Video Matrix Platform (M60)
User's Manual
V2.1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M60 and is the answer not in the manual?

Questions and answers

Related Manuals for Dahua M60

Summary of Contents for Dahua M60

  • Page 1 Video Matrix Platform (M60) User’s Manual V2.1.0...

  • Page 2: Foreword

    Foreword General This manual introduces function, installation, use, operation and maintenance of Video Matrix Platform. Model Video Matrix Platform-12U, Video Matrix Platform-7U Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a high potential hazard which, if not avoided, will result DANGER in death or serious injury.
  • Page 3 About the Manual The Manual is for reference only. If there is inconsistency between the manual and the  actual product, the actual product shall prevail. We are not liable for any loss caused by the operations that do not comply with the manual. ...

  • Page 4: Important Safeguards And Warnings

    Important Safeguards and Warnings The following description is the correct application method of the device. Please read the manual carefully before use, in order to prevent danger and property loss. Strictly conform to the manual during application and keep it properly after reading. Operating Requirement Do not place or install the Device in a place exposed to sunlight or near the heat source.

  • Page 5: Table Of Contents

    Table of Contents Foreword ..............................I Important Safeguards and Warnings ..................... III 1 Overview ..............................1 1.1 Introduction ............................ 1 1.2 Functional Feature ......................... 1 1.2.1 Structural Feature ........................ 2 1.2.2 Hardware Feature ....................... 2 1.2.3 Software Feature ......................... 2 1.3 Introduction to Cards in System ....................
  • Page 6 3.2.3 System Setting ........................28 3.2.4 System Info ........................32 3.2.5 Shutdown .......................... 35 4 Web Operation ............................. 37 4.1 Network Connection ........................37 4.2 System Login ..........................37 4.3 Screen ............................38 4.3.1 Adding Video Wall ......................40 4.3.2 Window Configuration ....................... 40 4.3.3 Signal Configuration ......................

  • Page 7: Overview

    Overview Introduction Based on Advanced Telecommunications Computing Architecture (ATCA), video matrix platform is designed as a modern telecommunication-level device which supersedes DVR, decoder, analog matrix, and video wall controller. It is compatible with past and current network monitoring environments. Main Application: ...

  • Page 8: Structural Feature

     This platform integrates video signal encoding/decoding, centralized data storage, online real-time preview and various networks, plan, log, user right management, device maintenance functions and etc., and allows HD video command/dispatch and video conference system. 1.2.1 Structural Feature 19-inch 7U and 12U standard rack case for universal uses. ...
  • Page 9  Support cascading among video matrix platforms, extending the video processing and networking abilities of video matrix platforms, and thus achieving the integration of multi-level video surveillance system.  Support TCP/IP protocol stack, including TCP, UDP, RTP, RTSP, DHCP, DNS, DDNS, NTP, SADP protocols.

  • Page 10: Introduction To Cards In System

    Connection diagram Introduction to Cards in System Table 1-1 System cards Functional Name Model Description Note Module  host supports 10 function cards. M60-12U One MBC0050 main  control panel. built-in power  Platform Video matrix adaptors (redundant). Standard Host...
  • Page 11 Functional Name Model Description Note Module 16-ch HD-SDI video  HD-SDI video input (BNC). VEC1604HS encoding card One DVI audio input Optional  (16-ch) port (16-ch). 2-ch RS–485 port.   8-ch DVI video input. Optional HD DVI video  One VGA audio input (support VEC0804HD...

  • Page 12: Host System

    Host System 1.4.1 12U Host Case Video Matrix Platform with 19-inch 12U structure host case includes function card slot, power port and intelligent temperature-controlling fan. See Figure 1-4. Figure 1-4 Appearance of 12U Host Case Indicator lights on the front panel display device working status. See Table 1-2. Table 1-2 Function introduction ON/OFF button.

  • Page 13: Host Case

    Power module indicator light.  Red: Power module is abnormal. Off: Power module is normal.  Fan indicator light. Red: Fan is abnormal.  Off: Fan is normal.  Hardware structure is as below:  Air intake of host has a dust filter behind the plastic shell. Three groups of intelligent temperature-controlling fans allow hot swap.

  • Page 14: Main Control Panel

    Alarm indicator light.  Red: Fault occurs. Off: Device is normal.  Temperature indicator light. Red: Board card temperature is too high.  Off: Board card temperature is normal.  Power module indicator light.  Red: Power module is abnormal. ...

  • Page 15: Function Card

    Table 1-4 Introduction to ports of main control panel Port Quantity Function Reset Button Restore to default settings. Power Indicator of Display power status of main control panel Main Control Panel Disk Reading-writing Display disk reading-writing status. Status Indicator Working Diaplay CPU working status.

  • Page 16: Vec3204Fb Sd A/V Encoding Card

    1.5.1 VEC3204FB SD A/V Encoding Card Figure 1-8 VEC3204FB SD A/V encoding card 1.5.1.1 Main Features and Functions Features 32-ch BNC video port input (1.0 Vp-p, 75 ohms).   32-ch audio input.  2-ch RS–485 port.  One power button. ...

