Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Installation tools
Mounting hardware used on this product
includes fasteners with hexalobular socket
heads (ISO 10664). Installation requires
the use of matching tools.
Surge Protection
This product features built-in surge protection circuitry in compliance
with applicable standards.
For comprehensive protection of a luminaire installation against lightning
and electrical surges, it is essential to cover mains supply and data input
lines at the distribution board level, by using respective primary (Type 1)
and secondary (Type 2) surge arrestors in compliance with EN61643-11/
IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and
activated prior to luminaire installation. Also, disconnect luminaires
before operating high-power devices such as, for example, electrical
arc welders.
WE-EF LIGHTING
Installation and Maintenance
Instructions
Bollard
KTX234 LED
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WE-EF KTX234
Summary of Contents for WE-EF KTX234
- Page 1 WE-EF LIGHTING Installation and Maintenance Instructions Bollard KTX234 LED Surge Protection Do not open during installation This product is factory-sealed. This product features built-in surge protection circuitry in compliance Refer to the instructions contained in this with applicable standards. document for details.
- Page 2 Bollard KTX234 KTY234 KTY234 H = 10.63 in H = 23.62 in H = 39.37 in IP66, IK10, Class I, ta = 40°C Weight for KTX234 10.63 for KTY234 23.62 15.0 for KTY234 39.37 19.6 Accessories: Planted root – Galvanised steel.
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. To remove the head of the luminaire during maintenance, loosen screw J with Torx T-20 tool and rotate it anti-clockwise until it can be lifted up. -
Page 4: Installation
Installation The product must be installed and maintained by a building/construction and/or electrical regulations and relevant legislation. Warning: Notice: no longer be valid and shall become the full responsibility of the modifying person/organisation. Claims based on defects attributable to improper installation and/or application, and the consequences thereof, are excluded. -
Page 5: Installation Procedure
J. 6) Connect luminaire cable E to mains supply cable F in watertight terminal connector G (not supplied by WE-EF): a) ON/OFF (L = Phase, N = Neutral, = Earthing) b) 0-10V (L = Phase, N = Neutral, = Earthing, D-/D+ = 0-10V control line). - Page 6 KTX234...
- Page 7 Torque: set screw Screw Torque max. 2.0 Nm (17.7 in-lb) 4.0 Nm (35.4 in-lb) 6.0 Nm (53.1 in-lb) max. 15.0 Nm (132.8 in-lb) max. 100.0 Nm (885.1 in-lb) Direction of Light for [R65] One-sided...
- Page 8 WE-EF LIGHTING United States of America Tel +1 724 742 0030 Fax +1 724 742 0035 info.usa@we-ef.com TO9241W0422 © WE-EF 2022 Technical specifications are subject to change.
- Page 9 WE-EF LIGHTING Installation and Maintenance Instructions Planted Root ESV4 ESV2 ESV6...
- Page 10 Planted Root ESV4 300-0461 ESV4 300-0464 Suitability Suitability 1. KTX234 1. CFY259 2. KTY234 2. GRY234 3. ZFY230 3. RRY324 4. GRY224 4. RRZ324 5. Short post 5. XRY324 6. XRZ324 ESV4 300-0586 ESV4 300-0459 Suitability Suitability 1. XRY334 1. QSI254 2.
- Page 11 Planted Root ESV2 300-9115 ESV6 300-0457 Suitability Suitability 1. PSY414/424 1. LTM440 2. LTM444 3. AMW-C 4. AMF-C 5. AMF-S 6. AML-C ESV6 300-0824 Suitability 1. AML-C 2. FLA461...
-
Page 12: Installation Instruction
When the ESV is being installed for following products: KTY234/KTX234/ZFY230/CFY259/ Instructions are a guideline for installation to FLA461, please orientate the planted root these requirements and provide detail for as shown (base plate is at an angle of 45°... - Page 13 5) For all other product that use ESV6 please orientate planted root as shown (base plate connections/conduit. is parallel to the pathway). For this installation, use M16 bolts supplie. 7) Place the ESV in the form work for concrete 8) Fit the nominated bolts through mounting pad, ensuring orientation, position and levels are correct.
- Page 14 9) Pour concrete to desired level depending on requirement of concrete, paver or soil. Ensure (as per luminaire instructions) onto mounting level. Concrete Paver Soil...
- Page 15 WE-EF LIGHTING United States of America Tel +1 724 742 0030 Fax +1 724 742 0035 info.usa@we-ef.com TO9257W0422 © WE-EF 2022 Technical specifications are subject to change.
