Rack Adapter Panel
GRA-451
Assembly Manual
GW INSTEK PART NO. 82RA-45100MA1
This assembly manual contains proprietary information, which is protected by copyrights. All rights are
reserved. No part of this manual may be photocopied, reproduced or translated to another language
without prior written consent of Good Will company.
The information in this manual was correct at the time of printing. However, Good Will continues to
improve products and reserves the rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.
ISO-9001 CERTIFIED MANUFACTURER
Advertisement
Table of Contents
Related Manuals for GW Instek GRA-451
Summary of Contents for GW Instek GRA-451
- Page 1 Rack Adapter Panel GRA-451 Assembly Manual GW INSTEK PART NO. 82RA-45100MA1 This assembly manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company.
- Page 2 GRA-451 Assembly Manual GRA-451 The GRA-451 rack mount is suited for the ASR-6000 AC/DC Power Supplies. The GRA-451 supports both the EIA and JIS standards for use with standard sized rack units. Rack Mount Adapter Component List and Assembly Description Please check to make sure all the components of the GRA-451 rack mount kit are provided.
- Page 3 GRA-451 Assembly Manual Item Part NO. Description GRA-451-JIS 62EL-200HD101 HANDLE Assembly 62RA-451HP401 J RIGHT BRACKET 62RA-451HP301 J LEFT BRACKET 62RA-442HP501 J MIDDLE BRACKET 594B-W4012NS1 BMS-W-4*12 594B-W3008NS1 BMS-W-3*8 593B-06010NS1 FMS-6*10...
- Page 4 GRA-451 Assembly Manual Assembly Initial setup 1. Remove the parts described below from the underside of the power supply units. Foot * 6 M4*10 screw * 6 Installation 1. Attach the left and right brackets to both sides of power process supply units.
- Page 5 GRA-451 Assembly Manual Specification Rack installation Diagram (EIA) Rack installation Diagram (JIS) It is suggested to utilize L-shape angle bars to provide support from the bottom of unit while assembling the rack mount.