  • Page 17: Vec1604Hs 16-Ch Hd Sdi Encoding Card

    1.5.2 VEC1604HS 16-CH HD SDI Encoding Card Figure 1-9 VEC1604HS 16-ch HD SDI encoding card 1.5.2.1 Main Features and Functions Features 16-ch HD-SDI video input port.   16-ch audio input.  2-ch RS–485 port.  16 1080P, 30 fps. ...

  • Page 18: Vec0804Hd Hd Dvi Encoding Card

    1.5.3 VEC0804HD HD DVI Encoding Card Figure 1-10 VEC0804HD HD DVI encoding card 1.5.3.1 Main Features and Functions Features 8-ch DVI-I video port input, supporting DVI, VGA and HDMI input.   8-ch audio input.  2-ch RS–485 port.  One power button.

  • Page 19: Vec1604Hc 16-Ch Hdcvi Encoding Card

    1.5.4 VEC1604HC 16-CH HDCVI Encoding Card Figure 1-11 VEC1604HC 16-ch HDCVI encoding card 1.5.4.1 Main Features and Functions Features 16-ch BNC video input port. HDCVI signal input.   16-ch audio input, support external and built-in.  2-ch RS–485 port. ...

  • Page 20: Vec0804Us 8-Ch 3G-Sdi Encoding Card

    1.5.5 VEC0804US 8-CH 3G-SDI Encoding Card Figure 1-12 VEC0804US 8-ch 3G-SDI encoding card 1.5.5.1 Main Features and Functions Features 8-ch 3G-SDI video input port.   8-ch audio input.  2-ch RS–485 port.  Eight 1080P, 60 fps.  One power button. ...

  • Page 21: Vec0805Uh 8-Ch Uhd Encoding Card

    1.5.6.1 Main Features and Functions Features 16-ch HDMI video input port, and 4-ch VGA video input port.  16-ch HDMI built-in audio input, and 16-ch external audio input port.  1-ch RS–485 port.  8-ch 4K (4096x2160@24 or 3840x2160@30) and 12-ch 1080P (1920x1080@60). ...

  • Page 22: Vdc0905H 9-Ch Hd Hdmi Decoding Card

    Functions  H.264/H.265 video compression technology.  PCM audio compression standard. Video encoding parameter is adjustable in each channel, including resolution, frame rate,  bit stream rate, image quality and etc. Each channel supports schedule and event compression parameters.  Support composite and video stream encoding.

  • Page 23: Vdc1505H 15-Ch Hd Hdmi Decoding Card

    1.5.9.1 Main Features  12-ch HDMI digital video port output.  12-ch audio output.  2-ch RS–485 port. 4-ch alarm input port.  2-ch alarm output port.  One power switch.  10 indicators (power, PCIE indicator, decoding chip operating indicator). ...
  • Page 24 1.5.11.1 Main Features  18-ch HDMI digital video port output.  18-ch audio output.  2-ch RS–485 port. 4-ch alarm input port.  2-ch alarm output port.  One power switch.  14 indicators (power, PCIE indicator, decoding chip operating indicator). ...

  • Page 25: Device Installation

    Device Installation Inspection Steps When you receive Video Matrix Platform, please inspect it according to the following steps. Step 1 Inspect whether there are obvious damages on its appearance. The material of product package should be able to protect the product from most impacts during transportation.

  • Page 26: Installation Steps

    Ensure well ventilation. It is suggested that its installation position shall be more than  50cm above the ground. Power Supply Requirement Rated voltage range: AC 100V–AC 120V, AC 200V–AC 240V, 50 Hz/60 Hz. Anti-interference Requirement  On-site power supply system shall take effective anti-interference measures. ...
  • Page 27 Before you insert board card, please remove the black port sheath first. Figure 2-2 Remove sheath Step 3 Insert interface board and front panel of main control panel into "M" slot of the chassis, and then tighten screws. See Figure 2-3. Figure 2-3 Install board card Insert the interface board, tighten the set screws, and then insert front panel.
  • Page 28 Figure 2-4 Connect the monitor of local interface Step 6 Ground terminal of Video Matrix Platform must be properly grounded. See Figure 2-5. To guarantee personal safety and device safety, Video Matrix Platform and those devices (such as video wall and PC) that are connected the platform with cables shall be grounded.
  • Page 29 Figure 2-5 Grounding At present, power supply of most devices can be grounded directly. In this case, their grounding terminals don’t require grounding treatment. Step 7 Connect network cable, VGA cable and other cables. Step 8 Plug in and press ON/OFF button to boot the device. See Figure 2-6. Figure 2-6 Boot-up Device Installation 23...

