GILLIAN CABINET
Assembly Instructions
TOOLS REQUIRED BUT NOT INCLUDED:
Phillips head screwdriver, level, pencil
WARNINGS:
Do not throw away packing materials and carton until after
assembly. Assemble all parts on a clean smooth surface
CARE INSTRUCTIONS:
Avoid direct exposure to sunlight. Do not place overheat or air
conditioning vents. Adjust levelers so that the furniture sits flat on
uneven floors.
Blot spills do not rub, with a clean white cloth
Do not use harsh chemicals.
Before cleaning any part test a small spot in a hidden area.
You may need to re-tighten all bolts after initial use.
PARTS INCLUDED
(A) Top Panel
x1
(E) Back Panel
x1
HARDWARE LIST
(J) Hex key
x 1
(N) Screw
[M4 x 30mm] x8
EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.
© 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent
rights. Any unauthorized reproduction, adaptation, distribution or other infringement will be
prosecuted.
(B) Side Panel
x1
(F) Center Rail
(G) Door
x1
(K) Bolt
[1/4" x 1"] x8
(O) Metal Anchor
[M15 x 28mm] x11
(C) Side Panel
x1
(H) Door
x1
x1
(L) Spring washer
[1/4"] x8
(P) Machine Screw
[M8 x 35mm] x11
(D) Bottom Panel
x1
(I) Cleat
x1
(M) Flat washer
[1/4"] x8
Page 1 of 3
Advertisement
Table of Contents
Related Manuals for URBAN OUTFITTERS GILLIAN
Summary of Contents for URBAN OUTFITTERS GILLIAN
- Page 1 [M4 x 30mm] x8 [M15 x 28mm] x11 [M8 x 35mm] x11 EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC. © 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent Page 1 of 3 rights. Any unauthorized reproduction, adaptation, distribution or other infringement will be...
- Page 2 Spring Washer (L) and Bolt (K) as shown. Tighten with supplied Hex Key (J). Do not over-tighten. Locate the holes in the Back Panel (E), insert screws (N) and tighten with a Phillips head screwdriver (not provided). EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC. © 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent Page 2 of 4 rights.
- Page 3 Roll the case back onto its base. Align and insert the Doors (G) and (H) as shown below. EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC. © 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent Page 3 of 4 rights.
- Page 4 STEP 6 With help hang, the Cabinet onto Wooden French Cleat (I) to complete assembly. EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC. © 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent Page 4 of 4 rights.
