Arduino MATERIA 101 Assembly Manual page 20

Assembly Manual
Arduino Materia 101
Fig. 8
Fig. 10
Fig. 9
Fig. 11
assEmBlINg ThE caRRIagE
Fig. 8 with M3x6 bolts (4), as you did with
Take LM8UU bearings (2), then using the left one (fig. 3). Fasten the metal
Seeger pliers, assemble Seeger rings rod guides (4) with M3x6 (2) bolts
(2) for each bearing. inside the threaded holes (fig 3).
Repeating the same process you did
Fig. 9 for the left shoulder. For this one,
Assemble the bearing, wedging in also use the LM8UU bearings (2) with
the nylon bearing carrier that we attached Seegers.
assembled before on the left shoulder.
Fig. 10
Now assemble a Seeger ring for each
of four LM8UU bearings. To do this
use a Seeger pliers.
Attach the LM8UU bearings (4) with
only one Seeger on the X bars with 2
bearings to each bar. The Seeger ring
must be internally aligned.
Fig. 11
It is time to assemble the right
shoulder. Take the shoulder and
secure two nylon bearing carriers
20