  • Page 30: Boot-Up/Shutdown

    2.3.3 Boot-up/shutdown 2.3.3.1 Boot-up Plug in power cable, and press power switch on front panel. Power indicator turns on and device boots up, followed by 90s booting interface. The time depends on quantity of inserted board cards. Please pay attention to the following points during booting: ...

  • Page 31: Local Interface Configuration

    Local Interface Configuration Before you operate in local interface, you must connect monitor and other control devices (i.e. mouse, keyboard) to the device. Basic Operation of Software Interface 3.1.1 Entering System Menu Step 1 Turn on the device. The Device Initialization interface is displayed. See Figure 3-1. Figure 3-1 Device initialization Step 2...

  • Page 32: Main Interface

    Figure 3-2 System login Step 5 Input password, click OK to log in the system. Password security measure: In case that password is wrong for 5 times within every 30 minutes, the account will be locked. 3.1.2 Main Interface After normal login, the main interface is displayed. See Figure 3-3. Local Interface Configuration 26...

  • Page 33: Menu Introduction

    Figure 3-3 Main interface 3.1.3 Menu Introduction After login, right-click the main interface. The system pops up functional menu. See Figure 3-4 and Table 3-1. Figure 3-4 Functional menu Table 3-1 Functional description Name Description Display main menu, including system setting, system info and Main menu shutdown.

  • Page 34: Menu Navigation

    The check box is selected when it is filled with  or ticked, and it is not selected when it is  not filled. This note applies to the whole document. Figure 3-5 Main menu 3.2.2 Menu Navigation Table 3-2 Menu navigation Main Sub menu Description...
  • Page 35 Figure 3-6 System setting System setting shall be carried out by authorized users only. 3.2.3.1 General You can configure basic information of the device, such as device information, system time, and date format. Step 1 In the main menu, select System Setting > General. The General interface is displayed.
  • Page 36 Figure 3-7 General Step 2 Configure parameters. See Table 3-3. System time cannot be changed arbitrarily, or you cannot search records. System time can only be changed when it is not recording time according to hard drive information, or when the recording is stopped. Table 3-3 General parameters description Parameter Description...
  • Page 37 3.2.3.2 Network Configure device network parameters, so that device can communicate with devices in the network. Step 1 In the main menu, select System Setting > Network. The Network interface is displayed. See Figure 3-8. Figure 3-8 Network Step 2 Configure parameters.

  • Page 38: System Info

    Parameter Description Select the DHCP box, the system automatically obtains an IP address. When the DHCP function is enabled, the IP address, gateway, and subnet mask cannot be set manually. If DHCP is effective, the obtained information will be displayed ...
  • Page 39 Figure 3-9 System info 3.2.4.1 Version You can view the version details such as system version, build date, web version and serial number. 3.2.4.2 Online Users You can view online users that visit the video matrix platform remotely. In the main menu, select System Info > Online users. The Online users interface is displayed.
  • Page 40 Figure 3-10 Online users 3.2.4.3 Status You can view fan speed, card, temperature and source information, device time, net percentage, CPU percentage and memory percentage. In the main menu, select System Info > Status. The Status interface is displayed. See Figure 3-11 and Table 3-5. Local Interface Configuration 34...

  • Page 41: Shutdown

    Figure 3-11 Status Table 3-5 System status description Parameter Description Fan Speed Display the speed of two fans. Display information about cards in the slots, including card type, Card Information encoding or decoding card. Also, display present operating status, including data exchange and online status. Temperature Information Display present temperature and status of cards.
  • Page 42 Figure 3-12 Shutdown Logout menu user: Exit the menu, and you need to input password to enter the menu  again. Shutdown: Exit the system, and turn off power supply.  Restart system: Exit the system, and restart the system. ...

  • Page 43: Web Operation

    Web Operation Network Connection Step 1 Connect the video matrix platform and the PC with network. Step 2 Set the IP address, subnet mask and gateway of PC and video matrix platform respectively. For network setup of video matrix platform, refer to “4.5.2 Network.” Step 3 If there is no router in the network, distribute IP address in the same network ...

  • Page 44: Screen

    The login interface is displayed. See Figure 4-2. Figure 4-2 Login Step 4 Enter username and password, and then click Login. See Figure 4-3. Figure 4-3 Operation interface Step 5 View the points for attention and highlights on the page. ...
  • Page 45 Figure 4-4 Screen Table 4-1 Screen function description Name Description Video wall After you add a video wall, you can select the video wall in the selection area drop-down list of Video Wall. See "4.3.1 Adding Video Wall." Window Add window, adjust window, put the window at the bottom and configuration turn off the signal.

  • Page 46: Adding Video Wall

    4.3.1 Adding Video Wall You need to add video wall when you log in for the first time. See Figure 4-5. Figure 4-5 Adding video wall Click in the center of interface to enter Video Wall Setup interface. See "4.5.5.1 Video Wall Setup."...
  • Page 47  Select a window, press and move the left mouse button. The selected window will be moved to the required position.  Select a window, drag any direction control point to change the dimension of the selected window.  Select a window, right-click and select Bottom. The selected window will be at the bottom of other windows.

