Arduino MATERIA 101 Assembly Manual page 8

Assembly Manual
Arduino Materia 101
C18 - Kapton tape
- M3x10 bolt
C24
C19 - Spiral cable wrap
- M3x20 nylon stand-offs (6) - Large shrink tube
- Medium shrink
C20
- M3 nuts (12) C25
- Washers (4) - White LED strip
- LED bipolar cable
C21 - Red connectors (2)
- M3x10 nylon stand-offs (8)
C22
- X/Y metal rod guides (8)
- Z metal rod guides (16)
- D6 bearings (4)
C23
- Clips (2)
- M3x10 nylon stand-offs (2)
- Small shrink tube
- 4 wire cables (2)
(Z and Y motors)
- Pulley
- Brass gear wheel
- M3 grub screw
- Bipolar cable for
power switch
- M3x6 bolts (10)
TO COMPLETE THE NOTES
ASSEMBLY YOU WILL
NEED THE FOLLOWING Screws could loosen because of damage or from vibration
TOOLS: so use threadlock on each screw that touches a metal part.
Threadlock is a liquid that fills in the gaps between the threads
- 2.5 Allen Key of screws and hardens into a rubber like substance or glue.
- 1.5 Allen Key
- 3 Allen Key We suggest Loctite 221, a low resistance threadlocker for the
- Medium size cross head some screws. You can also use teflon tape.
(Phillips) screwdriver
- Small size flathead We suggest using sewing machine oil to lubricate the Z axis
screwdriver bearings and guide rods.
- Seeger pliers
- Scissors Arduino's Materia 101 Assembly Kit is meant for a user who
- Soft solderer already has experience with assembly. The manual assumes
- Multimeter the user knows how to use a soldering iron.
- Soldering Tin
- Adhesive tape
- Hair dryer or lighter
8
kIT cONTENTs
