- Page 1 ORIGINAL INSTRUCTIONS>EN PETROL TILLER RAC173PTIL-A USER GUIDE CAUTION: Read the instructions before using the machine.
-
Page 2: Table Of Contents
CONTENTS 1. SAFETY WARNINGS……………………………………………………………3 2. INTENDED USE………………………………………………………………….6 3. PRODUCT DESCRIPTION……………………………………………………..7 4. TECHNICAL DATA………………………………………………………………7 5. ASSEMBLY…………………………………………………………....8 6. OIL AND FUEL FILLING…………………………………………....15 7. OPERATION…………………………………………………………………….16 8. INSPECTION AND MAINTENANCE…………………………………………18 9. TRANSPORTATION AND STORAGE……………………………………….18 10. DECLARATION OF CONFORMITY………………………………………….19 11. WARRANTY…………………………………………………………………….20 12. PRODUCT FAILURE………………………………………………....21 13. WARRANTY EXCLUSIONS………………………………………....22... -
Page 3: Safety Warnings
1. SAFETY WARNINGS WARNING! Before using this tool, please read this safety and operating instructions carefully. Knowing and mastering this information and instructions will help you to use this machine safely and reduce the risk of accidents and electric shocks. If you give this unit to another person, give them this manual as well. - Page 4 h) Use extreme caution when reversing or pulling the machine towards you; i) Do not change the engine governor settings or over speed the engine; j) Start the engine carefully according to manufacturer instructions and with feet well away from the tool(s); k) Do not put your hands or feet near or under rotating parts;...
- Page 5 - Never allow people to approach the tool, especially during its operation. - Do not use the tiller when you are tired, sick, or under the influence of alcohol, drugs or drugs. - Always wear appropriate clothing (do not wear short or loose clothing). Wear safety shoes (do not wear sandals or work barefoot).
-
Page 6: Intended Use
The fuel is flammable; Warning! Rotating tools keep it away from the fire. Do not add fuel while the machine is running Warning! Exhaust gas. Do not use clutch lever STOP position indoor clutch lever START position Caution! Hot surface Remove the spark plug before Wear ocular and hearing protection servicing and maintenance. -
Page 7: Product Description
3. PRODUCT DESCRIPTION 1. Left handle (clutch lever) 2. Right handle (ON / OFF lever) 3. Handle bracket 4. Starter rope 5. Oil tank 6. Fuel tank 7. Air filter 6. Fuel tank 8. Mudguard 9. Blades 10. Wheel 11. Drag strut (depth limiter) 12. -
Page 8: Assembly
5. ASSEMBLY Unpack and lift out the rotary tiller, and take out other accessories and tools in the box. Read the instructions carefully and operate every step strictly according to the instructions. INSTALL THE DRAG STRUT Remove the M6*35 bolts and nuts on the drag strut of the rotary tiller (Fig. 2) (Fig. 3), and insert the drag strut into the corresponding hole of the rotary tiller from bottom to top, lead the screw through the hole of rotary tiller and drag strut using M6*35 (Fig. - Page 9 INSTALL THE ARMREST FIXING SEAT Install the armrest fixing seat on the armrest bracket, and lock it with φ8*φ24*2 washers and hexagon head bolts M6*30 (Fig. 6). Armrest fixing seat Hexagon head bolt φ8*φ24*2 washer Fig. 6 Fig. 7 INSTALL THE LEFT AND RIGHT HANDRAILS Lock the φ8*φ24*2 washers and hexagon head bolts M8*30 in the tool bag, and take off the M8 nuts (Fig.
- Page 10 Fig. 10 Fig. 11 Fig. 12 LOCK THE LEFT AND RIGHT HANDRAILS Lock the 4 bolts and nuts on the left and right handrails by using a wrench (Fig. 12) INSTALL THE CLUTCH CABLE Unscrew an M8 nut among the adjustment screws of clutch cable and lead it through the lug hole of the iron block of left handrail (Fig.
- Page 11 Fig. 15 Fig. 16 Fig. 17 ADJUST THE TIGHTNESS OF CLUTCH CABLE Tighten the screw of the clutch cable by hand (Fig. 18), and screw M8 nut to the position of small iron block to check whether the clutch cable is properly tightened. The clutch cable should be tightened if the blade does not rotate or slips when the rotary tiller is loosening the soil.
- Page 12 INSTALL THE ROTARY TILLER Operate this step if you have purchased our HG60T rotary tiller. First take off the mounted rotary blade at one end, release the quick release pin spring, pull out the quick release pin (Fig. 22), and install the rotary blade on the shaft lever of transmission box.
- Page 13 Right auxiliary fender M8*16 bolt Fig. 26 Fig. 27 INSTALL THE HANDLE The handle is used to facilitate transfer and handling (Fig. 29). First, unscrew the two M8*25 bolts on the variable speed bracket of rotary tiller (Fig. 30), turn the handle upward to the corresponding hole position, and screw the two bolts in and lock with a wrench (Fig.
- Page 14 Fig. 30 Fig. 31 Fig. 32...
-
Page 15: Oil And Fuel Filling
6. OIL AND FUEL FILLING WARNING! Engine delivered without oil or fuel: Fill up with petrol and oil before starting the engine: 1) FUEL Recommended fuel: unleaded petrol with an octane rating of at least 87. Open the fuel tank cap. Pour the fuel carefully into the tank without overflowing. Never exceed the maximum level. -
Page 16: Operation
7. OPERATION Before starting the petrol engine, keep the clutch handle of rotary tiller to the disengaged position. 1) Pull down the supporting wheel frame, detach the limit round rod of support wheel frame from the slot and rotate upward to the gear position of Cultivation (Fig. 34). 2) Set up the required depth of tilling. - Page 17 5) Utilization a) Do not start walking the rotary tiller until it reaches the predetermined speed, then press the clutch handle (Fig. 37) and slowly press its supporting rod into the soil, so that the rotary blade goes into the soil. Handle Fig.
-
Page 18: Inspection And Maintenance
8. INSPECTION AND MAINTENANCE Warning! Always clean the appliance after use. Failure to clean it properly may cause damage to the unit or cause malfunction. Warning! Injuries may occur during work on teeth. Wear protective gloves. Before carrying out any maintenance, switch off the appliance and allow it to cool down. GENERAL MAINTENANCE - Check that the tool is not damaged. -
Page 19: Declaration Of Conformity
BUILDER 32, rue Aristide Bergès -Z1 31270 Cugnaux - France Tel. +33 (0) 5.34.502.502 Fax: +33 (0) 5.34.502.503 Declares that the machine named below PETROL TILLER RAC173PTIL-A Serial number: 20220654886-20220656405 Complies with the following European Directives: Machinery Directive 2006/42/EC EMC Directive 2014/30/EU Emission directive (EU) 2016/1628 &... -
Page 20: Warranty
11. WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor. -
Page 21: Product Failure
12. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank if your product has one. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. -
Page 22: Warranty Exclusions
13. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •... - Page 23 BUILDER SAS 32, rue Aristide Bergès - ZI 31270 Cugnaux – France Made in PRC 2022...
