Unverferth ROLLING HARROW 1645 Manual page 91

Vertical-Fold Rolling Harrow 1645/1645D — Parts
Main Frame Components
Please visit www.unverferth.com/parts/ for the most current parts listing.
ITEM PART NUMBER
87970G
1
87970R
2 9003125
3 9003126
4 9003127
5 901576
6 901891
7 91605
8 95136
9 95605
10 97048
11 97961
76374G
12
76374R
13 93415
14 88361
15 9393-016
16 9390-110
17 9800
18 9500003B
19 9165
20 9230
21 9231
22 9247
23 9345
24 9349
25 9234
26 9162B
27 9391-035
28 75635B
29 93415
30 75637B
31 93415
32 9390-121
33 9801
34 9390-123
35 9390-130
36 85631
37 91144-165
38 73130B
(Continued on next page)
Main Frame Assembly =Green=
Main Frame Assembly =Red=
Fluorescent Strip 2 x 9 =Red/Orange=
Reflector 2 x 9 =Red=
Reflector 2 x 9 =Amber=
Decal, Unverferth
Decal, DANGER (Electrocution...)
Decal, FEMA
Decal, WARNING (Folding or Unfolding Wings...)
Decal, WARNING (Falling Equipment...)
Decal, WARNING (Pinch Point...)
Decal, WARNING (Read & Understand)
Axle Weldment
Axle
Grease Zerk
Spindle 2" Dia. x 12 w/3/4-16UNF Threaded End
Slotted Nut 3/4-16UNF
Capscrew 1/2-13UNC x 3 3/4 (Grade 5)
Locknut 1/2-13UNC
Hub 6 Bolt Assembly Complete (Includes Items 19 through 24)
Bearing Cone 1.25 Bore (LM67048)
Seal
Wheel Bolt 9/16-18UNF x 1 1/8 (Grade 5)
Bearing Cone 1.62 Bore (LM501349)
Bearing Cup (LM67010)
Bearing Cup (LM501310)
Flat Washer 13/16 ID
Hub Cap =Black=
Cotter Pin 5/32" Dia. x 1 1/2
Bearing Housing Right-Hand with Grease Zerk
Grease Zerk
Bearing Housing Left-Hand with Grease Zerk
Grease Zerk
Capscrew 5/8-11UNC x 1 1/4
Locknut 5/8-11UNC
Capscrew 5/8-11UNC x 1 3/4
Capscrew 5/8-11UNC x 3 1/2
Pin 1" Dia. x 4
Spiral Pin 1/4" Dia. x 1 7/8
Stop/Transport Lock
DESCRIPTION QTY
1
2
2
4
2
2
1
2
1
2
1
1
4
4
4
4
4
4
1
1
6
1
1
1
1
4
4
1
2
1
2
8
38
6
4
4
8
2
5-7
