Arch Storage Cabinet
Assembly Instructions
TOOLS REQUIRED BUT NOT INCLUDED:
Phillips head screwdriver
WARNINGS:
Do not throw away packing materials and carton until after
assembly. Assemble all parts on a clean smooth surface
CARE INSTRUCTIONS:
Avoid direct exposure to sunlight. Do not place overheat or air conditioning
vents. Adjust levelers so that the furniture sits flat on
uneven floors.
Blot spills do not rub, with a clean white cloth
Do not use harsh chemicals.
Before cleaning any part test a small spot in a hidden area.
You may need to re-tighten all bolts after initial use.
PARTS INCLUDED
(A) Top panel
x1
(F) Front panel
x1
HARDWARE LIST
(J) Hex key
x1
(N) Screw
[M3.5 x 19mm] x54
(R) Screw
[M3 x 19mm] x2
