Rack Adapter Panel
GRA-428
Assembly Manual
GW INSTEK PART NO. 82RA-42800M01
This assembly manual contains proprietary information, which is protected by copyrights. All rights are
reserved. No part of this manual may be photocopied, reproduced or translated to another language
without prior written consent of Good Will company.
The information in this manual was correct at the time of printing. However, Good Will continues to
improve products and reserves the rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.
ISO-9001 CERTIFIED MANUFACTURER
Advertisement
Table of Contents
Related Manuals for GW Instek GRA-428
Summary of Contents for GW Instek GRA-428
- Page 1 Rack Adapter Panel GRA-428 Assembly Manual GW INSTEK PART NO. 82RA-42800M01 This assembly manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company.
- Page 2 Overview GRA-428 Overview The GRA-428 3U 19”rack mount is suited for the PSP-405, PSP-603 and PSP-2010 Programmable Switching DC Power Supply. The GRA-428 is designed for use with standard sized rack units. Rack Mount Adapter Component List and Assembly Description Please check to make sure all the components of the GRA-428 rack mount kit are provided.
- Page 3 GRA-428 Assembly Manual Assembly Description Assembly of the GRA-428 simply involves securing the PSP-405, PSP-603 or PSP-2010 units into the bottom chassis. Steps 1. Remove both side screws of the PSP-405, PSP-603 or PSP-2010 units. 2. Attach the two Brackets(5) to the PSP-405, PSP-603 or PSP-2010 units, using the BMS-W-3*6(6) screws.
- Page 4 Appearance Appearance GRA-428...
