When the edge is flat or a drop, use
the short distance of the RoboRuler.
When the edge is a wall, use the
longer distance of the RoboRuler.
Leave a minimum of 1.2 m (4 ft) if the
edge of the lawn borders water.
30
20 cm (8in)
5 cm
(2in)
28 cm (11in)
Min 1.2m (4ft)
• It is not necessary to bury the Perimeter Wire, though you may
do so, up to 5 cm (2 in) deep.
• Burying the wire along exposed areas, such as pavements, is
TIPS
usually recommended.
• If additional Perimeter Wire is required in order to complete
the setup, you can extend it using the waterproof Wire
Connectors provided. (See Section "Splicing the Perimeter
Wire" at the very end).
C. Make Smooth Turns
Maintain a 45° angle at all left-turn corners when laying the
wire along the perimeter.
20 cm / 8 in
45˚
Left turns
