Description

Introduction

In this document, Facility Management System (FMS) is a generic term,
which refers to the Metasys® Network, Companion™, and Facilitator™
supervisory systems. The specific system names are used when referring to
system-specific applications.
Table 1: Related Documents
Document Title
Air Handling Unit (AHU) Controller Technical
Bulletin
ASC and N2 Bus Troubleshooting Technical
Bulletin
Controller Access Technical Bulletin
N2 Communications Bus Technical Bulletin
Universal Packaging Module Technical Bulletin
Zone Terminal Technical Bulletin
The Unitary (UNT) Controller is an electronic device for digital control of
packaged air handling units, unit ventilators, fan coils, heat pumps, and
other terminal units serving a single zone or room. It also can be
configured as a generic Input/Output (I/O) device for basic point
monitoring applications when used within a Metasys Network.
You can easily configure point inputs and outputs, and software features to
control a wide variety of Heating, Ventilation, and Air Conditioning
(HVAC) equipment applications. The UNT may be used as a standalone
controller or connected to a FMS.
When connected to a FMS, the UNT provides all point control information
to the rest of the network. The devices communicate through an N2 Bus.
For a smaller facility, the UNT can function as a standalone controller.
Figure 1 illustrates the UNT.
Code Number
LIT-6363010
LIT-1628315
LIT-6363003
LIT-1628310
LIT-6364013
LIT-1628413
LIT-636018
LIT-6281120
LIT-1628120
LIT-6363070
LIT-1628370
LIT-6363014
LIT-1628330
UNT Controller—Unitary (UNT) Controller 5
FAN
636.3
1628.2
636.3
1628.2
636.4 / 637.5
1628.4 / 1637.5
636
628.1
1628.1
636.3
1628.2
636.3
1628.2
