Page 2
FC8768/01 DISASSEMBLY- AND RE-ASSEMBLY ADVISE • To remove the Bucket, unlock the top handle by pushing • The foam in the Inlet filter assy can be cleaned. the button on the lid of Bucket (see picture). By pulling the plastic ring the foam filter can be removed without touching the dirt on the filter (see picture).
Page 3
FC8768/01 DISASSEMBLY- AND RE-ASSEMBLY ADVISE • To reach the inner parts for repair, Upper housing (18) • When lifting at position push the button a little has to be removed. First the On/Off button (17) and towards the front side.
Page 4
FC8768/01 DISASSEMBLY- AND RE-ASSEMBLY ADVISE • After removing the two buttons remove the 4 screws • After removing the Upperhousing, Hose connection (10) at the back and the 5 screws at the front of the and Bucket inlet sealing (13) are accessible. To replace Upperhousing (see pictures).
Page 11
FC8768/01 Version history 13/12 Version 1.1 : FC8768/01 initial release. 14/07 Version 1.2 : On page 1 at Technical Information, changed Hepa 12 Super Clean Air into EPA 10 washable fi lter. In Parts List at Pos. 6, changed 4322 004 93711 HEPA 12 Filter Cougar into 4322 004 93792 EPA 10 Filter.
