Standard Features - Compaq SCSI Quick Start Manual

QuickSpecs

Standard Features

P r o c e s s o r
One of the following depending on
Model
C a c h e M e m o r y
One of the following depending on
Model
C h i p s e t
M e m o r y
N e t w o r k C o n t r o l l e r
E x p a n s i o n S l o t s
S t o r a g e C o n t r o l l e r
S t o r a g e
I n t e r f a c e s
DA-10961 World Wide — Version 18 — June 27, 2002
Intel Pentium III processor 1.40 GHz
Intel Pentium III processor 1.26 GHz
Integrated 512-KB Level 2 ECC cache (full speed)
ServerWorks LE 3.0 Chipset with 133-MHz Front Side Bus
Note: For more information regarding ServerWorks, please see the following URL:
http://www.serverworks.com/products/overview.html
Standard 128 MB (PC133-MHz ECC Registered SDRAM DIMM memory)
Maximum 4 GB
Compaq NC3163 Fast Ethernet NIC (embedded) PCI 10/100 WOL (Wake On LAN)
I/O (5 Total, 5 Available)
64-bit/33MHz PCI 4
32-bit/33MHz PCI 1
Integrated Dual Channel Wide Ultra3 SCSI Adapter
Integrated Dual Channel Ultra ATA-100 IDE Adapter with Integrated ATA RAID 0, 1, & 1+0
Diskette Drives 1.44 MB
CD-ROM 40x IDE (ATAPI) CD-ROM Drive
Hard Drives One of the following:
Maximum Internal Storage 254.8 GB (3 x 36.4 GB non-hot-plug + 2 x 72.8 GB hot plug) (internal drive bays,
with Optional Hot Plug Drive and optional hot plug drive cage)
Cage (SCSI Models)
Maximum Internal Storage
320 GB (4 x 80.0 GB) (internal drive bays and removable media bays)
(ATA Models)
Parallel 1
Serial 2
Pointing Device (Mouse) 1
Graphics 1
Keyboard 1
USB 2
Note: Please see the following URL for additional information regarding USB
Network RJ-45 (Ethernet) 1
Compaq ProLiant ML330
PCI Voltage:
3.3 volts
5.0 volts
(SCSI Models) OR
None
(1) 18.2-GB Wide Ultra3 SCSI 10,000 rpm 1 Drive
(1) 40-GB ATA/100 7200 rpm 1 Drive
Models only)
support: http://www.compaq.com/products/servers/platforms/usb-
support.html.
Generation 2 (G2)
(ATA Models)
(SCSI Models only)
(ATA 1.26-GHz and higher
2
