  • Page 1 H- CMD7070 DVD/MP3/CD-RECEIVER DVD/MP3/CD- Instruction manual...

  • Page 2: Table Of Contents

    Dear customer! Thank you for purchasing our product. For safety, it is strongly recommended to read this manual carefully before connecting, operating and/or adjusting the product and keep the manual for reference in the future. Table of contents Table of contents ............................2 Important safeguards ............................3 Installation/Connections ..........................4 Panel controls..............................6...

  • Page 3: Important Safeguards

    Important safeguards · Using the device at temperature below -10º may cause the breakage of the device. BEFORE USING PLEASE HEAT UP THE PASSENGER COMPARTMENT TO THE RECOMMENDED TEMPERATURE! · Read carefully through this manual to familiarize yourself with this high-quality sound system. ·...

  • Page 4: Installation/Connections

    Installation/Connections First complete the electrical connections, and then check them for correctness. Installation way It is an anti-theft installation way. The chassis wear a metal sliding housing. Please have the wiring connection of the power supply, speakers and antenna as for the requirement of the manual, and then install the metal sliding housing into the car according to the diagram.

  • Page 6: Panel Controls

    Panel controls Front panel 1. OPEN BUTTON. Press it to flip down the front panel and you can insert the disc into the compartment or press the EJ button to eject the disc from the disc compartment. 2. IR REMOTE SENSOR 3.
  • Page 7 7. UP AND DOWN BUTTONS. 8. BAND BUTTON. Press it repeatedly to select your desired radio band during RADIO mode. 9. AF (Alternative Frequencies) button. 10. PTY/PLAY/PAUSE (Program Type) button. 11. A.P BUTTON (AUTO-STORAGE/PRESET MEMORY SCAN). 12. PRESET STATION [1-6] AND RPT, RDM BUTTONS. 13.
  • Page 8 Unit chassis face RESET BUTTON. Press it to rehabilitate the distorted program to zero LED indicator. Flashing when detachable panel is remove Rear cover Rear RCA Line out socket Video output (2 RCA jacks). ISO connector Optical digital audio output (optional) Power and speakers wires socket Video output (2 RCA jacks).
  • Page 9 ISO connector PLEASE USE ONLY ORIGINAL CONNECTOR WHICH GOES WITH SET. Notes: · In spite of having any kinds of speaker system, must use 4 ohms impedance of speaker to reduce the distortion during high volume level.

  • Page 10: Remote Control

    Remote control 1. MODE button 2. SEL button 3. Power on/off 4. JOG UP/SEEK UP button 5. F.FWD/NEXT button 6. JOG RIGHT button 7. F.BWD/PREV button 8. JOG DN/SEEK DN button 9. MENU/BAND button 10. Number/Preset Memory buttons 11. PTY/ZOOM button 12.

  • Page 11: Battery Information Of Remote Controller

    25. VOL button 26. JOG LEFT button 27. VOL+ button 28. ENTER button Battery Information of Remote Controller Replace Battery in Remote Controller: 1. Remove the battery holder as the direction indicated by the arrow. 2. Replace the old battery by a new battery with (+) polarity forward. 3.

  • Page 12: Lcd Description

    LCD description 1. DVD/VCD/CD/MP3 indicators 2. Playing status indicators 3. Repeat playback indicators (single or all for DVD disc, single or all for VCD/CD disc, single, folder and all for MP3 disc) 4. Title number indicator 5. Chapter number indicator 6.

  • Page 13: Glossary

    Glossary PBC (PlayBack Control) PlayBack Control is a menu recorded on the disc with SVCD or VCD2.0 format. For the discs contained PBC, it can playback interactive software with the menu displayed on TV. And if the disc contains still images, it can playback high definition of still image.

  • Page 14: Features

    Features 1. Fully compatible Fully compatible with the most popular discs formats such as DVD, CD, CD-R (containing MP3, JPEG), CD-RW represented in the market. 2. Upgrade intelligently Support the function of upgrading the software for playing discs of new formats to keep up with the market competition.