  • Page 48: Signal Configuration

    Precondition Manual setting window wide and height has been enabled. See “4.5.5.3.2 Global Setup.” Operation Steps Step 1 Double click the window. The Window Information interface is displayed. See Figure 4-8. Figure 4-8 Window information Step 2 Configure window position and window size. Step 3 Click Apply.
  • Page 49 4.3.3.3 Signal on Wall Output a signal to a window on the video wall, and you can view video of the signal on the screen. Step 1 Select a window on the video wall, or press and hold left mouse button to select an area on the video wall.

  • Page 50: Video Wall Management

    4.3.4 Video Wall Management You can manage the video wall, including scheme management, auto-align, window split, refresh video wall, clear screen, screen management, lock video wall, eagle eye and senior function. 4.3.4.1 Scheme Management You can manage schemes and configure switch timer. 4.3.4.1.1 Video Scheme Save video wall layout as a video scheme, configure multiple video schemes to be displayed on the screen in turn, and thus manage them.
  • Page 51 Double-click Control ID and scheme name, and you can change them. Figure 4-13 Set tour sequence. Step 6 Click Start. Scheme tour starts, and tour information is displayed at the bottom right corner of the interface. See Figure 4-14. Figure 4-14 Tour information ...
  • Page 52 Figure 4-15 Combined plan Step 2 Click The Scheme Management interface is displayed. See Figure 4-16. Figure 4-16 Scheme Management Step 3 Select video scheme and collection scheme you want. Step 4 Click OK to save the combined plan. See Figure 4-17. Figure 4-17 Save combined plan For other configurations, see “4.3.4.1.1 Video Scheme.”...
  • Page 53 Figure 4-18 Switch timer Step 2 Select Type, Scheme and Week, and then set switch time.  Tick the check box, and the time point will take effect. Two scheme time periods shall not be the same.  Step 3 Click OK.
  • Page 54 4.3.4.3 Window Split Select block or window, and split according to split plan of the system or you can enter split number manually. 4.3.4.3.1 Block Division During block division, the system clears previous block window, and divides the block according to the selected split.
  • Page 55 Figure 4-22 Block division display 4.3.4.3.2 Window Split Window split is to split the selected windows freely. Previous signal remains in the first window after splitting. Step 1 Select a signal window. It is suggested that tour window should not be selected for window split. Step 2 Select Window Split >...
  • Page 56 Figure 4-24 Window split display 4.3.4.4 Refresh Video Wall Click to refresh channel preview and layout information of current video wall. 4.3.4.5 Clear Screen Click to clear screen. 4.3.4.6 Screen Management You can manage the screen, including controlling screen power, controlling power switch and adjusting screen parameters.
  • Page 57 Figure 4-25 Screen management Step 1 Select a block from the drop-down list of Block. Step 2 In the block, select one or more screens, and then click ON or OFF to turn on or turn off the screen. 4.3.4.6.2 Power Switch According to the requirement, connect the video matrix platform with serial port cable of LED screen, in order to control the power of LED screen.
  • Page 58 4.3.4.6.3 Adjust Screen You can configure brightness, color temperature and other parameters of LED corresponding to output signal, and adjust screen display. If manufacturer protocol is DH-LED-N, the Adjust Screen tab is displayed in Screen Management interface, so you can adjust LED parameters. Select the Adjust Screen tab.
  • Page 59 Figure 4-28 Eagle eye Adjust area box size in the eagle eye map with mouse or scroll wheel, to change main window display area size. Drag area box position in the eagle eye map, to change main window display area. 4.3.4.9 Senior Function You can configure senior functions, including PTZ control, virtual LED, background, decoding strategy and show screen ID.
  • Page 60 Parameter Description Step Control PTZ turning speed. 1–8 steps can be set. Zoom Click to adjust zoom. Focus Click to adjust definition. Iris Click to adjust brightness. Click to open PTZ menu of preview interface. Then,  PTZ menu select different functions with direction key, to operate PTZ. ...
  • Page 61 Figure 4-31 Virtual LED Step 3 Configure parameters. See Table 4-4. Table 4-4 Virtual LED parameter description Parameter Description Title Enter the title of virtual LED, which will be displayed on the video wall. Enter width and height of virtual LED. Enter coordinate of virtual LED.
  • Page 62 Parameter Description Configure roll mode of virtual LED title on the screen, including Left to Roll mode right, Right to left, Top to bottom and Bottom to top. Configure roll speed of virtual LED title, ranging from 0 to 5. Roll speed It is static text when the roll speed is 0.

  • Page 63: Preview

    Figure 4-33 Add background Step 2 Select Block and Picture Name, and select Enable. Step 3 Click OK. 4.3.4.9.4 Decoding Strategy Drag the slider to adjust window fluency, and thus balance real-time decoding and fluency (only network signal supports this function). Step 1 Select a network signal window, click , and then click...

