◎ 510-gram weight (excluding batteries)
◎ Digitally regulated output - maintains constant brightness
◎ Low-voltage warning function to alert users to replace the batteries
◎ Reverse polarity protection guards against improper battery installation
◎ Dual button switch system in the front for quick switching
◎ Made of durable aircraft-grade aluminum
◎ Premium Type III hard-anodized anti-abrasive finish
◎ Toughened ultra-clear glass lens with anti-reflective coating

Operation Instruction

Two buttons control the TK75's operation. The right side button with a power source
mark is for ON/OFF. The left side button with a recycling mark controls MODES &
BRIGHTNESS LEVELS.
A single press on the power switch turns the TK75 on or off.
With the flashlight on, a single press on the mode switch switches the light between the Turbo
→Low→Mid→High→brightness levels;
To enter into the strobe mode, press and hold the side mode switch for about one second. It
will flash between 6Hz and 15Hz every two seconds.
To enter into SOS mode, press and hold the side mode switch for about three
seconds.
While in strobe or SOS mode, a single press on the side mode switch returns the TK75 to
non-flashing mode where brightness can be adjusted.
Whether it is on or off, the light will enter into strobe or SOS mode if the mode switch is
pressed and held.
With advanced circuitry, the TK75 will remember the last-used brightness level (not flashing
modes) the next time it is turned on.
Overheating protection:
As with any high-output LED flashlight, the TK75 builds up heat when operated at Turbo
brightness for extended periods. For your safety, the light will downshift to High after 20
minutes in Turbo. Return to Turbo using the mode switch.
Note: The video for TK75 operation can be viewed and downloaded from t h e Fenix
website by clicking to SERVICE followed by LIGHT OPERATION VIDEO.

Battery Specifications

Type
Fenix ARB-L2
Non-rechargeable Battery
(Lithium)
Rechargeable Battery
(Li-ion)
Rechargeable Battery
(Li-ion)
Rechargeable Battery
Nominal
Dimensions
Voltage
18650 3.6V
CR123A
16340 3.7V
18650 3.7V
16340 3.2V
Usability
Recommended
3V Banned
Banned
Cautious*
Banned
√
×
×
！
×
