BasE assEmBly
Fig. 1 Fig. 2
To complete this part you will need: Take the bottom tray and turn it over
so the flat side is facing upwards.
Bottom tray
—
Rubber feet (4) Fig. 3
—
Z axis motor with already Separate each foot.
—
connected lead screws
Z support bars Fig. 4
—
Metal rod guides (4) Paste a foot to each corner.
—
M3x35 allen bolts (2)
—
to secure the motor
Arduino Mega 2560
—
board and Ramps shield
M3x20 nylon stand-offs(3)
—
O-Ring to assemble motor
—
40x40 fan
—
M3x6 bolts (8)
—
M3x10 bolts (2)
—