  • Page 64: Window Function

    Figure 4-35 Preview Table 4-5 Function description of preview interface Name Description Window Preview video in the window. See "4.4.1 Window Function." Carry out single, 4-split, 9-split, 16-split, 25-split and 36-split of the Window split window. Remote Click to enter Network Signal interface. You can device add, modify and delete device.

  • Page 65: Signal Configuration

    Figure 4-36 Window function Table 4-6 Functional description Name Description When the video is in the original status, click the icon, press  and hold on left mouse button to select any area. The selected area will be zoomed in. When the video is zoomed in, press Partial zoom and hold on left mouse button to drag the video image.

  • Page 66: Ptz Control Panel

    Local signal: Display local signal source. For specific configurations, refer to “4.5.4.2 Local  Signal.” Network signal: Display signal source of the added device in “Remote Device”. For specific  adding methods, refer to “4.5.4.1 Network Signal.” 4.4.2.2 Custom You can customize signal group. Custom tab displays added group and signal source. You can drag signal group to the window for loop play of signals in the group.
  • Page 67 Figure 4-37 PTZ Control Table 4-7 PTZ parameters description Parameter Description Click Setup, turn the camera with direction buttons, and click Set Left  Border and Set Right Border to set left and right borders of PTZ scan. Scan Click Start, and PTZ starts to scan. Click Stop, and PTZ stops ...

  • Page 68: Setup

    Setup 4.5.1 System Config On this interface, you can complete general setting, user management, config backup, auto maintenance, system upgrade, picture management, fan control, PTZ control, comm setup, safe management and storage path. 4.5.1.1 General You can configure basic information of the device, such as device information and system date. 4.5.1.1.1 Setting of General Information Set device name, no.
  • Page 69 Figure 4-39 Date Step 2 Configure parameters. See Table 4-9. Table 4-9 Date parameters description Parameter Description Date Format Select date display format you want. Time Format Select time format you want. Date Separator Select date separator you want. System Time Set system time.
  • Page 70 4.5.1.2 User Management User management adopts two-level management mode: user and user group. You can manage their basic information (only those with user management authority can operate user management).  User name and group name support maximum 6 characters and can only be consisted of letter, number, and underline (_).
  • Page 71 Figure 4-41 Add User Step 2 Enter username, password, confirm password and note, and then select group. When selecting a group for a user, authority of the user can only be a subset of  the group, and should be no higher than the group authority. To conveniently manage the user, it is suggested that general user authorities ...
  • Page 72 Figure 4-42 Modify User Step 2 Modify user information. Default user can only modify password, rather than other information. Step 3 Click OK. Modify Password Step 1 Click corresponding to the user you want to modify. Step 2 Select Modify Password. Step 3 Input old password, input new password and confirm password.
  • Page 73 Select Setup > System Config > User Management > User Management > Group. The Group interface is displayed. See Figure 4-43. Figure 4-43 Group 4.5.1.3 Config Backup The configuration file of video matrix platform can be exported to flash drive for backup. When the video matrix platform goes wrong, you can import configuration file to restore configuration quickly.
  • Page 74 Figure 4-45 System maintenance  To manually reboot the system, click Reboot, and the system will reboot at once. Click Shutdown, and the system will be shut down at once.  SSH is used to open background debugging port for technicians. Select SSH Enable, and click OK to enable remote debugging function.
  • Page 75 Step 1 Select Setup > System Config > Picture Management. The Picture Management interface is displayed. See Figure 4-47. Figure 4-47 Picture management Step 2 Click Browse to select a local picture. Step 3 Click Upload to upload local picture. Select one picture, and click Delete to delete the picture.
  • Page 76 4.5.1.7.2 Close Buzzer You can configure buzzer time. In case of alarm, the system will beep continuously according to the set time. You can close buzzer according to your need. Step 1 Select Setup > System Config > Fan Control > Close Buzzer. The Close Buzzer interface is displayed.
  • Page 77 Figure 4-50 PTZ setup Step 2 Configure PTZ parameters. See Table 4-10. Table 4-10 PTZ parameter description Parameter Description Device Type Select device type to be controlled. It is Local by default. Slot Select corresponding slot. Channel Select channel to be configured. Port Select corresponding port.
  • Page 78 Figure 4-51 Comm setup Step 2 Configure parameters. See Table 4-11. Table 4-11 Comm parameters description Parameter Description Slot Select the slot you want to configure. Channel Select the channel you want to configure. Com Type The default is RS–232. Function Configure comm function.
  • Page 79 Figure 4-52 System service Step 2 Enable system service. See Table 4-12. Table 4-12 System service parameters description Parameter Description Common Gateway Interface (CGI) is an interface between external application programs and web server. Audio/Video Transmission Encrypt the audio and video during transmission. Encryption Step 3 Click OK.

