SB 32.24 and SB 16.12 User Guide

Operation at Different Sample Rates

All analogue and AES inputs are available simultaneously for an SB 16.12 running at any available
sample rate, or an SB 32.24 running at 44.1 or 48 kHz.
An SB 32.24 running at 88.2 or 96 kHz has a maximum of 32 inputs available. The last 8 inputs can
either be analogue or AES. This is user-definable on a pair by pair basis directly from System T or
Live console software, or using Network I/O Controller as shown in the AES I/O section of this guide.
Analogue in 1-24
Analogue in 25-32
AES in 1-8
Dante Tx Channel Number
44.1/48 kHz
25-32
33-40
Dante Tx Channel Number
88.2/96 kHz
1-24
25-32 (analogue/AES
depending on switch in
software)
13
