Rack Adapter Panel
GRA-410
Assembly Manual
GW INSTEK PART NO. 82RA-41000MA1
This assembly manual contains proprietary information, which is protected by copyrights. All rights are
reserved. No part of this manual may be photocopied, reproduced or translated to another language
without prior written consent of Good Will company.
The information in this manual was correct at the time of printing. However, Good Will continues to
improve products and reserves the rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.
ISO-9001 CERTIFIED MANUFACTURER
Advertisement
Related Manuals for GW Instek GRA-410
Summary of Contents for GW Instek GRA-410
- Page 1 Rack Adapter Panel GRA-410 Assembly Manual GW INSTEK PART NO. 82RA-41000MA1 This assembly manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company.
- Page 2 The GRA-410 is supports both the EIA (GRA-410-E) and JIS (GRA-410-J) standards for use with standard sized rack units. Incorporating a strong frame and robust design, the GRA-410 can fit up to 6 Type I, 3 Type II or 2 Type III PSW power supplies.
- Page 3 GRA-410 Assembly Manual 62RA-410HP101 Middle Bracket 592B-W3008NS1 PMS-W-3*8 62RA-410HPA01 EIA BRACKET 3U 593B-03008NS1 FMS-3*8 593B-03005NS1 FMS-3*5 62RA-410HP501 Right Bracket 62RA-410HP401 Left Bracket 62RA-410HP301 Rear Bracket 62RA-410HP901 Rack HP 594B-W3008NS1 BMS-W-3*8 GRA-410-J Item Part NO. Description GRA-410-J 59CA-04017NS1 Rack Screw Assembly...
- Page 4 Assembly Assembly Initial setup 1. Remove the handle (from) the power supply units. Remove the handle cover. Remove the screws securing the handle to the case. Remove the handle. → 2. Remove the feet from the underside of the PSW. Instrument 1.
- Page 5 GRA-410 Assembly Manual 2. Attach the Front Bracket to the Middle Bracket with the rack screws. Front Bracket Rack screw 3. Secure the Rack holding plates (X6) to the groove on the Rear Bracket and to the instrument(s). Rack holding...
- Page 6 Specification 2. Secure the panels with the PMS-W-3*8 screws. Use the SR-3S PIN GOOD pins to hold two adjacent brackets together. Front Bracket screws Specification Load Capacity Max 20kg Rack Weight GRA-410-E:1.0kg GRA-410-E: 1.2kg Rack installation Diagram...
