- Page 1 Thermal Monocular HIKMICRO LYNX S & LYNX Pro Series User Manual V5.5.58 202302 Contact Us...
-
Page 2: Table Of Contents
Thermal Monocular User Manual Table of Contents Chapter 1 Overview........................1 1.1 Brief Description ........................1 1.2 Function ..........................1 1.3 Appearance ..........................2 1.3.1 Button ......................... 2 1.3.2 Component ......................... 3 Chapter 2 Preparation ........................ 4 2.1 Charge Device ........................4 2.2 Power On/Off ........................ - Page 3 5.5.2 Record Video ......................21 5.6 Hot Tracking ......................... 22 5.7 Export Files .......................... 22 5.7.1 Export Files via HIKMICRO Sight ................22 5.7.2 Export Files via PC ....................24 Chapter 6 System Settings ......................25 6.1 Date Adjustment ......................... 25 6.2 Synchronize Time ........................
- Page 4 Thermal Monocular User Manual Safety Instruction ........................30 Legal Information ........................33 Regulatory Information ......................35...
-
Page 5: Chapter 1 Overview
The device supports DPC (Defective Pixel Correction) and FFC (Flat Field Correction) which can optimize the image quality. Client Software Connection The device can capture snapshots, record videos, and set parameters by HIKMICRO Sight App after being connected to your phone via hotspot. Storage... -
Page 6: Appearance
Thermal Monocular User Manual 1.3 Appearance 1.3.1 Button Figure 1-1 Buttons on the Device Table 1-1 Function of Button Icon Button Function ● Press: Standby mode/Wake up device Power ● Hold: Power on/off Non-Menu Mode: ● Press: Capture pictures Capture ●... -
Page 7: Component
Thermal Monocular User Manual 1.3.2 Component Eyepiece Diopter Adjustment Knob Tripod Mount Cable Interface Lens Cover Figure 1-2 Overview of Component ● Lens Cover: Protects the lens from dust or scratch. ● Diopter Adjustment Knob: Adjusts the dioptric setting. ● Cable Interface: To connect the device to power supply or transmit data with a type-C cable. ●... -
Page 8: Chapter 2 Preparation
Thermal Monocular User Manual Chapter 2 Preparation Take out the device and accessories. Check them with the packaging list to confirm device and accessories are included and available for use. Read the user manual to learn the usage methods and cautions. 2.1 Charge Device After the device starts up, the OSD (on-screen display) shows the battery status. -
Page 9: Power On/Off
Thermal Monocular User Manual 2.2 Power On/Off Power On When the device is connected to cable or the battery is enough, hold for 2 seconds to power on the device. Power Off When the device is turned on, hold for 2 seconds to power off the device. Note ●... -
Page 10: Quick Menu
Thermal Monocular User Manual Figure 2-2 Menu Description ● Press to move the cursor up. ● Press to move the cursor down. ● Press to confirm and hold it to exit the main menu. 2.3.2 Quick Menu In the live view interface, press to show the quick menu. -
Page 11: Firmware Status
Thermal Monocular User Manual 2.4 Firmware Status 2.4.1 Client Software Connection Connect the device to the HIKMICRO Sight App via hotspot, then you can capture picture, record video, or configure parameters on your phone. Steps 1. Hold to show the main menu of device. -
Page 12: Upgrade Device
2.4.3 Upgrade Device Upgrade Device via HIKMICRO Sight Before You Start Install HIKMICRO Sight on your phone and connect your device to the app. Steps 1. Tap the device series to enter the device information interface. 2. Tap Device Upgrade to enter the firmware upgrade interface 3. - Page 13 Thermal Monocular User Manual Upgrade Device via PC Before You Start Please get the upgrade package first. Steps 1. Connect the device to your PC with cable. 2. Open the detected disk, copy the upgrade file and paste it to the root directory of the device. 3.
-
Page 14: Chapter 3 Image Settings
Thermal Monocular User Manual Chapter 3 Image Settings You can set palettes, brightness, scenes, FFC (flat field correction), and DPC (defective pixel correction) to display the better image effect. 3.1 Adjust Diopter Make sure the eyepiece covers your eye and aim at the target. Adjust the diopter adjustment knob until the OSD text or image is clear. -
Page 15: Adjust Focus
Thermal Monocular User Manual Figure 3-2 Adjust Diopter 3.2 Adjust Focus Slightly rotate the focus ring to adjust the focus of the objective lens. Figure 3-3 Adjust Objective Lens Note ● DO NOT touch the lens directly with your finger, or place any sharp objects near them. ●... -
Page 16: Adjust Image Brightness
Thermal Monocular User Manual 3.3 Adjust Image Brightness Steps 1. In the main menu, select and press to confirm. 2. Press to adjust image brightness. 3. Hold to save and exit. In white hot mode, the higher the value of brightness is, the brighter the image is. The image effect in white hot mode is showed as picture below and effect in black hot mode is opposite. -
Page 17: Select Scene
Thermal Monocular User Manual 3.7 Select Scene You can select proper scene according to actual using scene to improve the display effect. Steps 1. Hold to go to the main menu. 2. Select and press to enter the setting interface. 3. - Page 18 Thermal Monocular User Manual Red Hot The hot part is red-colored in view. The higher the temperature is, the redder the color is. Fusion From high temperature to low temperature, the image is colored in from white, yellow, red, pink to purple.
