GW Instek GRA-429 Assembly Manual

Rack adapter panel

Rack Adapter Panel

GRA-429

Assembly Manual

GW INSTEK PART NO. 82RA-42900M01

This assembly manual contains proprietary information, which is protected by copyrights. All rights are

reserved. No part of this manual may be photocopied, reproduced or translated to another language

without prior written consent of Good Will company.

The information in this manual was correct at the time of printing. However, Good Will continues to

improve products and reserves the rights to change specification, equipment, and maintenance

procedures at any time without notice.

Good Will Instrument Co., Ltd.

No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.

ISO-9001 CERTIFIED MANUFACTURER

Table of Contents

Need help?

Do you have a question about the GRA-429 and is the answer not in the manual?

Page 1 Rack Adapter Panel GRA-429 Assembly Manual GW INSTEK PART NO. 82RA-42900M01 This assembly manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company.
Page 2 GRA-429 Assembly Manual GRA-429 The GRA-429 rack mount is suited for use with the APS-7200 AC power sources. Only one power source can be used with the GRA-429 rack adapter. The GRA-429 will accommodate a 7U-sized rack. Rack Mount Adapter Component List...
Page 3 GRA-429 Assembly Manual Assembly Initial setup 1. Remove the four wheel casters from the APS-7200 as shown in the below diagram. 2. Remove the six screws located on each side panel of the APS-7200 as shown in the below diagram.
Page 4 Specification 3. Screw the left bracket (62RA-429HP101) to the left side panels of the APS-7200 and right bracket (62RA-429HP201) to the right side panel of the APS-7200 using the six (594B-W4012NS1) screws as shown in the below diagram.
Page 5 GRA-429 Assembly Manual Specification Rack Dimensions APS-7200...
