DIGITAL-LOGIC MICROSPACE MSEBX800 User Manual page 41

DIGITAL-LOGIC AG
X30A Printer Port (Centronics, EMI-Filtered)
D-SUB Connector:
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Pin 9
Pin 10
Pin 11
Pin 12
Pin 13
Pin 14
Pin 15
Pin 16
Pin 17
Pins 18-25
X30B Serial Port COM1 RS232 (EMI-Filtered)
D-SUB connector:
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Pin 9
X30C VGA
Pin
1
2
3
13
14
5, 6, 7, 8, 10
4, 9, 11, 12, 15
Signal
Strobe
Data 0
Data 1
Data 2
Data 3
Data 4
Data 5
Data 6
Data 7
Acknowledge
Busy
paper end
select
autofeed
error
init printer
shift in (SI)
GND
Signal
DCD
RXD
TXD
DTR
GND
DSR
RTS
CTS
RI
Signal
Red
Green
Blue
H-Synch
V-Synch
GND
NC
MSEBX800/900 Detailed Manual V1.0
41