  • Page 15: Compatible Discs

    Compatible discs DVD Video DVD disc include video and audio data. The data can contained by the 12 cm diameter of DVD disc is 7 times of one can contained by the common CD-R disc. Its maximum continuous playback time can be up to 2 hours (one of double-sided disc can be up to 4 hours).
  • Page 16 Picture-CD Compatible with Picture-CD disc. Do not need setting the additional software. Picture-CD is a disc format that stores photo with electronic file format developed by Kodak company. Photo-CD Compatible with Photo-CD disc. Do not need setting the additional soft ware. Photo-CD is a disc format that stores photo with electronic file format developed by Konica company.

  • Page 17: Function Of Controls

    Function of controls 1. POWER BUTTON Press the PWR button on the front panel or POWER button on the remote controller to turn on the unit. 2. MODE/TA BUTTON Press the MD/TA button on the front panel or MODE button on the remote controller to select DISC or RADIO mode.
  • Page 18 When you find the desired color of the LCD backlighting, press it and hold for more than 2 seconds again to set the color of the LCD backlighting and stop flashing. 5. CLOCK DISPLAY AND ADJUSTMENT BUTTONS Press CLK button on the front panel or the remote controller to display time on LCD. Press CLK button and hold it for about 2 seconds to flash HOUR, then press VOL+ or VOL- button on the front panel or the remote controller to set HOUR;...

  • Page 19: Radio Operation

    Radio Operation 1. PRESET STATION [ 1-6 ] BUTTONS A). To memorize the current frequency, press any one of the six preset buttons (1-6) on the front panel or on the remote controller and hold it for more than 2 seconds. B).
  • Page 20 5. PTY (PROGRAM TYPE) BUTTON You can start searching for the radio stations according to their types. Press it shortly to display PTY and flash NEWS. Press and hold it to display NEWS and then press VOL+ or VOL- button to select one of PTY programs: NEWS AFFAIRS INFO...
  • Page 21 When pressed long, AF mode is converted to REGION ON/OFF mode. REGION ON MODE: AF mode or PI SEEK is used to the station which have PI codes same as the current station (PI CODE is checked when AF search is in process). REGION OFF MODE: The regional code in the format of PI code is ignored when AF mode or PI SEEK are in process (PI CODE and covering area are not checked during AF searching).

  • Page 22: Basic Disc Operation

    2. A MP3 disc may contain several folders. Each folder may not contain more than 199 tracks for the player. When writing MP3 disc, you had better divide the disc into several H-CMD7070 folders, and each folder cannot contain more than 199 tracks.
  • Page 23 Common Question Q: Nothing is displayed on TV screen when the DVD player is turned on: A: Ensure that the TV was set to right video input (not TV channel); for example, if you make VIDEO1 INPUT of TV and DVD player connected with each other, then you need to set TV to VIDEO1. Loading Disc 1.
  • Page 24 2) To let pass the tracks while playback press F.BWD/PREV button shortly to find the desired track. Press F.BWD/PREV to play the last chapter/track from the beginning. Press F.BWD/PREV button shortly to playback the current chapter/track from the beginning. Press F.FWD/NEXT button shortly to start playing the next chapter /track. H-CMD7070...
  • Page 25 Playback with DVD Video Menu When you insert a DVD disc into disc compartment, the DVD player begins searching the disc automatically: H-CMD7070 1. It begins to playback automatically and stays at the menu frame. 2. Move the cursor with UP/DOWN/LEFT/RIGHT buttons.

