conform to the provisions of EC Directive 2006/42/EC (Machinery Directive), and the harmonised standards mentioned below. Hydraulic core drill Pmax (bar) LCD 500 LCD 1500 Following harmonised standards were applied: ♦ EN ISO 11148-3:2010 Technical Documentation authorised representative:...
- Page 20 Any unauthorized use or copying of the contents or any part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers, and drawings. www.atlascopco.com...