  • Page 80: Network

    4.5.1.11 Storage Path Select the storage path for snapshots and records. Step 1 Select Setup > System Config > Storage Path. The Storage Path interface is displayed. See Figure 4-54. Figure 4-54 Storage path Step 2 Click Browse to select the storage path for snapshots and records respectively. Step 3 Click OK.
  • Page 81 Figure 4-55 TCP/IP Step 2 Set TCP/IP parameters. See Table 4-13. Table 4-13 TCP/IP parameters description Parameter Description IP Version Select IP version. It is IPv4 by default. Preferred Enter the configured IP address of DNS server. Server Alternate Enter the configured IP address of alternate DNS server. Server Default Net Card Select default net card.
  • Page 82 Parameter Description The default setting is single NIC. Single NIC: Two Ethernet cards are used independently. Request  HTTP, RTSP and other services of the device through net card 1 or net card 2. You need to configure one default net card (net card 1 by default), to request network services launched by the device, including DHCP, Email and FTP.
  • Page 83 Parameter Description Static  Manually enter the IP address, subnet mask and gateway. DHCP  Select the DHCP box, the system automatically obtains an IP address. When the DHCP function is enabled, the IP address, subnet mask and default gateway cannot be set manually. If DHCP is effective, the obtained information will be displayed ...
  • Page 84 Parameter Description The allowable maximum number of clients accessing the Device at the same time, such as web, platform, and mobile phone. The default value is Connection 128. TCP service port. The default setting is 37777. You can configure this TCP Port parameter according to your actual situation.
  • Page 85 4.5.2.3 IP Filter Set network authority of other devices to access video matrix platform, to enhance device network and data security. Network authority strategy includes white list and black list.  After white list is enabled, only devices in the white list can login web interface successfully. ...

  • Page 86: Event Management

     When you log in web interface with IP host in the white list, you can login the device successfully.  When you log in web interface with IP host in the black list, the system pops up a message that the IP host has been added to black list, and you cannot login successfully.

  • Page 87: Signal Management

    Figure 4-62 IP conflict Figure 4-63 MAC conflict Step 2 Select Enable to enable the alarm function. Step 3 Configure the parameters. See Table 4-17 for details. Table 4-17 Abnormal parameters description Parameter Description After the alarm is stopped, the alarm output is delayed for some Output Delay time, ranging from 0 seconds through 300 seconds.
  • Page 88 Figure 4-64 Network signal Searching and Adding Step 1 Click Device Search. The system starts to search all network signals in the LAN. See Figure 4-65. Figure 4-65 Searching signal Filter device type in Display Filter. For example, select IPC, and all IPC devices will be displayed here.
  • Page 89 Figure 4-66 Adding signal  If the device is under normal use, Connection Status will change from Failed to Successful after several seconds. The system will display Saved successfully again.  If Connection Status remains Failed, the device might not be started, or a black list has been configured, or it is not included in a white list.
  • Page 90 Figure 4-67 Manual add Step 2 Configure the parameters. See Table 4-18 for details. Table 4-18 Manual add parameters description Parameter Description Device Name It is to enter device name. Manufacturer Select device manufacturer. Protocol It is TCP by default. IP Address Configure the IP address of device to be added.
  • Page 91 Step 2 Click Import Config or Export Config in HTTP environment. A dialog box is displayed. See Figure 4-68. Figure 4-68 Dialog box Step 3 Click OK. The system jumps to HTTPS environment. You need to login again, and then click Import Config or Export Config. Deleting Network Signal Select a network signal from the added signal list, and click Delete to delete the network signal.
  • Page 92 Figure 4-69 Input title Step 2 Select the card, and configure channel name and control ID for each channel. Enter Start Control ID and click Setup, so control ID of channels will start from the Start Control ID. Step 3 Click OK.
  • Page 93 4.5.4.2.3 Encode Setup Configure encode parameters of local audio and video signals, including encode mode, stream type and resolution and so on. Step 1 Select Setup > Signal Management > Local Signal > Encode Setup. The Encode Setup interface is displayed. See Figure 4-71. Figure 4-71 Encode setup Step 2...
  • Page 94 Parameter Description Level Baseline and Main are available. Audio encoding format includes G.711A, PCM, G.711Mu, AAC and MPEG2-Layer2. The default format is G.711A. Audio Format Audio format here is effective to audio stream. Step 3 Click OK. 4.5.4.2.4 OSD Custom Customize OSD effect of local signal, so time and channel title will be overlaid onto video.
  • Page 95 Figure 4-73 Custom OSD Step 2 Click Edit Title. The editing box pops up, and 6 titles can be configured at the same time. See Figure 4-74. Figure 4-74 Edit title Step 3 Edit the titles and click OK. Titles are displayed on the left of the interface. See Figure 4-75. Web Operation 89...
  • Page 96 Figure 4-75 Display title Every title can be moved freely. Select one title:  Click Delete to delete the title.  Click Left Align or Right Align. All titles will be aligned on the left or on the right by reference to title position.
  • Page 97 Configure the parameters. See Table 4-21 for details. Table 4-21 Global config parameters description Parameter Description OSD Edge After selection, there is a black edge around font. Private and Standard are available. It is Private by default. Zoom in Standard mode zooms in more than that of private mode. Title Import Import config table to complete batch config.
  • Page 98 Figure 4-78 Ultra-high-resolution Create capture and splicing group as you want. Refer to "4.5.4.3 Signal Group." 4.5.4.3 Signal Group Customize signal group. Signal Group tab displays added group and signal source. You can drag signal group to the window for loop play of signals in the group. Step 1 Select Setup >...
  • Page 99 Move your mouse pointer to Custom device tree or Collection in Group list, and then click The dialog box of creating a group is displayed. See Figure 4-80. Figure 4-80 Create a group Enter group name, and then click OK. A group has been created.

