- Page 1 Technical Manual RS CAMBRIDGE PLATFORM BTE GN ReSound A/S Global Technical Operations https://gto.gnresound.com Lautrupbjerg 7 DK-2750 Ballerup, Denmark...
-
Page 2: Table Of Contents
Doc 0428820 rev. B Table of Contents Form-Factor-Matrix & Product Information ..................3-4 Part list..............................5 Part list - HSG parts..........................6 Part list - thin tubes & domes......................7-8 Disassembling procedure ........................9 Replacing mic filter ..........................10 For internal GN Operations only ......................11 Part list - test equipment ........................12 Test equipment ..........................13 HI testing ............................14... -
Page 3: Form-Factor-Matrix & Product Information
Form-Factor-Matrix & Product Information (C70R) Doc 0428820 rev. B Platform CAMBRIDGE BTE C6 Product Model Model Model Model Data Sheet Wireless programming & HI test RT977-DWC RT777-DWC RT577-DWC RT477-DWC 401710000 Integrated Batt - rechargeable Wireless programming & HI test RT971-DWC RT771-DWC RT571-DWC RT471-DWC... - Page 4 Form-Factor-Matrix & Product Information (C80R) Doc 0428820 rev. B Platform CAMBRIDGE BTE C6 Product Model Model Model Model Data Sheet 80R (P) Wireless programming & HI test RT988-DWC RT788-DWC RT588-DWC RT488-DWC Integrated Batt - rechargeable 401711000 80R (HP) Wireless programming & HI test RT988-DWHC RT788-DWHC RT588-DWHC...
-
Page 5: Part List
Part List Doc 0428820 rev. B Part No Description Part No Description 21396100 HOOK ASM,LARGE,CAM (no hook filter) 22215600 KIT,CLR MARKERS,C80R HP 21396200 HOOK ASM,MEDIUM,CAM (no hook filter) 22215000 KIT,PLASTIC HOOKS,CLR MKR,C80R 21396300 HOOK ASM,SMALL,CAM (no hook filter) 21978700 KIT,HOOKS,CLR MARKERS,C70R 21521100 METAL HOOK,ASM,LARGE,CAM (no hook filter) 20420900... -
Page 6: Part List - Hsg Parts
Part List - HSG Parts Doc 0428820 rev. B TOP HSG ASM (C80R) TOP HSG ASM (C70R) COLOUR see note below see note below GOLD 22121770 22121870 WARM GREY 22121771 22121871 ESPRESSO 22121772 22121872 DEEP BLACK 22121773 22121873 BRONZE 22121774 22121874 CHAMPAGNE 22121775... -
Page 7: Part List - Thin Tubes & Domes
Part List - Thin Tubes & Domes (for C70R models only) Doc 0428820 rev. B Description Description Part No Part No Part No Description (Blister packs) (Plastic bag) 22161800 THIN TUBE,CAM,R,SL 0,5 PCS 22268400 THIN TUBE,CAM,R,SL 0,BAG,1P 22267800 FITTING KIT,THIN TUBE&HOOK,BE 22161801 THIN TUBE,CAM,R,SL 1,5 PCS 22268401... - Page 8 Part List - Thin Tubes & Domes (for C70R models only) Doc 0428820 rev. B SUREFIT (SF) - STD, OPEN & CLOSED DOMES Description Bag (10 pcs) DOME,REC,STD,BAG,10PC 21432300 DOME,OPEN,REC,SM,BAG,10PC 21432400 DOME,OPEN, REC,MDM,BAG,10PC 21432500 DOME,OPEN, REC,LGE,BAG,10PC 21432600 DOME,CLOSED,REC,SM,BAG,10PC 21432000 DOME,CLOSED,REC,MDM,BAG,10PC 21432100 DOME,CLOSED,REC,LGE,BAG,10PC 21432200...
-
Page 9: Disassembling Procedure
Disassembling Procedure (C80R is shown) Doc 0428820 rev. B PIN REMOVAL TOOL 15502500 Remove the hook by pulling upwards in a slight angle. Locate the TOP HSG pin and push it out using a pin removal tool. Pull the pin out completely using the tweezers. -
Page 10: Replacing Mic Filter
Replacing Mic Filter Doc 0428820 rev. B Open the filter box and take out one of the tools. Insert the removal tip into the used mic filter FILTER,MIC,CASE,8PCS and then pull the tool straight out. It is important to pull it straight and not on an angle... -
Page 11: For Internal Gn Operations Only
Doc 0428820 rev. B The remaining part of the Technical Manual is for internal GN operations only Page 11 of 15 Not subject to issue control when printed... -
Page 12: Part List - Test Equipment
Part List - Test Equipment DSA6000 Doc 0428820 rev. B Please also see GTO info doc “GI-01-10-002 – Guide to “WL Only test” - to be found on GTO web https://gto.gnresound.com Part No Description 20310800 NOAHLINK WL CPD-1 18220700 COUPL MIC,TSYS,TM-12,MEASURED 22260400 EA TEST JIG,CAM80,DSA6000 (C70R&C80R models) 17517800... -
Page 13: Test Equipment
Test Equipment for the DSA6000 Doc 0428820 rev. B Please also see GTO info doc “GI-01-10-002 – Guide to “WL Only test” - to be found on GTO web https://gto.gnresound.com COUPL MIC,TM-12, 2cc coupler 2cc coupler insert BTE NOAHLINK WL CPD-1 EA TEST JIG,CAM80,DSA6000 MEASURED p/n 30-4838800 can... -
Page 14: Hi Testing
HI Test - DSA6000 Doc 0428820 rev. B Please also see GTO info doc “GI-01-10-002 – Guide to “WL Only test” - to be found on GTO web https://gto.gnresound.com Use of test jig/fixture is mandatory during DSA6000 final HI testing. The HI fixture/jig is placed in the brown test frame. Place the HI in the fixture according to pic and place it all in the test chamber as shown and select the correct test tpix. -
Page 15: Wireless Test
Wireless Test DSA6000 Doc 0428820 rev. B The wireless range test is a combined DSA6000 NOAHLINK SAS-3 Noahlink/SAS Range Check test using the SAS-3 with its MAC address entered into the DSA 6000 system configuration and a Noahlink mounted di- rectly in any of the DSA 6000 units USB ports.