  • Page 26: Advanced Operation

    The mode Repeat Playback makes it possible to watch one fragment or scene several times. 1. Press REPEAT button repeatedly to switch between several REPEAT modes. 2. For different kinds of discs, press REPEAT button repeatedly to switch over between the following REPEAT modes: H-CMD7070...
  • Page 27 2. When PBC mode is on, to return the PBC MENU, press STOP key on remote control. When PBC mode is off, press STOP key on remote control to stop playing. H-CMD7070 Common problem Q: I do not want to look through title menu, I just want to start playing the first track.
  • Page 28 Console Operation 1. During playback, press OSD button to display Console menu. 2. The Console function is only available for DVD/VCD discs, and the Console menus are different between DVD/VCD discs. The Console menu of DVD disc: Item (press UP/DN to Function Selection select desired item)
  • Page 29 Channel Display current sound mode Press LEFT/RIGHT to select the mode of NORMAL or 3D. The Console menu of VCD disc: Item (press UP/DN Function Selection to select desired item) PBC menu is on now (can not change) Chapter Display current chapter number Press LEFT/RIGHT or and total quantity of chapters.
  • Page 30 3. Press UP/DOWN/LEFT/RIGHT buttons to select the start point of the area you want to enlarge. 4. When you enlarge the image to 16X, press ZOOM button again to turn off the ZOOM function to return the original size of the image. H-CMD7070...
  • Page 31 3. On the condition that no subtitle is displayed on TV screen, press SUBTITLE button to display subtitle. Selecting the audio language: H-CMD7070 1. Press AUDIO button to display the information of the current state of audio language and audio output on TV screen.
  • Page 32 2. Then press ANGLE button repeatedly to change current viewing angle. 3. If angle menu is not displayed on TV screen, press ANGLE button to display angle menu. Region Code The region code is used in DVD players and on DVD discs. To be able to play the DVD disc the regional codes on DVD player and on DVD disc must be the same.
  • Page 33 5) Press TITLE key, then input "0" four times "0000". 6) It will display two lines of words on the screen shown as below: Region EDIT:_ Region CODE:0 The first line is the regional code you will set. The second line is the regional code has been set. "0"...
  • Page 34 Common problem Q: After inserting DVD disc into disc compartment, a dialogue window appears and asks me to input a password of 4 figures. Why? A: It happens so because the disc movie you are playing was rated with the Parental Control, and the current rating level of DVD player is lower than one of the disc.
  • Page 35 ADD ALL: mark out and then press ENTER button to make all files of playback list of CD or of the current folder (MP3) copy into the program list. DELETE: mark out and then press ENTER button to delete the selected file from the program list. DELETE ALL: mark out and then press ENTER button to delete all files from the program list.
  • Page 36 · Use the RIGHT button to open the list of the setup item, then use UP/DOWN and ENTER to change the selected options. LANGUAGE Menu When you open the System Setup Menu, the first item of the Setup Menu is LANGUAGE. 1.
  • Page 37 DISPLAY Menu The second item of the Setup Menu is DISPLAY Menu which is used to change the image settings. 1. The function of TV Aspect is used to set the image size while playing the wide screen movie on a common TV set. You may choose the following formats of TV Aspect: 4:3 and 16:9.
  • Page 38 AUDIO Menu The third item of the Setup Menu is AUDIO Menu which is used to change the sound settings. 1. The function of Sample Freq. allows to change the sound settings according to the settings of the attached unit: 48 kHz while using the digital connection the sound will be reproduced with 48 kHz.
  • Page 39 LOCK Menu The forth item of the Setup Menu is LOCK Menu which is used to set Parental Control. 1. The function Level of Parental Control. · Before you enter the item, the system will ask you input the password. ·...
  • Page 40 OTHER Menu The fifth item of Setup Menu is OTHER Menu is used to setup Load Default and Screen Saver. 1. The function Load Default is used to restore all the default settings on the setup menus to their factory settings. If you have revised the defaults in the setup menu, and want to cancel all these modifications, you can choose the item Load Default and press ENTER for confirmation.

  • Page 41: Anti-Theft System

    Anti-Theft System This unit is equipped with a detachable and mask panel. Panel can be detached and taken with you, helping to deter theft. Removing the panel 1.Press OPEN button to open the panel (fig 1). 2.Remove the panel (fig 2). 3.Place the panel into the case and take it with you when you leave the car (fig 3).

  • Page 42: Handling Discs

    Handling discs · Dirty, scratched or warped discs may cause skip ping or noise. · Handle the disc only by the edges. To keep clean do not touch its surface. · Discs should be stored in their cases after use to avoid scratches. ·...

  • Page 43: Troubleshooting Guide

    Troubleshooting guide Cause Solution Symptom General The car ignition is not on. If the power supply is properly connected No power The fuse is blown. to the car accessory switch the ignition key to " ACC ". Replace the fuse. Disc Presence of disc inside the player.
  • Page 44 The radio does not The antenna cable is not connected the Insert the antenna cable firmly select a work, signals are too weak. station manually. the radio station automatic selection does not work.