  • Page 100: Display Management

    Figure 4-83 Select device Select one signal or multiple signals. Select All to select all the signals. Step 4 Select a group. Step 5 Click Signals have been divided into groups. See Figure 4-84. Figure 4-84 Grouping is completed  Select a signal from a group, and click to delete the signal.
  • Page 101 4.5.5.1 Video Wall Setup You can configure video walls according to actual quantity and splitting of screens, so signals can be displayed on video walls. Select Setup > Display Management > Video Wall Setup. The Video Wall Setup interface is displayed. See Figure 4-85. Figure 4-85 Video wall setup 4.5.5.1.1 Adding Video Wall...
  • Page 102 Figure 4-87 Add screen Table 4-22 Parameters description Name Description Single Screen Click to add single screen. 4-split Screen Click to add a 4-split screen. 9-split Screen Click to add a 9-split screen. 16-split Screen Click to add a 16-split screen. Click this icon, enter row and column number in the pop-up User Custom Custom interface, and you can add a custom screen.
  • Page 103 Figure 4-89 Copy video wall Step 3 (Optional) Select Show Block Name. Every splicing screen will show a block name, such as Splicing Video Wall 1.  For single screen, it still shows Screen 1, Screen 2 and so on. ...
  • Page 104 Figure 4-91 Slot information Step 5 Select one slot, press and hold on left mouse button to drag the slot onto the screen, and bind the slot channel with screen. See Figure 4-92. All screens on the video wall shall be bound with slot channel; otherwise, when ...
  • Page 105 Figure 4-92 Slot binding Step 6 Double-click a new video wall block. The Block Setup interface is displayed. See Figure 4-93. Figure 4-93 Block setup Step 7 Set parameters. See Table 4-23. Table 4-23 Block setup parameters description Parameter Description Name Configure block name.
  • Page 106 Parameter Description Select Customized to configure resolution of output screen corresponding Resolution to each slot. Step 8 Click OK. Step 9 Click Done. The system exits Video Wall Layout Setup interface. The new video wall is displayed in video wall list. See Figure 4-94. Figure 4-94 Adding is completed New video wall is ON by default.
  • Page 107 Figure 4-95 Screen setup Step 2 Click drop-down list or text box to configure manufacturer, serial port and com address.  They shall be the same with actual manufacturer, serial port and com address (DIP address) of video wall.  Click drop-down list at the top, to configure manufacturer and serial port together.
  • Page 108 Step 3 Click OK. 4.5.5.2.3 Screen Timer Configure fixed ON/OFF time of every screen. Within the configured period, every screen will be turned ON/OFF at the fixed time. Step 1 Select Setup > Display Management > Screen Management > Screen Timer. The Screen Timer interface is displayed.
  • Page 109 Figure 4-98 Display setup Step 2 Configure the parameters. See Table 4-25 for details. Table 4-25 Parameter description Parameter Description Slot Configure slot of display. Channel Configure the channel of display. Configure the resolution of display. Customize the resolution after you Resolution select Customized.
  • Page 110 Parameter Description Drag the slider to adjust the image contrast. The bigger the value is, the more obvious the contrast between the light area and dark area will Contrast become. And vice versa. However, if the value is too big, the dark area is likely to become darker and the light area will be over exposed.
  • Page 111 Parameter Description After the camera enables IVS rule function, rule line turns red and IVS Rule flickers if a moving object enters the alarm zone of blue rule line. After the camera enables tracking box function, the system selects Tracking Box and tracks moving objects with a green box on the output interface.
  • Page 112 Figure 4-100 Output name Step 2 Configure output name and control ID for each channel. Enter Start Control ID and click Setup, so control ID of channels will start from the Start Control ID. Step 3 Click Save. 4.5.5.5 Structured Info Receive structured data info about face, motor vehicle, non-motor vehicle and crowd density, and then display the data on the video wall.

