AirKing 4DA35B/9102B Operating Instructions & Parts Manual

Oscillating fans

OPERATING INSTRUCTIONS & PARTS MANUAL

OSCILLATING FANS

12" (30,5 cm) MODEL 4DA35B/9102B

16" (40,6 cm) MODEL 4DA36B/9106B

It is not intended to be used in commercial, industrial or agricultural settings.

READ AND SAVE THESE INSTRUCTIONS

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE,

INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED.

PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY

INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD

RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE!

Rev. M 4/17

2084067

Table of Contents

Need help?

Do you have a question about the 4DA35B/9102B and is the answer not in the manual?

Page 1 OPERATING INSTRUCTIONS & PARTS MANUAL OSCILLATING FANS 12" (30,5 cm) MODEL 4DA35B/9102B 16" (40,6 cm) MODEL 4DA36B/9106B It is not intended to be used in commercial, industrial or agricultural settings. READ AND SAVE THESE INSTRUCTIONS READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED.
Page 2 BE CERTAIN that the power source for the Fan is 120V AC. DO NOT plug the Fan into 240V or other power source. The Blue Plug™ on your AirKing fan is a safety feature. It contains a non-replaceable safety device (fuse) that should not be removed or tampered with.
Page 3 MODEL 4DA35B/9102B 4DA36B/9106B DESCRIPTION OPERATION VARIABLE OSCILLATION: Pull oscillation knob on the rear of The Air King 12" (30,5 cm) and 16" (40,6 cm) Oscillating Fans fea- ® the motor up. Turn fan head to left, right, or straight ahead. Push ture whisper quiet operation with a 3 paddle blade.
Page 4 MODEL 4DA35B/9102B 4DA36B/9106B REPLACEMENT PART LIST PART NO. FOR MODEL DESCRIPTION 4DA35B/9102B 4DA36B/9106B Motor 02035053 02035052 Rotary Switch 2055087 2055087 Crimp Connect 7091854 7091854 Elevation Spring 02090586 Ratchet Plate 02010162B 02010162B Neck Bolt 02090521 02090521 5/16-24 Hex Nut 02090033 02090033...
