Arduino MATERIA 101 Assembly Manual page 18

Assembly Manual
Arduino Materia 101
Fig. 1
Fig. 3
Fig. 2
assEmBlINg ThE caRRIagE
Fig. 1 Fig. 2
To complete this step, select these Take the left shoulder, fasten two
tools and parts: nylon bearing carriers with M3x6
bolts (4). This part must be attached
Right lateral shoulder to the inside of the shoulder.
—
Left lateral shoulder
—
Stepper motor with pulley Fig. 3
—
X axis D8x244mm guide If you need to, polish the holes of the
—
LMU88 bearings (8) X guide carrier with some sandpaper
—
Seeger rings(12) to ensure a good connection.
—
Nylon bearing supports (4) With M3x6 bolts (2) couple and
—
M3x10 nylon stand-offs (2) and secure the 4 metal rod guides. If
—
M3x20 nylon stand-offs (2) needed, you may use a D8x315mm
M3x6 bolts (20) bar to center the metal rod guides
—
X axis metal rod guides (8) with the
—
T2.5 500 belt tightening. After this step, test if
—
M3x25 bolt the guide is fully inserted into both
—
M3 lock nut metal rod guides. You can do this by
—
12mm 3x6 teflon tube pushing the second rod guide laterally
—
End-stops (2) with a flathead screwdriver.
—
M3 x10 bolts (2) This part must not move.
—
T2.5 16 pulley
—
18
shoulder hole before