  • Page 45: Specification

    Specification General. Power supply: 12V DC Current consumption/Fuse: max. 10A/ 10 A Maximum power output: 50Wx4 channels Dimensions (W x H x D) 178 x 50 x 165 mm Working temperature range: -10º - +60º FM Stereo Radio. Frequency range: 64.0 -108.0 MHz Usable sensitivity/ I.F.
  • Page 46 ................................46 ...........................47 ............................50 ..........................57 ..........................58 ........................59 DISC RADIO ....................61 ..............................64 ..........................68 DVD- ................73 ..........................90 ............................91 ..............................91 ....................92 ..........................94...
  • Page 47 · -10º · · · · · · · · · · ·...
  • Page 48 ·...
  • Page 50 OPEN. MD/TA. RADIO CLOCK. EJECT OPEN,...
  • Page 51 RADIO. AF ( PTY ( (1-6) RPT, RDM. (MUTE). MD/TA, BAND, +, -, SEL. V-SEL/ MENU/ ENTER(SEL) VOLUME -UP/DOWN, MENU-UP/DOWN(+/-). EJECT (...
  • Page 52 Reset RCA) RCA)
  • Page 53 ·...
  • Page 54 MODE JOG UP/SEEK UP F.FWD/NEXT JOG RIGHT F.BWD/PREV JOG DN/SEEK DN MENU/BAND PTY/ZOOM ANGLE CLOCK MUTE AUDIO TITLE/PBC A/P SUBTITLE/LOUD REPEAT PLAY/PAUSE STOP...
  • Page 55 VOLUME - JOG LEFT VOLUME + ENTER...
  • Page 56 DVD/VCD/CD/MP3 VCD/CD DVD/VCD CD/MP3 Dolby digital RDS: AF, EON, TA, TP PTY. : VOCAL, POP ROCK...
  • Page 57 PBC ( PBC, DVD-...
  • Page 58 DVD, CD, CD-R ( MP3, JPEG), CD-RW, Dolby Digital. MPEG2. « ». icture CD, Photo CD icture CD Photo CD (Screen Saver) (Screen Saver). Screen Saver.
  • Page 59 DVD Video DVD- (Æ12 CD-R DVD- SVCD SVCD MPEG2. VCD. . SVCD VCD2.0 VCD1.1 VCD2.0 VCD2.0, VCD1.1 Picture CD VCD1.1 (Æ12 ) 74 DVCD DVCD. DVCD . DVCD CD-DA CD-DA. CD-DA CD-DA (Æ12 ) 74 MP3/WMA/JPEG CD-R/CD-RW/CD-ROM MP3/WMA/JPG,...
  • Page 60 Picture-CD Picture-CD . Picture-CD Kodak. Photo-CD Photo-CD . Photo-CD Konica. CD-R/CD-RW CD-R/CD-RW ISO9660, 3, JPG, JPEG, Ac3, PCM, MPG, MPE, WAV,WMA. DVD+/-R DVD+/-R UDF, 3, JPG, JPEG, Ac3, PCM, MPG, MPE, WAV,WMA.
  • Page 61 DISC RADIO POWER POWER MODE MODE : DISC ( RADIO ( AUDIO MODE LEVEL. VOL+ VOL- BASS TREBLE BALANCE FADER VOL+ VOL- VOL+ VOL-,...
  • Page 62 MUTE/LCD COLOUR ( « »). MUTE LCD FLASH , FLASH ON ( FLASH OFF HOUR ( VOL+ SEL, MINUTE ( VOL+ VOL , : FLAT, POP, VOCAL ROCK. OPEN OPEN EJECT...
  • Page 63 LOUD,...
  • Page 64 [1-6] (1 6) [1-6]. A.P. FM1, FM2 BAND RADIO BAND...
  • Page 65 TUNE/SEEK UP/DOWN >>/<< PTY ( NEWS. NEWS, VOL+ VOL-, NEWS ( ) à AFFAIRS ( ) à INFO ( ) à SPORT ( ) à EDUCATE ( ) à DRAMA ( ) à CULTURE ( ) à SCIENCE ( ) à VARIED ) à...
