MULTISPENSE 900 W/TOUCHSCREEN CONTROLLER MODULE
3.2

OPERATION

The Controller Module provides the controls for producing liquid flow via a positive displacement pumping mechanism.
The systems utilize solid-state electronics, stepping motor drives, and precision machined ceramic pump heads.
These components combine to provide exceptional accuracy and precision, high reliability, and low maintenance.
IVEK units have custom designed stepping motors and pumps sized to the specific dispensing application to provide
the proper torque and speed.
Volume commands for the Controller Module use number of full revolutions. Rate commands are in revolutions per
minute. The typical resolution of the pumps used is 200 steps per revolution, or 1.8° per step.
3.2.1

Drive System

All operational parameters on the Controller Module are programmed through the touchscreen. Total electronic
control allows for full accountability of cumulative volumes dispensed.
3.2.2

Touchscreen

The touchscreen provides an operator interface to all operating parameters in the Controller Module. New values can
be entered and current values displayed for all the functions of the system. The touchscreen contains nine different
operator interface screens with each providing information to the operator. Start and Stop buttons appear on two
screens for starting and stopping the system.
3.2.2.1 Introduction
Configurations - A configuration is a collection of the operating parameters required to operate the system. The
operating parameters include volume, rate, direction and drawback. For each configuration, the parameters are stored
in the configuration database. All channels use the same value for a given parameter.
Buttons - A button initiates a command being sent to the IVEK Multispense 900 Controller Module. The "Start" and
"Stop" area in the Main screen (Figure 3.8) are examples of buttons.
Boxes - A box looks identical to a button, but provides information only. Pressing a box will have no effect on the
system. The "CHANNEL" and "DESCRIPTION" area in the Fault Screen (Figure 3.13) are examples of boxes.
Screens - There are nine screens used to setup, operate and exit the system as shown in Figure 3.3. Each screen
contains information relating to operating the system. The screens and a brief description are as follows:
Main Screen
Volume & Rate Screen
Configuration Screen
Params A Screen
Params B Screen
Drawback Screen
Fault Screen
Exit Screen
Figure 3.3 shows the screens and provides an overview of the function of each screen. Lines and arrows show
accessibility for each screen.
27 March, 2015
Volume, Rate and Drawback settings are viewed here. The system can be operated from this screen.
Volume and Rate settings are viewed and changed here. The system can be operated from this
screen.
Configurations are changed and stored with this screen. Any parameters changed outside the
configuration will not be saved as a configuration.
Displays Totalizer, Permission, Prime Duration and Ready Out information.
Displays software versions and Controller serial number. Acceleration setting is viewed and
changed (Microspense only).
Drawback and Stall Retries settings are viewed and changed here.
Faults are displayed and cleared.
Clear Totalizer Screen Clears all totalizer values.
Exit the software.
