IVEK DIGISPENSE 3009 Manual

Controller module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DIGISPENSE 3009 CONTROLLER MODULE, STYLE B
Section
Description
3.
DIGISPENSE 3009 CONTROLLER MODULE, STYLE B ....................................................................... 3-2
3.1
DESCRIPTION .................................................................................................................................... 3-3
3.1.1 Front Panel Controls And Indicators ................................................................................................ 3-3
3.1.2 Rear Panel Detail.............................................................................................................................. 3-4
3.1.3 Fluid Movement ................................................................................................................................ 3-6
3.1.4 Dispense Rate .................................................................................................................................. 3-6
3.1.5 Direction ............................................................................................................................................ 3-6
3.1.6 Acceleration ...................................................................................................................................... 3-6
3.1.7 Drawback .......................................................................................................................................... 3-7
3.1.8 Torque .............................................................................................................................................. 3-7
3.1.9 Initial Rate ......................................................................................................................................... 3-7
3.2
ELECTRICAL ....................................................................................................................................... 3-7
3.3
STANDARD OPERATION ................................................................................................................... 3-7
3.3.1 Dispense Mode ................................................................................................................................. 3-8
3.3.2 Meter Mode ....................................................................................................................................... 3-8
3.3.3 Prime Mode ...................................................................................................................................... 3-8
3.3.4 Display .............................................................................................................................................. 3-8
3.3.5 Help .................................................................................................................................................. 3-9
3.3.6 Permission Levels............................................................................................................................. 3-9
3.3.7 Screens ............................................................................................................................................. 3-9
3.3.8 Setup .............................................................................................................................................. 3-31
3.3.9 Start-up ........................................................................................................................................... 3-31
3.3.10 Faults ............................................................................................................................................. 3-33
3.4
ADVANCED OPERATION................................................................................................................. 3-33
3.4.1 Production Mode............................................................................................................................. 3-33
3.4.2 Fluidic Setup Mode ......................................................................................................................... 3-34
3.4.3 Display ............................................................................................................................................ 3-35
3.4.4 Help ................................................................................................................................................ 3-36
3.4.5 Permission Levels........................................................................................................................... 3-36
3.4.6 Recipes ........................................................................................................................................... 3-36
3.4.7 Screens ........................................................................................................................................... 3-36
3.4.8 Status ............................................................................................................................................. 3-86
3.4.9 Rear Panel Interfaces ..................................................................................................................... 3-86
3.4.10 Warnings ........................................................................................................................................ 3-98
3.4.11 Faults ............................................................................................................................................. 3-99
3.4.12 Operating The System ................................................................................................................... 3-99
3.5
INSTALLATION ............................................................................................................................... 3-102
3.6
MAINTENANCE ............................................................................................................................... 3-102
3.6.1 Assembly/Disassembly Procedures ............................................................................................. 3-102
3.7
PROBLEM GUIDE ........................................................................................................................... 3-102
3.8
SPECIFICATIONS ........................................................................................................................... 3-103
3.9
MODEL NUMBER ........................................................................................................................... 3-103
3.10
ILLUSTRATED PARTS BREAKDOWN ........................................................................................... 3-103
29 October, 2019

Table of Contents

IVEK Corp.
Page 3-1
Page #
P03R017E