-
Page 19: Adjust Digital Zoom
Thermal Monocular User Manual 3.9 Adjust Digital Zoom You can zoom the image by using this function. Press in the view mode, the live view switches between 1 ×, 2 ×, 4 × and 8 ×. Note This function varies according to different camera models. 3.10 Set Picture in Picture Mode Steps 1. -
Page 20: Correct Defective Pixel
Thermal Monocular User Manual 3. Press to enter the setting interface. 4. Press to switch FFC mode. – Manual: Hold in live view to correct the non-uniformity of display. – Auto: The device performs FFC automatically according to the set schedule when switching on the camera. - Page 21 Thermal Monocular User Manual ● If the screen OSD blocks the defective pixel, move the cursor to reach the defective pixel, then the device performs mirror display automatically as shown in the figures below. Figure 3-7 Mirror Effect...
-
Page 22: Chapter 4 Measure Distance
Thermal Monocular User Manual Chapter 4 Measure Distance The device can detect the distance between the target and the observation position. Before You Start When measuring the distance, keep the hand and the position steady. Otherwise, the accuracy may be affected. Steps 1. -
Page 23: Chapter 5 General Settings
Thermal Monocular User Manual Chapter 5 General Settings 5.1 Set OSD This function can display or hide the OSD information on the live view interface. Steps 1. Hold to show the main menu. 2. Go to Function Settings, and select 3. -
Page 24: Set Display Brightness
Thermal Monocular User Manual Figure 5-1 Brand Logo Display 5.3 Set Display Brightness You can adjust the display brightness of the screen in the quick menu. Steps 1. In the live view mode, press to show the quick menu. 2. Select , and press to confirm. -
Page 25: Capture And Video
Thermal Monocular User Manual Note Avoid direct sunlight and enable the burning prevention function to reduce the risk of sensor damage from the heat. 5.5 Capture and Video 5.5.1 Capture Picture In the live view interface, press to capture picture. Note When capturing succeeds, the image freezes for 1 second and a prompt shows on the display. -
Page 26: Hot Tracking
You can access device albums and export files to your phone via HIKMICRO Sight. Before You Start Install HIKMICRO Sight on your mobile phone. Steps 1. Open HIKMICRO Sight and connect your device to the app. See Client Software Connection. - Page 27 Thermal Monocular User Manual 2. Tap Media to access device albums. Figure 5-4 Access Device Albums 3. Tap Local or Device to view the photos and videos. – Local: You can view the previous files on the app. – Device: You can view the files of the current device. Note The photos or videos may not show in Device.
-
Page 28: Export Files Via Pc
● When you connect the device to PC for the first time, it installs the drive program automatically. ● You can also export files via HIKMICRO Sight. See the user manual of the app for detailed operation. -
Page 29: Chapter 6 System Settings
Thermal Monocular User Manual Chapter 6 System Settings 6.1 Date Adjustment Steps 1. Hold to show the main menu. 2. Go to General Settings, and select 3. Press to enter the configuration interface. 4. Press to select the year, month, or day to be synchronized, and press change the number, then press again to finish the setting. -
Page 30: Unit Settings
Thermal Monocular User Manual 6.4 Unit Settings You can switch the unit for distance measurement. Steps 1. Hold to show the main menu. 2. Go to General Settings, and select 3. Press to enter the unit setting interface. Press to select the unit as required. 4. -
Page 31: Restore Device
Thermal Monocular User Manual 6.7 Restore Device Steps 1. Hold to show the menu of device. 2. Go to General Settings, and select 3. Press to restore the device to defaults according to the prompt. -
Page 32: Chapter 7 Frequently Asked Questions
Thermal Monocular User Manual Chapter 7 Frequently Asked Questions 7.1 Why does the charge indicator flash improperly? Check the following items. 1. Check whether the device is charged with standard power adapter and the charging temperature is above 0 °C (32 °F). 2. -
Page 33: Chapter 8 Appendix
Chapter 8 Appendix 8.1 Device Command Scan the following QR code to get device common serial port commands. Note that the command list contains the commonly used serial port commands for HIKMICRO thermal cameras. 8.2 Device Communication Matrix Scan the following QR code to get device communication matrix. - Page 34 Thermal Monocular User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. Laws and Regulations ● Use of the product must be in strict compliance with the local electrical safety regulations. Symbol Conventions The symbols that may be found in this document are defined as follows.
- Page 35 Thermal Monocular User Manual voltage and capacity are 3.635 VDC/3350 mAh. ● For long-term storage of the battery, make sure it is fully charged every half year to ensure the battery quality. Otherwise, damage may occur. ● Use the battery provided by qualified manufacturer. Refer to the product specification for detailed battery requirements.
- Page 36 Thermal Monocular User Manual Manufacture Address Room 313, Unit B, Building 2, 399 Danfeng Road, Xixing Subdistrict, Binjiang District, Hangzhou, Zhejiang 310052, China Hangzhou Microimage Software Co., Ltd. COMPLIANCE NOTICE: The thermal series products might be subject to export controls in various countries or regions, including without limitation, the United States, European Union, United Kingdom and/or other member countries of the Wassenaar Arrangement.
- Page 37 INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKMICRO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
- Page 38 Thermal Monocular User Manual CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES. IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER PREVAILS.
- Page 39 Thermal Monocular User Manual Regulatory Information These clauses apply only to the products bearing the corresponding mark or information. EU/UK Compliance Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the Directive 2014/30/EU (EMCD), Directive 2014/35/EU (LVD), Directive 2011/65/EU (RoHS).
- Page 40 Thermal Monocular User Manual Directive 2006/66/EC and its amendment 2013/56/EU (Battery Directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
- Page 41 Web: www.hikmicrotech.com E-mail: support@hikmicrotech.com UD31412B...
