Rack Adapter Panel
GRA-420
Assembly Manual
GW INSTEK PART NO. 82RA-42000M01
This assembly manual contains proprietary information, which is protected by copyrights. All rights are
reserved. No part of this manual may be photocopied, reproduced or translated to another language
without prior written consent of Good Will company.
The information in this manual was correct at the time of printing. However, Good Will continues to
improve products and reserves the rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.
ISO-9001 CERTIFIED MANUFACTURER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRA-420 and is the answer not in the manual?

Questions and answers

Related Manuals for GW Instek GRA-420

Summary of Contents for GW Instek GRA-420

  • Page 1 Rack Adapter Panel GRA-420 Assembly Manual GW INSTEK PART NO. 82RA-42000M01 This assembly manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company.
  • Page 2 Overview GRA-420 Overview The GRA-420 rack mount is suited for the GDS-2000A. The GRA-420 is designed for use with standard sized rack units. Rack Mount Adapter Component List and Assembly Description Please check to make sure all the components of the GRA-420 rack mount kit are provided.
  • Page 3 GRA-420 Assembly Manual Assembly Initial setup 1. Connect the handle (62RA-411HD101) to the front plate (62RA-420FP101) and the bottom cover(62RA-420LO101) with “594B-06012ZS1” screws. 2. Connect the top(57RG-20B03701) and bottom(57RG-20B03801) foam squares to the left(62RA-420HP101) and right(62RA-420HP201) fasteners.
  • Page 4 Assembly Instrument 1. Place the scope onto the floor of the rack, against the insertion window. 2. Insert the left and right fasteners into the two holes in the bottom cover.
  • Page 5 GRA-420 Assembly Manual 3. Screw the left and right fasteners to the rack with the embossed nuts(6010-L00040S1). Appearance GRA-420...
