Rack Adapter Panel
GRA-439
Assembly Manual
GW INSTEK PART NO. 82RA-43900MA1
This assembly manual contains proprietary information, which is protected by copyrights. All rights are
reserved. No part of this manual may be photocopied, reproduced or translated to another language
without prior written consent of Good Will company.
The information in this manual was correct at the time of printing. However, Good Will continues to
improve products and reserves the rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.
ISO-9001 CERTIFIED MANUFACTURER
Advertisement
Table of Contents
Related Manuals for GW Instek GRA-439
Summary of Contents for GW Instek GRA-439
- Page 1 Rack Adapter Panel GRA-439 Assembly Manual GW INSTEK PART NO. 82RA-43900MA1 This assembly manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company.
- Page 2 GRA-439 Assembly Manual GRA-439 The GRA-439 rack mount is suited for the ASR-2000(R) AC/DC Power Supplies. The GRA-439 supports both the EIA (GRA-439-E) and JIS (GRA-439-J) standards for use with standard sized rack units. Rack Mount Adapter Component List and Assembly...
- Page 3 593B-03008NS1 SCREW FMS ,3*8*0.5m/m ,ISO ,N ,RoHS 4 593B-03005NS1 SCREW FMS ,+ ,3*5 ,ISO ,N ,RoHS 62RA-439HP201 CA GRA-439 RIGHT BRACKET ,RoHS 599B-03006NS1 SCREW IMS ,+ ,3*6 ,ISO ,N ,RoHS 594B-W3008NS1 SCREW BMS ,+ ,3*8*0.5P ,ISO ,N (WASHER P.S) ,RoHS...
- Page 4 Remove the handle. → 2. Remove the feet from the underside of the power supply units. Instrument 1. Insert ASR-2000(R) into the GRA-439 rack mount insertion horizontally and ensure the catch links up with the groove. ¾ ÷ ¾ ¹...
- Page 5 GRA-439 Assembly Manual 2. Attach the Front Bracket to the Middle Bracket with fastening the rack screws. Front Bracket Front Bracket ¾ ÷ ¾ ¹ ASR-2000(R) Rack Screw Rack Screw 3. Secure the Rack Holding Plates (Rack HP) to the groove on the Rear Bracket and to the ASR-2000(R).
- Page 6 Specification 2. Secure the panel with the PMS-W-3*8 screws. Blank Panel BLANK PANEL Specification Load Capacity Max 20kg Rack Weight GRA-439-E:1.0kg GRA-439-J: 1.2kg Rack installation Diagram Please note the minimum width that is needed to be supported on the L-brackets.