  • Page 113: Info

    Figure 4-101 Structured info Step 2 Select the structure info you want. Step 3 Click OK. Info 4.6.1 Device Info You can view device info, including card info, decode info, device info, system status, system log and online user. 4.6.1.1 Card Info You can view card status, type, port type and temperature status of the video matrix platform.
  • Page 114 Figure 4-103 Decode info You can configure Record Time Interval at the top right corner of the interface, and then click . The system records this channel according to the time interval. 4.6.1.3 Device Info 4.6.1.3.1 Device Info You can view device info and card log of video matrix platform. Step 1 Select Info >...
  • Page 115 4.6.1.3.2 Network Sniffer Network sniffer is to intercept, resend, edit and transfer the data received and sent through network, so as to inspect network security. In case of network error, you can carry out sniffer operation on this interface, download the sniffer file to local device, and provide it to technicians to analyze network status.
  • Page 116 4.6.1.3.3 Ping With ping command, check whether camera or video matrix platform is connected normally. Step 1 Select Info > Device Info > Device Info > Ping. The Ping interface is displayed. See Figure 4-108. Figure 4-108 Ping Step 2 Enter the IP address and ping times, and click Ping.
  • Page 117 When ping function is enabled, you can open only one web client. Otherwise, ping information might not be displayed completely. 4.6.1.3.4 Log Level Configure background printing debugging log level. Step 1 Select Info > Device Info > Device Info > Log Level. The Log Level interface is displayed.
  • Page 118 4.6.1.5 System Log You can search and view system log information about video matrix platform according to time and log type, and backup the log to local PC. Step 1 Select Info > Device Info > System Log. The System Log interface is displayed. See Figure 4-112. Figure 4-112 System log Step 2...

  • Page 119: Help

    4.6.1.7 About Select Info > Device Info > About, and you can view version information about this device. 4.6.2 Help In the Info > Help > User’s Manual, you can read user’s manual online, and you can click Download to download the user’s manual. Web Operation 113...

  • Page 120: Platform Software Operation

    Platform Software Operation Besides web, remote control can be realized with Digital Surveillance System (DSS) and Professional Surveillance System (PSS). For specific operations, please refer to the user’s manual of Digital Surveillance System (DSS) and Professional Surveillance System (PSS). Platform Software Operation 114...

  • Page 121: Faq And Maintenance

    FAQ and Maintenance If your question is not included hereunder, please contact local customer service personnel or call headquarter customer service personnel. We will be always at your service. 1. Q: I cannot boot up the device properly after connecting it to power supply. A: In case that the device doesn’t boot up after normal shutdown and connection with power supply, please press the Power Button on front panel.
  • Page 122  Front panel is not in good contact with interface board, so signals are not output to the interface board. Please pull out and plug the front panel again.  There is an error in front-end device.  Configured screen and observed screen are not the same one. ...
  • Page 123  It is not an active pickup.  It is not an active sound device.  Audio cable breaks down.  Hardware failure. 10. Q: There is audio during monitoring, but no audio during playback. A: This may be due to: ...
  • Page 124 Files\webrec in PC. 15. Q: There is mosaic or no video when preview video in the network. A: This may be due to:  Network is not stable.  The client is subject to resource constraints.  There is area tampering in the device. ...

  • Page 125: Use And Maintenance

    20. Q: I cannot play the downloaded file. A: This may be due to:  There is no video player.  DXB8.1 or higher graphic acceleration software has not been installed.  There is no DivX503Bundle.exe control when you play the AVI file via media player. ...

  • Page 126: Appendix 1 Mouse Operation

    Appendix 1 Mouse Operation This part illustrates mouse operation with right hand. Plug a mouse with USB port into USB port of the device, so as to operate the menu functions. System pops up password input dialogue box if you have not logged in. During live surveillance, left-click to enter main menu or open the navigation bar.
  • Page 127 In numerical input box: Increase or decrease numerical value. Scroll Mouse Switch items in the combo box. Wheel Page up or page down. Move mouse Select and move the control or one item of the control under current coordinate. Select a motion detection area with a frame. Drag mouse Select cover-area.

  • Page 128: Appendix 2 Cybersecurity Recommendations

    Appendix 2 Cybersecurity Recommendations Cybersecurity is more than just a buzzword: it’s something that pertains to every device that is connected to the internet. IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks.
  • Page 129 The account lock feature is enabled by default, and we recommend you to keep it on to guarantee the account security. If an attacker attempts to log in with the wrong password several times, the corresponding account and the source IP address will be locked. Change Default HTTP and Other Service Ports We suggest you to change default HTTP and other service ports into any set of numbers between 1024~65535, reducing the risk of outsiders being able to guess which ports you...
  • Page 130 In order to better ensure the safety of equipment and reduce potential cyber risks, we recommend:  Disable the port mapping function of the router to avoid direct access to the intranet devices from external network.  The network should be partitioned and isolated according to the actual network needs. If there are no communication requirements between two sub networks, it is suggested to use VLAN, network GAP and other technologies to partition the network, so as to achieve the network isolation effect.