  • Page 66 AF ( , RDS NEW FREQUENCY ( RDS). SEEK, SCAN, AUTO MEMORY RDS- REGION ON/OFF. REGION ON PI SEEK ( . (PI CODE AF). REGION OFF AF).
  • Page 67 EON, EON. SEEK, (SCAN), AUTO MEMORY...
  • Page 68 POWER, DVD- DVD- DVD- 1. DVD- (Screen Saver). DVD- Screen Saver DVD- Screen Saver H-CMD7070 CD-R, CD-R/W, DVD-R DVD-R/W. CD-R, CD-R/W, DVD-R DVD-R/W...
  • Page 69 CD-R, CD-R/W, DVD-R DVD-R/W, DVD- VIDEO 1 INPUT DVD- VIDEO 1. OPEN, DVD- ERROR DISK ( PLAY/PAUSE: PLAY/PAUSE, PLAY/PAUSE,...
  • Page 70 PLAY/PAUSE, STOP: STOP PLAY/PAUSE STOP F.FWD/NEXT F.BWD/PREV F.FWD/NEXT F.BWD/PREV >> / << · DVD- : x2 à x4 à x16 à x100 à · : x2 à x4 à x8à · PLAY/PAUSE, F.BWD/PREV F.FWD/NEXT. F.BWD/PREV H-CMD7070 F.FWD/NEXT,...
  • Page 71 DVD Video DVD- ENTER, PLAY MOVIE ( ENTER, H-CMD7070 MENU, LANGUAGE ( Disc Subtitle ( ENTER SCENE SELECT ( ENTER...
  • Page 72 ENTER MENU TITLE,...
  • Page 73 DVD- REPEAT REPEAT H-CMD7070...
  • Page 74 VCD/SVCD VCD2.0/SVCD TITLE/PCB, PREV. NEXT, STOP STOP H-CMD7070 TITLE/...
  • Page 75 TITLE/ TITLE/ OSD ( DVD/VCD DVD/VCD. DVD- ENTER ENTER...
  • Page 76 ENTER AUDIO SUBTITLE ANGLE NORMAL...
  • Page 77 ENTER PBC OFF) NORMAL BAND DVD- à NTSC à PAL à AUTO à DVD. RANDOM (RDM) RANDOM...
  • Page 78 · DVD Karaoke, VCD, SVCD, CD · VCD/SVCD ZOOM DVD/VCD/Data CD. ZOOM, ZOOM...
  • Page 79 ZOOM DVD- SUBTITLE, SUBTITLE SUBTITLE AUDIO,...
  • Page 80 ANGLE, ANGLE ANGLE, DVD- DVD- DVD-...
  • Page 81 REGION ERROR : DVD- , DVD- "stop" "STOP". "AP" "REG SET". "eject" TITLE, "0" 4 "0000". Region EDIT:_ Region CODE:0 "0" DVD-...
  • Page 82 : 0, 1, 2, 3, 4, 5, 6, "ENTER" « » ),2,3,4,5,6,7,8 ( DVD- DVD- DVD- DVD- DVD- DVD- DVD- DVD-...
  • Page 83 MP3, JPEG, TITLE · JOG UP/DOWN, ENTER, · ENTER, · MP3, STOP (2 ENTER, ENTER, ENTER, ENTER, ENTER,...
  • Page 84 (CD) ENTER, ENTER, TITLE · PLAY/PAUSE ENTER, · STOP · (PLAYBACK PICTURE), (SPEED) SPEED, : >, >>, >>>, PLAYBACK PICTURE ENTER, PLAY/PAUSE ENTER, MENU,...
  • Page 85 · · · ENTER, « » « » DVD- « » DVD. « » « DVD» DVD.
  • Page 86 : 4:3 16:9. 16:9 4:3) 4:3. · · , PAL NTSC. : CVBS.
  • Page 87 DVD- DVD-...
  • Page 88 · · · 1 8. · « ».
  • Page 89 DVD-...
  • Page 90 OPEN, .1). . 2).
  • Page 91 · · · · · · · ·...
  • Page 92 ».
  • Page 93 RESET.
  • Page 94 12 , 10 / 10 178 50 165 -10º - +60º : 64.0 108.0 / 10.7 522-1620 DVD/SVCD/VCD/CD/MP3/Picture-CD/Photo-CD/CD-R /CD-RW/DVD±R/JPEG NTSC/PAL / 24 / 0..+/-30 16:9 4:3 1.0 , 75 RMS (+/-3 (A-vtd)/ . 2000...
